Parameter Specification Manufacturer / Series Eaton / DG4V-5 Part Number / Model DG4V-5-2AJ-M-U-H6-20 Valve Type Solenoid Operated, Directional Control Valve Configuration 5-Port, 4-Way (5/4) Actuation Type Single Solenoid, Spring Offset Spool Type 2AJ (This is a specific spool configuration. Refer to Eaton's datasheet for exact flow path characteristics). Mounting Style Subplate Mounting (ISO 4401-05 (CETOP 5) interface) Electrical Connection DIN 43650 Form A (with LED indicator and manual override) Coil Voltage (Example) Note: The "-H6-20" typically specifies the coil. H6 often denotes 12V DC. This must be confirmed with the supplier or datasheet as other voltages are available. Protection Class IP65 (Dust tight and protected against water jets) Performance Nominal Flow Rate 20 L/min (5 US GPM) Maximum Operating Pressure 350 bar (5,000 psi) Maximum Peak Pressure 400 bar (6,000 psi) Solenoid Characteristics Solenoid Type Wet Pin AC or DC (specific to order code) Duty Cycle Continuous (Class F insulation system) Hydraulic Fluid Mineral oil-based hydraulic fluids to ISO 11158 (e.g., HV46) Fluid Temperature Range -30 °C to +80 °C (-22 °F to +176 °F) Fluid Viscosity Range 10 to 500 cSt (50 SSU to 2300 SSU) Filtration Level Recommended: 25 µm absolute or better, per ISO 4406 code 18/16/13 Weight (Approx.) ~2.5 kg (5.5 lbs) - (varies with coil and options) Materials Housing Steel Spool Hardened Steel Seals Nitrile (Buna-N) - Standard

The ABB IRB67003HAC042840-001 DSQC608-3HAC12934-1 manipulator harness is a critical component designed for seamless integration with ABB IRB 6700 series robots, ensuring smooth operation and enhanced efficiency in industrial automation applications.

Core Features:

8mm stainless steel probe with M10×1 threading

0.5-2.5mm measuring range (8mV/µm sensitivity)

Wide frequency response (DC to 10kHz)

Military-grade connector for reliable signal transmission

IP67 protection rating for harsh environments

Technical Highlights:

Operating temperature range: -40°C to +150°C

-24VDC power supply with 50Ω output impedance

±1% linearity across full measurement range

Supports cable runs up to 500 meters

Typical Applications:

Turbine and compressor shaft monitoring

Bearing condition assessment

Rotor position and eccentricity measurement

Speed sensing in critical machinery

Certifications & Compliance:

Meets API 670 and ISO 7919 standards

ATEX/IECEx versions available

CE and RoHS compliant

This system is particularly suited for power generation, oil & gas, and heavy industrial applications where reliable machinery protection is essential. Its robust construction ensures accurate measurements even in challenging operating conditions.
