Parameter Specification Manufacturer Eaton Model Number SV1-10-4-00 Product Line SV1 Safety Switches Rated Current 30 Amps Rated Voltage (AC) 240V AC / 480V AC Electrical Poles 3-Pole (3-Phase) Type Non-Fusible (Safety Switch Disconnect) HP Rating 5 HP @ 240V AC; 10 HP @ 480V AC (Typical for this rating, confirm with datasheet) Enclosure Requirement Designed to be mounted in a suitable enclosure (NEMA 1, 3R, 12, etc.) Operation Manual Rotary Handle Status Indication Visible Blade (ON/OFF visible) Safety Standards UL 98, CSA C22.2 Common Applications Industrial control panels, motor disconnects, HVAC systems, machinery power isolation.

Parameter Specification Manufacturer Eaton (Axiom Series) Model Number DGMFN-5-Y-A2W-B2W-30 Product Type 5/2 Solenoid Operated Directional Control Valve Ports 5 Positions 2 (5/2 Way) Actuation Type Single Solenoid, Spring Return Operator Single Solenoid Voltage 24V DC (as indicated by the "-30" suffix) Hazardous Location Rating UL Listed for Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Groups E, F, G; Class III. Enclosure Rating NEMA 4X (Weatherproof & Corrosion-Resistant) / IP67 (Dust-tight and Immersion resistant up to 1m) Port Size 1/4" NPT (Common for this series, but verify with datasheet) Operating Pressure Range Typical for this type: 30 to 120 PSI (Please consult the official datasheet for exact values) Media Compressed Air (Lubricated or Non-Lubricated) Body Material Die-cast Zinc (with corrosion-resistant coating) Seal Material Buna-N (Nitrile) - Standard Coil Class Class F (155°C) Conduit Hubs Two 1/2" NPT (Standard for explosion-proof enclosures)

Parameter Specification Manufacturer Eaton Model Number 6041615-001 Product Name Maintenance Bypass Switch Assembly Compatible UPS Series Eaton 93PM, 9PX Rated Current 30 A Rated Voltage 250 VAC Electrical Poles 3-Pole (L1, L2, L3, N, G) Switch Type Rotary Cam Switch Switch Positions LINE - BYPASS - OFF Wiring Hardwired (pre-assembled terminal block) Safety Standards UL, cUL Listed Primary Function To safely bypass the UPS for maintenance without dropping the critical load. Typical Use Case Service, repair, or replacement of the connected UPS while keeping the downstream equipment powered.

Parameter Value / Description Product Name Eaton DGMDC 3 Y PK 41 Type / Class Type 2 (Class II) Surge Protective Device (SPD) Rated Voltage 400 V / 230 V AC Nominal System Voltage 230/400 V AC Network Configuration 3-Phase + N (Neutral) + PE (Earth) SPD Circuit Configuration 3+1 Max. Continuous Operating Voltage Uc 335 V L-N / 335 V L-L Voltage Protection Level Up (at In) ≤ 1.5 kV Nominal Discharge Current In (8/20 µs) 20 kA per mode Max. Discharge Current Imax (8/20 µs) 40 kA per mode Impulse Current Iimp (10/350 µs) Not typically specified for Type 2; this is a Type 1 parameter. Short-Circuit Current Rating (SCCR) 50 kA (according to UL 1449 4th Ed.) Backup Fuse Recommendation 160 A gG / gL (or according to local regulations) Response Time < 25 ns Status Indication Visual (Green/Red window) Remote Signaling Contact Yes, typically 1 changeover (CO) contact (e.g., for connection to a building management system) Connection / Cross-Section 35 mm² flexible cable or 25 mm² solid cable Mounting Plug-in module on 35 mm DIN rail Standards Compliance IEC 61643-11, EN 61643-11, UL 1449 (4th Edition) IP Protection Degree IP20 Operating Temperature -40 °C to +80 °C Module Replacement Yes, with removable cartridge (PK 41)

Parameter Value / Description Product Name Eaton C-175-F-11-JA-J Product Line Eaton M22-D Series Type Illuminated Push Button (Momentary Action) Lens Color Green Contact Configuration 1 Normally Open (NO) Contact Mounting Diameter 22 mm Voltage Rating (Light) Depending on the lamp/LED version. Requires cross-referencing the specific "F-11" actuator code. Common voltages are 24V, 110V, 230V AC/DC. Current Rating (Contacts) Typically 10 A at 250 V AC / 6 A at 400 V AC Electrical Life Typically > 1,000,000 mechanical operations (load-dependent) Mechanical Life Typically > 5,000,000 operations Degree of Protection Front side: IP66 (Dust-tight and protected against powerful water jets) Rear side (terminals): IP20 (Protected against touch by fingers) Connection Type Screw Clamp Terminals Material (Actuator) Thermoplastic (Polyamide) Operating Temperature -25 °C to +70 °C Standards Compliance IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14

Parameter Value / Description Product Name Eaton RG-3FK1-30-JA Product Line Eaton RG Series Signal Towers Type Multi-Stack LED Signal Tower / Tower Light Number of Levels / Stories 5 Standard Color Sequence Green - Yellow - Red - Blue - White (from top to bottom) Light Source High-Intensity LEDs Supply Voltage 24 V DC (This is a common voltage for this series; please verify in specific datasheets) Power Consumption Approx. 2.5 W per segment (approx. 12.5 W total for all 5 segments) Lens Material Polycarbonate Degree of Protection IP65 (Front and body) Mounting Via M30 mounting thread (The "-30-" in the part number indicates this) Connection Type Pre-wired cable or connector (specific type and length may vary; often a 2-meter cable) Switching Each segment requires a separate DC voltage signal to activate (e.g., PLC digital output). Operating Temperature -25 °C to +55 °C Storage Temperature -30 °C to +70 °C Standards Compliance IEC/EN 60529, UL 508, CSA C22.2 No. 14

Parameter Value / Description Product Name Eaton TGM PC-3-ABK-BAK-50 Product Line Eaton TGM Series (Heavy-Duty Limit Switches) Type Heavy-Duty Limit Switch with Maintained Contact Action Actuator Type Side Rotary Lever (with roller) Contact Configuration 1 Normally Open (NO) + 1 Normally Closed (NC) (This is the standard for "PC-3" series) Rated Operating Current 10 A at 600 V AC / 0.5 A at 600 V AC (for DC voltages, please check datasheet) Rated Insulation Voltage 600 V Electrical Life 1,000,000 operations (at rated load) Mechanical Life 10,000,000 operations Degree of Protection IP65 (Dust-tight and protected against water jets) Electrical Connection Screw Clamp Terminals Housing Material Metal (typically die-cast zinc) Operating Temperature -25 °C to +85 °C (depending on seal material) Actuator Travel Approximately 12° (for this side rotary lever type) Operating Force Defined by the lever length and spring mechanism. Standards Compliance IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14

Parameter Value / Description Product Name Eaton DGMPC-5-ABN-BAN-30 Product Line Eaton D4B / D4C Series (Heavy-Duty Limit Switches) Type Heavy-Duty Limit Switch with Maintained Contact Action Actuator Type Top Push Plunger with Roller Contact Configuration 2 Normally Open (NO) Contacts (This is the standard configuration for the "PC-5" contact block) Rated Operating Current 10 A at 600 V AC Rated Insulation Voltage 600 V Electrical Life 1,000,000 operations (at rated load) Mechanical Life 10,000,000 operations Degree of Protection IP65 (Dust-tight and protected against water jets) Electrical Connection Screw Clamp Terminals Housing Material Metal (Die-cast zinc) Operating Temperature -25 °C to +85 °C (depending on seal material) Pretravel The distance the plunger moves from its free position to the operating point. (Specific value requires datasheet, e.g., ~4.8mm). Overtravel The distance the plunger can travel beyond the operating point. (Specific value requires datasheet). Operating Force The force required to actuate the plunger (Specific value requires datasheet, e.g., ~3.5 N). Reset Force The force exerted by the internal spring to return the plunger. Standards Compliance IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14

Parameter Specification Notes Series DGMDC-5 Output Power 30 W Continuous Input Voltage (Vin) 4.5 - 5.5 VDC Wide Range Output Voltage (Vout) 13.8 VDC Nominal Output Current (Iout) Up to 2.17 A At full load Efficiency Typically 89% At nominal input, full load Isolation 1500 VDC Input to Output Input-Output Ripple & Noise < 50 mVp-p Typical, 20MHz bandwidth Line Regulation ±0.5% For full input range change Load Regulation ±0.5% From 10% to 100% load Operating Temperature -40°C to +100°C With derating above ~85°C Storage Temperature -55°C to +105°C Package / Mounting Through-Hole (Pin-in-Paste) "TN" Style Dimensions (L x W x H) Approximately 33.0 x 22.6 x 10.2 mm Safety Standards UL/EN/IEC 60950-1 Or equivalent EMC Complies with EN 55032 (FCC Part 15) Class B Typically with external filter

Parameter Specification Notes / Explanation Model Series DG4V Valve Size 03 CETOP 3, NFPA D01 Mounting Interface ISO 4401-03 NFPA D01, H7 Option Number of Ports 4 (P, T, A, B) Number of Positions 3 Actuation Type Solenoid Operated, Hydraulic Pilot Requires pilot pressure Solenoid Type Wet Armature DC Maximum Operating Pressure 350 bar (5,000 psi) Maximum Flow Capacity ~ 45 L/min (12 US gpm) Dependent on spool type and pressure drop Pilot Pressure Range 17 - 35 bar (250 - 500 psi) minimum Required for spool shifting Internal Pilot Supply From 'P' port Return Spring M Spring-centered to neutral position Manual Override U With manual override (standard) Seal Material Standard: Nitrile (Buna-N) Optional Viton available
