Technical Parameters Category Specification Product Model 5PX2200 Product Family Eaton 5PX Series UPS Topology Double Conversion Online Rated Capacity 2200VA/1980W Input Characteristics - Voltage Range 200-240V AC - Frequency Range 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - Input Connection IEC 320 C14 Output Characteristics - Voltage 200-240V AC - Frequency 50/60 Hz (±0.5% synchronous) - Waveform Pure Sine Wave - Efficiency Up to 96% - Output Connections (8) IEC 320 C13 Battery System - Battery Type Sealed Lead-Acid (SLA) VRLA - Typical Runtime 5.5 minutes at full load - Recharge Time 3 hours to 90% capacity - Battery Life 3-5 years (typical) Physical Specifications - Form Factor Tower/Rack-mountable (2U) - Dimensions 89 × 482 × 660 mm (H×W×D) - Weight 22.5 kg Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <45 dBA at 1 meter Communications - Interfaces USB, Serial, Network slot - Management Eaton Intelligent Power Manager

Technical Parameters Category Specification Product Model 9PX 6000 Product Family Eaton 9PX Series UPS Topology Double Conversion Online Rated Capacity 6000VA/5400W Input Characteristics - Voltage Range 200-240V AC - Frequency Range 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - Input Connection Hardwired Output Characteristics - Voltage 200-240V AC - Frequency 50/60 Hz (±0.5% synchronous) - Waveform Pure Sine Wave - Efficiency Up to 97% (in online mode) - Output Connections Hardwired or multiple outlet strips Battery System - Battery Type Sealed Lead-Acid (SLA) VRLA - Typical Runtime Configurable with external battery packs - Recharge Time 2-4 hours to 90% capacity - Battery Life 3-5 years (typical) Physical Specifications - Form Factor Tower/Rack-mountable (6U) - Dimensions 265 × 482 × 810 mm (H×W×D) - Weight 75 kg Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <55 dBA at 1 meter Communications - Interfaces USB, Serial, Network (standard) - Management Eaton Intelligent Power Manager

Technical Parameters Category Specification Product Model 9SX 1000i Product Family Eaton 9SX Series UPS Topology Double Conversion Online Rated Capacity 1000VA/900W Input Characteristics - Voltage Range 160-280V AC - Frequency Range 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - Input Connection IEC 320 C14 Output Characteristics - Voltage 200-240V AC - Frequency 50/60 Hz (±0.5% synchronous) - Waveform Pure Sine Wave - Efficiency Up to 96% (in online mode) - Output Connections (6) IEC 320 C13 Battery System - Battery Type Sealed Lead-Acid (SLA) VRLA - Typical Runtime 5 minutes at full load - Recharge Time 3 hours to 90% capacity - Battery Life 3-5 years (typical) Physical Specifications - Form Factor 2U Rack-mountable - Dimensions 89 × 482 × 584 mm (H×W×D) - Weight 20 kg Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <45 dBA at 1 meter Communications - Interfaces USB, Serial, Network slot - Management Eaton Intelligent Power Manager - Display Color LCD graphical display

Technical Parameters Category Specification Product Model 9PX 8000 Product Family Eaton 9PX Series UPS Topology Double Conversion Online Rated Capacity 8000VA/7200W Input Characteristics - Voltage Range 200-240V AC - Frequency Range 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - Input Connection Hardwired (L16-30P or similar) - Maximum Current 40A Output Characteristics - Voltage 200-240V AC - Frequency 50/60 Hz (±0.5% synchronous) - Waveform Pure Sine Wave - Efficiency Up to 97% (in online mode) - Output Connections Hardwired or multiple outlet strips - Transfer Time 0 ms Battery System - Battery Type Sealed Lead-Acid (SLA) VRLA - Internal Battery Standard configuration - External Battery Supports multiple EBM units - Typical Runtime Configurable with external battery packs - Recharge Time 2-4 hours to 90% capacity - Battery Life 3-5 years (typical) Physical Specifications - Form Factor Tower/Rack-mountable (6U) - Dimensions 265 × 482 × 810 mm (H×W×D) - Weight 78 kg (with internal batteries) Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <55 dBA at 1 meter - Operating Altitude 0-3000 meters Communications - Interfaces USB, Serial, Network (standard) - Management Eaton Intelligent Power Manager - Display Full-color graphical LCD

Technical Parameters Category Specification Product Model 9PX6000RT Product Family Eaton 9PX Series UPS Topology Double Conversion Online Rated Capacity 6000VA/5400W Input Characteristics - Voltage Range 200-240V AC - Frequency Range 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - Input Connection Hardwired Output Characteristics - Voltage 200-240V AC - Frequency 50/60 Hz (±0.5% synchronous) - Waveform Pure Sine Wave - Efficiency Up to 97% (in online mode) - Output Connections Hardwired or outlet strips Battery System - Battery Type Sealed Lead-Acid (SLA) VRLA - Extended Runtime Configurable with external battery modules - Recharge Time 2-4 hours to 90% capacity - Battery Life 3-5 years (typical) Physical Specifications - Form Factor Tower/Rack-mountable - Dimensions 265 × 482 × 810 mm (H×W×D) - Weight 75 kg Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <55 dBA at 1 meter Communications - Interfaces USB, Serial, Network - Management Eaton Intelligent Power Manager

Technical Parameters Category Specification Product Model 93PR Product Family Eaton 93P Series UPS Topology Double Conversion Online (Three-Phase) Power Range 500-1600 kVA (scalable) Input Characteristics - Voltage 380/400/415V AC, 3PH + N - Frequency 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - THDi <3% at full load Output Characteristics - Voltage 380/400/415V AC, 3PH + N - Frequency 50/60 Hz (±0.1% static) - Waveform Pure Sine Wave - Efficiency Up to 97% (in online mode) - Overload Capability 125% for 10 minutes, 150% for 1 minute Battery System - Battery Voltage 480V DC (standard) - Battery Technology VRLA or Lithium-ion options - Runtime Configurable based on battery cabinets - Recharge Time <4 hours to 90% capacity Physical Specifications - Configuration Modular, N+X redundant - Form Factor Power module + system cabinet - Dimensions Varies by configuration Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <75 dBA at 1 meter Communications - Interfaces Ethernet, SNMP, USB, RS-232 - Management Eaton Intelligent Power Manager

Technical Parameters Category Specification Product Model EATS16A Product Family Eaton Automatic Transfer Switches Rated Current 16A Number of Poles 2 poles Rated Operational Voltage 230V AC Rated Frequency 50/60 Hz Short-Circuit Capacity 6kA Utilization Category AC-33A Mechanical Life 10,000 operations Electrical Life 1,000 operations at rated current Control Voltage 230V AC Operating Temperature -25°C to +60°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (for indoor installation) Standards Compliance IEC 60947-6-1, CE

Technical Parameters Category Specification Product Model EATS16CN Product Family Eaton Automatic Transfer Switches Rated Current 16A Number of Poles 2 poles Rated Operational Voltage 230V AC Rated Frequency 50/60 Hz Short-Circuit Capacity 6kA Utilization Category AC-33A Mechanical Life 10,000 operations Electrical Life 1,000 operations at rated current Control Voltage 230V AC Operating Temperature -25°C to +60°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 Standards Compliance IEC 60947-6-1, CE, CCC

Technical Parameters Category Specification Product Model NZMH2-A63 Product Family Eaton NZM H-series Miniature Circuit Breakers Number of Poles 2 poles Rated Current 63A Rated Voltage 230/400V AC Rated Frequency 50/60 Hz Breaking Capacity 10kA (at 400V AC) Tripping Characteristic C-characteristic (medium trip) Standards Compliance IEC 60898-1, CE Electrical Life 10,000 operations Mechanical Life 20,000 operations Operating Temperature -25°C to +55°C Storage Temperature -40°C to +85°C Protection Degree IP20 (when installed in enclosure) Electrical Characteristics Rated Insulation Voltage: 500V Impulse Withstand Voltage: 6kV Power Loss: <3W per pole Terminal Capacity: 35 mm² max cable size Tripping Characteristics Instantaneous Trip: 5-10 × In (C-characteristic) Thermal Trip: 1.13 × In, t > 1 hour (no trip) Magnetic Trip: 1.45 × In, t < 1 hour (trip) Mechanical Specifications Mounting: DIN rail (35mm) Connection: Screw terminals Torque Requirement: 2.5-3.0 Nm Weight: Approximately 0.4 kg Dimensions: 90 × 35 × 78 mm (H×W×D)

Technical Parameters Category Specification Product Model MATSG-200/3P Product Family Eaton MATSG Automatic Transfer Switch Series Rated Current 200A Number of Poles 3 poles Rated Operational Voltage 400V AC Rated Insulation Voltage 690V AC Rated Frequency 50/60 Hz Short-Time Withstand Current 15kA (1 second) Utilization Category AC-33A Mechanical Life 8,000 operations Electrical Life 800 operations at rated current Control Voltage 24V DC / 230V AC (depending on configuration) Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (for enclosure mounting) Standards Compliance IEC 60947-6-1, CE
