Parameter Specification Manufacturer Eaton Model Number DGMC-3-AT-CW-41 Product Line Axiom Series Product Type 3/2 Way Solenoid Valve, Single Solenoid, Spring Return Ports 3 (Inlet, Outlet, Exhaust) Positions 2 Actuation Type Single Solenoid, Spring Return Voltage 110V AC (as indicated by the "-41" suffix) Enclosure Rating Typically NEMA 4X / IP65 (Confirm with datasheet for this specific coil) Port Type Tube Fitting (Inline) Port Thread Standard NPT (National Pipe Taper) Port Size 1/4" NPT (This is strongly implied by the "-AT" code) Electrical Connection DIN 43650 Form A Connector (Standard industrial metric connector) Operating Pressure Range Typical for this type: 30 to 120 PSI (Consult the official datasheet for exact values) Media Compressed Air (Lubricated or Non-Lubricated) Body Material Engineering Plastic / Polymer Seal Material Buna-N (Nitrile) - Standard Mounting Pipe-mounted via its inline ports

Parameter Specification Manufacturer Eaton Model Number DG4V3M-22AL-M Product Line DG4V3 Series Product Type Manual Lever Operated Directional Control Valve Configuration Monoblock (Single Cast Body) Ports 4 (P = Pressure, T = Tank, A & B = Work Ports) Positions 3 (Forward, Neutral, Reverse) Actuation Type Manual Lever, Spring-Centered to Neutral Spool Type 22AL (This is a specific spool configuration. It typically describes a closed-center, parallel pressure path spool, but exact port diagram must be confirmed with datasheet). Max Operating Pressure Up to 350 bar (5,000 psi) Max Flow Rate Typically up to 45 L/min (12 US GPM) (Confirm with datasheet for specific spool) Port Size SAE 3/4"-16 (UNF) (This is standard for the DG4V3M series) Body Material Steel Seal Material Nitrile (Buna-N) - Standard

Parameter Specification Manufacturer Eaton Model Number DG4V-3-2C-M-U-H7-60 Product Line DG4V Series Product Type 4-Way, 3-Position Solenoid Valve Ports 4 (P = Pressure, T = Tank, A & B = Work Ports) Positions 3 Spool Type 2C (Float Center or Motor Center: P blocked, A → T, B → T in center position) Actuation Type Single or Dual Solenoid (Platform model) Solenoid Type Wet-armature (Wet-pin) Voltage 12V DC (as indicated by the "-60" suffix) Coil Connector DIN 43650 Form A (Standard industrial metric connector) Max Operating Pressure Typically 350 bar (5,000 psi) Max Flow Rate Varies with spool; typically up to 19 L/min (5 US GPM) Fluid Compatibility Mineral-based Hydraulic Oil to specified viscosity ranges Port Size ISO 4401-03 (CETOP 3) / NFPA D03 (Standard for the "-3" size) Seal Material Nitrile (Buna-N) - Standard

Parameter Specification Manufacturer Eaton Model Number DG4V-3-2A-M-U-H7-60 Product Line DG4V Series Product Type 4-Way, 3-Position Solenoid Valve Ports 4 (P = Pressure, T = Tank, A & B = Work Ports) Positions 3 Spool Type 2A (This is a specific spool configuration. Typically, "2A" signifies a Closed Center spool where P, T, A, and B are all blocked in the center position). Actuation Type Single or Dual Solenoid (Depending on order; this model is a platform for both) Solenoid Type Wet-armature (Wet-pin) Voltage 12V DC (as indicated by the "-60" suffix) Coil Connector DIN 43650 Form A (Standard industrial metric connector) Max Operating Pressure Typically 350 bar (5,000 psi) Max Flow Rate Varies with spool; typically up to 19 L/min (5 US GPM) Fluid Compatibility Mineral-based Hydraulic Oil to specified viscosity ranges Port Size ISO 4401-03 (CETOP 3) / NFPA D03 (This is standard for the "-3" size designation) Seal Material Nitrile (Buna-N) - Standard

Parameter Specification Manufacturer Eaton Model Series ST300 Full Model Number ST307-V2-150-B Kit / Assembly Code 02-139481 Product Type Soft Starter (Solid-State) with Integrated Bypass Rated Current 150 Amps (This is the key specification from the model number) Motor Power Rating Approx. 75 kW / 100 HP @ 400V AC (This is a typical rating; confirm based on your motor voltage) Supply Voltage 208-600V AC, 50/60 Hz Phases 3 Control Method Voltage Ramp (Standard) with Current Control option Key Features Integrated Bypass Contactor, Internal Overload Protection, Multiple Programmable Start/Stop Modes, Power Factor Correction (during run). Protection Features Overload, Phase Loss, Overcurrent, Jam, Underload, Overvoltage, Undervoltage, Thermal. Control Connections Programmable Digital Inputs, Relay Outputs, Analog Output. Enclosure Open Type (Bare Starter). Designed to be mounted inside a control panel with appropriate IP rating. Communication Optional communication modules (e.g., Modbus, DeviceNet, Profibus) available.

Parameter Specification Manufacturer Eaton Model Number DGMC-3-BT-GW-41 Product Line Axiom Series Product Type 3/2 Way Solenoid Valve, Single Solenoid, Spring Return Ports 3 (Inlet, Outlet, Exhaust) Positions 2 Actuation Type Single Solenoid, Spring Return Voltage 110V AC (as indicated by the "-41" suffix) Enclosure Rating NEMA 4X / IP65 (Dust-tight, waterjet resistant, and corrosion-resistant) Port Type Tube Fitting (Inline) Port Thread Standard BSPT (R') Port Size 1/4" BSPT (This is strongly implied by the "-BT" code) Operating Pressure Range Typical for this type: 30 to 120 PSI (Consult the official datasheet for exact values) Media Compressed Air (Lubricated or Non-Lubricated) Body Material Engineering Plastic / Polymer Seal Material Buna-N (Nitrile) - Standard Coil Connection Integral Pigtail Cable (Common for this style) Mounting Pipe-mounted via its inline ports

Parameter Specification Manufacturer Eaton Model Number 300AA00101A Product Line xEnergy Series Product Type Air Circuit Breaker (ACB) Mounting Type Fixed Number of Poles 3 Rated Current 100A (This is indicated by the "00101" code, where "101" often corresponds to 100A. Always verify on the breaker label.) Frame Size 300A (The "300" frame) Rated Operating Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Rated Frequency 50/60 Hz Breaking Capacity High (e.g., 42kA, 65kA, 100kA at specific voltages). The exact Icu/Ics values depend on the specific trip unit and application voltage. Trip Unit Micrologic Solid-State Trip Unit (Provides protection functions like Long-Time, Short-Time, Instantaneous, and Ground Fault). Operation Manual Storage Spring Mechanism (Charge-Handle-Close sequence) Standards IEC 60947-2

Parameter Specification Manufacturer Eaton Model Number DGMX2-3-PP-BW-B-40 Product Line Axiom MX2 Series Product Type 3/2 Way Solenoid Valve, Single Solenoid, Spring Return Ports 3 (Inlet, Outlet, Exhaust) Positions 2 Actuation Type Single Solenoid, Spring Return Operator Single Solenoid Voltage 24V AC (as indicated by the "-40" suffix) Enclosure Rating NEMA 4X / IP67 (Watertight, dust-tight, and corrosion-resistant) Port Type Manifold Mount (Sub-base) Port Size Typically M5 or according to the manifold base (The "-PP" often refers to porting for a specific manifold system) Operating Pressure Range Typical for this series: 0.5 to 8 bar (~7 to 116 PSI) (Consult official datasheet for exact values) Media Compressed Air (Lubricated or Non-Lubricated) Body Material Engineering Plastic / Polymer Seal Material Buna-N (Nitrile) - Standard Coil Connection Manifold Plug (Integrated into the coil, plugs directly into the manifold base) Mounting Snap-on mounting to a dedicated manifold base

Parameter Specification Manufacturer Eaton Model Number DGMC-3-PT-GW-B-41 Product Line Axiom Series Product Type 3/2 Way Solenoid Valve, Single Solenoid, Spring Return Ports 3 (Inlet, Outlet, Exhaust) Positions 2 Actuation Type Single Solenoid, Spring Return Voltage 110V AC (as indicated by the "-41" suffix) Enclosure Rating NEMA 4X / IP65 (Dust-tight, waterjet resistant, and corrosion-resistant) Port Type Tube Fitting (Inline) Port Size 1/4" (This is strongly implied by the "-PT" code, where 'T' is a common designation for 1/4 inch) Operating Pressure Range Typical for this type: 30 to 120 PSI (Consult the official datasheet for exact values) Media Compressed Air (Lubricated or Non-Lubricated) Body Material Engineering Plastic / Polymer Seal Material Buna-N (Nitrile) - Standard Coil Connection Integral Pigtail Cable (Common for this style) Mounting Pipe-mounted via its inline ports

Parameter Specification Manufacturer Eaton (Axiom Series) Model Number DGMFN-3-Y-A2K-B2K-41 Product Type 3/2 Solenoid Operated Directional Control Valve Ports 3 (Inlet, Outlet, Exhaust) Positions 2 (3/2 Way) Actuation Type Double Solenoid (Dual Coil), Springless Operator Double Solenoid Voltage 110V AC (as indicated by the "-41" suffix) Hazardous Location Rating UL Listed for Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Groups E, F, G; Class III. Enclosure Rating NEMA 4X (Weatherproof & Corrosion-Resistant) / IP67 (Dust-tight and Immersion resistant) Conduit Connection Two 1/2" NPT Conduit Hubs (Standard for explosion-proof enclosures) Port Size 1/4" NPT (Common for this series, but verify with datasheet) Operating Pressure Range Typical for this type: 30 to 120 PSI (Please consult the official datasheet for exact values) Media Compressed Air (Lubricated or Non-Lubricated) Body Material Die-cast Zinc (with corrosion-resistant coating) Seal Material Buna-N (Nitrile) - Standard Coil Class Class F (155°C)
