Technical Parameters Parameter Category Description / Value Brand & Series Eaton, M22 Series Model Number M22-R10K Sensor Type Inductive Proximity Sensor Housing Material Typically Nickel-plated brass or Stainless Steel Thread Size M22 x 1.5 Connection Type Pre-wired cable (Specific length varies) Integrated Resistor 10 kΩ Sensing Distance 5 mm (Standard for M22 inductive sensors) Output Type Analog or Special Configuration Supply Voltage 10-30V DC Current Consumption Typically ≤ 15 mA Switching Frequency Typically ≤ 500 Hz Hysteresis Typically ≤ 10% of sensing distance Protection Degree IP67 Ambient Temperature -25°C to +70°C Standards Compliance IEC 60947-5-2

The ABB DATX132 3ASC25H216 Torque Observer Board is designed to provide high-precision torque monitoring in industrial automation systems, enhancing system reliability and efficiency.

Our ABB advanced industrial control modules are designed for seamless integration into the IRB6700 series robots, ensuring optimal performance, enhanced efficiency, and precision in manufacturing environments.
