Key Parameters Category Description / Value Product Line Eaton DMV (Contactor Relays) Model / Frame Size DMV1000 Main Contacts 3 Poles Contact Configuration 3 Changeover Contacts (Form Z, 1 NO + 1 NC per pole) Rated Operational Current (Iₑ) For control loads, typically up to 20 A (at 240V AC) depending on utilization category Rated Thermal Current (Iᵼₕ) 40 A Rated Operational Voltage (Uₑ) Up to 690 V AC, 250 V DC Coil Control Voltage DC - Specific voltage (24V, 48V, 110V DC etc.) must be verified from device label Utilization Categories AC-15: Control of electromagnetic loads (>72 VA) DC-13: Control of electromagnetic loads Electrical Durability Millions of operations (load dependent) Mechanical Durability ~ 10-30 million operations Standards Compliance IEC/EN 60947-5-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Cage Clamp terminal technology

Key Parameters Category Description / Value Product Line Eaton DMV (Contactor Relays) Model / Frame Size DMV630 Main Contacts 3 Poles Contact Configuration 3 Changeover Contacts (Form Z, 1 NO + 1 NC per pole) Rated Operational Current (Iₑ) For control loads, typically up to 12 A (at 240V AC) depending on utilization category Rated Thermal Current (Iᵼₕ) 25 A Rated Operational Voltage (Uₑ) Up to 690 V AC, 250 V DC Coil Control Voltage DC - Specific voltage (24V, 48V, 110V DC etc.) must be verified from device label Utilization Categories AC-15: Control of electromagnetic loads (>72 VA) DC-13: Control of electromagnetic loads Electrical Durability Millions of operations (load dependent) Mechanical Durability ~ 10-30 million operations Standards Compliance IEC/EN 60947-5-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Cage Clamp terminal technology

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM300A Rated Operational Current (Iₑ) at AC-3 300 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 160 kW / 220 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 410 A Poles 3 (Main Contacts) Coil Control Voltage 220-240 V AC, 50/60 Hz (As explicitly specified) Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads (e.g., heaters) Electrical Durability Hundreds of thousands of operations (dependent on load) Mechanical Durability Millions of operations Arc Extinction System Sintered metal arc chute (as indicated by "S") Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections and cage clamp terminals for auxiliary contacts and coil.

Key Parameters Category Description / Value Product Line Eaton Power Xpert DG1 Model / Hardware DG1-34031FB Firmware / Application Code C54C (Feeder Protection) Key Protection Functions • Overcurrent (50/51, 50N/51N) • Ground Fault (50G/51G) • Negative Sequence / Unbalance (46) • Thermal Overload (49) • Under/Over Voltage (27/59) • Under/Over Frequency (81O/81U) • Reclosing (79) Inputs / Outputs (I/O) Multiple programmable digital inputs, relay (form-C) outputs, and analog inputs. The exact count is defined by the hardware code "34031FB". Metering & Monitoring Measures and displays Volts, Amps, Power (kW, kVAR, kVA), Power Factor, Frequency, Energy, etc. Communication Protocols Typically supports Modbus RTU over RS485 as standard. Other protocols like DNP3 or Ethernet may be available as options. Power Supply Common ratings are 24-48 V DC or 100-240 V AC/DC (The exact specification must be verified from the device nameplate and datasheet). Display Graphical or alphanumeric LCD display for status, measurements, and event logs. Standards Compliance IEC 60255, ANSI C37.90 Mounting Panel-mounted via a cutout, typically for a standard 19-inch rack or panel door.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM400 Rated Operational Current (Iₑ) at AC-3 400 A (For squirrel-cage motors) Rated Operational Power at AC-3 ~ 200 kW / 268 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 475 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is configurable. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors AC-1: Non-inductive loads Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Integrated Adapter RA250 adapter pre-mounted, enabling quick installation of RCU250 modules. Electrical Durability Hundreds of thousands of operations (load-dependent) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.

Key Parameters Category Description / Value Product Line Eaton DILM Model Type DILM32-01 Rated Operational Current (Iₑ) at AC-3 32 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 15 kW / 20 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 40 A Poles 3 (Main Contacts) Coil Control Voltage AC - The specific voltage (e.g., 24V, 110V, 230V, 400V, 500V AC) must be confirmed by the order code sticker on the device itself. The "-01" suffix is consistent with an AC coil. Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads (e.g., heaters) Electrical Durability Millions of operations (dependent on load) Mechanical Durability ~ 10 - 15 million operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Snap-on mounting on 35 mm symmetrical top-hat rail (DIN rail) or via screw mounting using the integrated feet. Connection Cage Clamp terminal technology for easy wiring without tools. Auxiliary Contacts Typically, at least 1 normally open (NO) auxiliary contact is included as standard and can be mounted on the front. Additional auxiliary contact blocks (e.g., DILEM...), mechanical interlocks, and timer modules are available as accessories.

Key Parameters Category Description / Value Product Line Eaton Inductive Proximity Sensors Series LS-S02 Sensor Type Inductive (detects metallic objects) Sensing Distance 12 mm Housing Material PTFE (Teflon) Housing Size / Thread M30 x 1.5 Mounting Shielded (Flush-mountable) Output Configuration NPN, Normally Open (NO) (as indicated by "ZBZ") Connection 4-pin M12 quick-disconnect connector Rated Operating Voltage Typically 10-30 V DC Output Current Typically ≤ 200 mA Standard IEC 60947-5-2

Key Parameters Category Description / Value Product Line Eaton Inductive Proximity Sensors Series LS-S02 Sensor Type Inductive (detects metallic objects) Sensing Distance 2.4 mm Housing Material PTFE (Teflon) Housing Size / Thread M8 x 1 Mounting Unshielded (Non-flush mountable) Output Configuration NPN, Normally Open (NO) (as indicated by "ZBZ") Connection 4-pin M12 quick-disconnect connector Rated Operating Voltage Typically 10-30 V DC Output Current Typically ≤ 200 mA Standard IEC 60947-5-2

Key Parameters Category Description / Value Product Line Eaton Inductive Proximity Sensors Series LS-S02 Sensor Type Inductive (detects metallic objects) Sensing Distance 23 mm Housing Material PTFE (Teflon) Housing Size / Thread M30 x 1.5 Mounting Shielded (Flush-mountable) Output Configuration NPN, Normally Open (NO) (as indicated by "ZBZ") Connection 4-pin M12 quick-disconnect connector Rated Operating Voltage Typically 10-30 V DC Output Current Typically ≤ 200 mA Standard IEC 60947-5-2

Key Parameters Category Description / Value Product Line Eaton ETR (Electronic Thermal Relay) Series ETR4 Rated Operational Current (Iₑ) Setting Range 55 - 70 A (Continuously adjustable within this range) Rated Operational Voltage for Main Circuit Up to 690 V AC, 50/60 Hz Power Supply for Electronics AC, sourced from the main current path (Self-powered) Tripping Class Class 10 (Standard tripping characteristic for general motor starting) Protection Functions • Thermal Overload Protection (based on I²t characteristic) • Phase Failure / Unbalance Protection • Jam / Stall Protection (short-time pickup setting) Ambient Compensation Yes (Provides stable performance across a range of ambient temperatures) Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Snap-on mounting onto compatible Eaton contactors (e.g., DILB, DILM series). Auxiliary Contacts • 1 Normally Closed (NC - 95-96): Trip contact, used to break the control circuit. • 1 Normally Open (NO - 97-98): Alarm contact, can be used for signaling. Test & Reset TEST button to simulate a fault, and STOP/RESET button.
