Parameter Specification (Estimated) Notes Product Type Thermal Overload Relay For 3-phase AC motor protection Series Likely part of the Eaton DILER or Meme series Adjustable Current Range e.g., 2.5 - 8.2 A Allows setting to match motor FLC Rated Insulation Voltage (Ui) 690 V / 750 V Rated Operational Voltage (Ue) 690 V AC Compatible Contactors Designed to match specific Trip Class Class 10 Standard trip characteristic (7-10 sec at 600% current) Ambient Temperature -20°C to +60°C Operation without derating Standards IEC/EN 60947-4-1, UL 508, CSA C22.2 Reset Mode Manual or Automatic Selectable Auxiliary Contacts Normally Closed (NC) + Normally Open (NO) For control circuit signaling (e.g., trip indication)

Parameter Specification (Estimated) Notes Product Type Thermal Overload Relay For 3-phase AC motor protection Series Likely part of the Eaton DILER or Meme series Same series as 300AA00382A Adjustable Current Range e.g., 2.0 - 6.3 A Fine-tuned to match the protected motor's FLC Rated Insulation Voltage (Ui) 690 V / 750 V Rated Operational Voltage (Ue) 690 V AC Compatible Contactors Designed to match specific Trip Class Class 10 Standard trip characteristic (7-10 sec at 600% current) Ambient Temperature -20°C to +60°C Operation without derating Standards IEC/EN 60947-4-1, UL 508, CSA C22.2 Reset Mode Manual or Automatic Selectable Auxiliary Contacts Normally Closed (NC) + Normally Open (NO) For control circuit signaling (e.g., trip indication)

Parameter Specification Notes / Explanation Series 2CFR Rated Current 30 A Rated Voltage 250 VAC / 50-60 Hz For single-phase systems Rated Voltage (DC) 350 VDC Leakage Current < 3.5 mA Typical at 250VAC / 50Hz Test Voltage (Hi-Pot) 2250 VAC (Line-Line) 1500 VAC (Line-Ground) For 1 minute Operating Temperature Range -25°C to +100°C With derating above +40°C Termination Style Screw Terminals Housing Material Metal (Shielded) Standards & Approvals Complies with EN/IEC 60939 UL 1283 recognized, CSA certified Mounting Through-hole or bracket

Parameter Specification Notes / Explanation Model Series DGMPC Kepner Proportional Control Valve Valve Size 3 Nominal size, e.g., 3/4" NPT ports Number of Sections 2 Indicated by -ABK- and -BAK- Actuation Type Manual Lever Spring-centered return Maximum Operating Pressure Up to 350 bar (5,000 psi) Maximum Flow Capacity ~ 75 - 110 L/min (20 - 29 US gpm) Port Size Typically 3/4" NPTF Inlet Section Features Includes Relief Valve & Power Beyond "41" code typically indicates this Leakage Classification Industrial Seal Material Standard: Nitrile (Buna-N)

Parameter Specification Notes / Explanation Model Series DGMFN Electrohydraulic Proportional Control Valve Valve Size 5 NG05 (Nominal Size 5), e.g., 3/4" or 1" ports Actuation Type Proportional Solenoid (Electric) Requires an electronic controller (Joystick) Number of Sections 2 Indicated by -A2W- and -B2W- Maximum Operating Pressure Up to 350 bar (5,000 psi) Maximum Flow Capacity ~ 60 - 100 L/min (16 - 26 US gpm) Port Size Typically 3/4" or 1" SAE Section Code - 1 A2W 。 Section Code - 2 B2W Inlet Section Features Includes Main Relief Valve, Power Beyond "-30" code typically indicates this Compensation Type Likely Load Sensing / Pressure Compensated For constant flow independent of load Solenoid Coil Voltage Typically 12 VDC or 24 VDC Standards ISO 4401

Parameter Specification Notes / Explanation Model Series CV1 Port Size 1/8" NPT "16" in the model number typically corresponds to 1/8" Number of Ports 5 (1-Pressure, 2-Exhaust, 2-Work ports A & B) Number of Positions 3 Actuation Type Solenoid Operated, Air Pilot Spool/Center Position Closed Center (All Ports Blocked) This is the "P" type in the model code Voltage Must be specified Common options: 12 VDC, 24 VDC, 120 VAC, 240 VAC Operating Pressure Range 30 - 120 psi (2 - 8 bar) Typical for pneumatic valves Maximum Flow (Cv factor) ~ 0.5 Response Time ~ 20 - 50 ms Duty Cycle 100% Continuous Mounting Style Sub-base / Manifold Mount ISO 5599-1 standard Seal Material Standard: Nitrile (Buna-N) Coil Connection Conduit or DIN Form A With LED indicator

Parameter Specification Notes Manufacturer / Series Eaton DG4V / DG3V D03 / NG6 interface Model Number DG4V-3-2A-M-U-H7-69-EN124 Valve Type Directional Control Valve Number of Ways / Positions 4-Way, 3-Position Porting Size D03 (NG6) ISO 4401 standard Port Thread 7/16"-20 UNF Common for D03 size Actuation Type Solenoid Operated, Spring Return Solenoid Type Single Solenoids (2x) Wet-pin, DC versions Center Position 2A: All Ports Blocked (Closed Center) "A", "B", and "P" to "T" are blocked. Spool Type "-69" Specific metering and performance characteristics for PTO/EN124 applications. Electrical Connection -H7: DIN 43650 Form A IP65-rated connector with LED indicator and manual override. Voltage Options Typically 12 VDC or 24 VDC Must be specified when ordering. Maximum Operating Pressure 350 bar (5,000 psi) Maximum Flow Rate ~ 20 L/min (5.3 US gpm) Dependent on spool type and pressure drop. Fluid Viscosity Range 10 to 380 cSt (50 to 1800 SUS) Fluid Type Mineral-based hydraulic oils, synthetics Compatible with standard hydraulic fluids. Temperature Range -20°C to +80°C (-4°F to +176°F) For hydraulic fluid. Compliance / Standard EN124 European standard for controls of vehicle PTOs. Seal Material Nitrile (NBR) Standard. Other options (e.g., FKM) may be available.

Parameter Specification Notes / Interpretation Manufacturer / Series Eaton CGR Cartridge Check Valve, Pilot Operated Model Number CGR-02-F-K-30 Valve Type Pilot-Operated Check Valve Cartridge Style CETOP C-02-2 ISO 7368 standard cavity. Critical for installation. Port Size #12 SAE O-ring Adjustment Type K-30: Cracking Pressure Adjustment Features an external screw for setting the pilot cracking pressure. Pilot Ratio 4:1 (typical for CGR-02) The pilot pressure required is approximately (System Pressure / Pilot Ratio). Maximum Operating Pressure 350 bar (5,000 psi) Maximum Pilot Pressure 210 bar (3,000 psi) Cracking Pressure Adjustment Range 1.7 to 14 bar (25 to 200 psi) The range over which the pilot opening pressure can be set. Flow Capacity Up to 75 L/min (20 US gpm) Dependent on pressure drop. Seal Material Nitrile (NBR) Standard. Other options like Fluorocarbon (FKM) may be available. Body Material Steel

Technical Specifications Parameter Specification Notes / Interpretation Manufacturer / Series Eaton CGR Cartridge Check Valve, Pilot Operated Model Number CGR-02-FK-30 Functionally identical to CGR-02-F-K-30. Valve Type Pilot-Operated Check Valve Cartridge Style CETOP C-02-2 ISO 7368 standard cavity. Critical for correct installation. Port Size #12 SAE O-ring Adjustment Type FK-30: External Cracking Pressure Adjustment Features an external screw for setting the pilot cracking pressure. Pilot Ratio 4:1 (typical for CGR-02) e.g., With 200 bar system pressure, ~50 bar pilot pressure is needed to open. Maximum Operating Pressure 350 bar (5,000 psi) Maximum Pilot Pressure 210 bar (3,000 psi) Cracking Pressure Adjustment Range 1.7 to 14 bar (25 to 200 psi) The range over which the pilot opening pressure can be set. Flow Capacity Up to 75 L/min (20 US gpm) Dependent on pressure drop. Seal Material Nitrile (NBR) Standard. Body Material Steel

Eaton 300AA00101A Apex? Series Stacked Sectional Control Valve for Lift Trucks This model is an Apex? series, stacked sectional, load-holding directional control valve specifically designed for the hydraulic systems of lift trucks and other material handling equipment. The "300AA00101A" is a complete assembly that typically includes multiple valve sections (spools) stacked together to control various functions such as lift, tilt, and auxiliary attachments.
