Key Parameters Category Description / Value Product Line Eaton BZM (Explosion-Proof Enclosures) Type Explosion-Proof Junction Box Rated Current 100 A Body Material Typically Cast Aluminum or other non-corrosive, non-sparking material. Hazardous Location Classifications Certified for Class I, Division 1, Class II, Division 1, and Class III groups (Exact certification must be verified from product documentation). Enclosure Rating Typically NEMA 4X (Weatherproof and Corrosion-Resistant) Conduit Entries Multiple threaded openings (specific number and size defined by the "X1N-3" code). Cover Bolted cover with an integral sealing surface to maintain explosion-proof integrity. Internal Volume Specific internal cubic capacity for housing connections.

Key Parameters Category Description / Value Product Line Eaton BZM (Explosion-Proof Enclosures) Type Explosion-Proof Lighting Distribution Box Rated Current 50 A (as indicated by "AX50" suffix) Internal Component Includes a 50A circuit breaker or switch-disconnector Body Material Typically Cast Aluminum Hazardous Location Classifications Certified for Class I, Division 1, Class II, Division 1, and Class III (Exact certification must be verified from product documentation) Enclosure Rating NEMA 4X (Weatherproof and Corrosion-Resistant) Conduit Entries Multiple threaded openings Cover Bolted cover with integral sealing surface

Key Parameters Category Description / Value Product Line Eaton BZM Explosion-Proof Enclosures Type Explosion-Proof Distribution Box Rated Current 100 A (as indicated by "AX100" suffix) Internal Component 100A circuit breaker or switch-disconnector Body Material Cast Aluminum Hazardous Location Class I Division 1, Class II Division 1, Class III Enclosure Rating NEMA 4X Protection Level IP66/IP67

Key Parameters Category Description / Value Product Line Eaton Encoders Series PDG Type Incremental Encoder Housing Diameter 13 mm Shaft Type Hollow Shaft (with specific clamping mechanism) Resolution 80 PPR (Pulses Per Revolution) Output Channels A, B two channels with 90° electrical phase shift Output Circuit Typically Complementary (Differential) Output Supply Voltage 5-30 V DC Max. Rotation Speed Typically 6000 rpm Output Frequency Typically 100 kHz Protection Class Typically IP50-IP64

Key Parameters Category Description / Value Product Line Eaton EIS (Signal Towers) Series EIS-40 Type Single-level Module Lens Diameter 40 mm Mounting Designed for modular stacking with other EIS-40 units and accessories. Compatible Lamps/LEDs Uses separate bulb or LED cartridges (e.g., standard incandescent, long-life LED modules) which are inserted into the unit. Lens Colors Available in various colors (e.g., Red, Yellow, Green, Blue, White) depending on the ordered variant. Voltage Depends on the installed lamp or LED cartridge (e.g., 24V, 48V, 110V, 230V AC/DC). Connection Typically screw terminals.

Key Parameters Category Description / Value Product Line Eaton FRBdM (RCBOs) Rated Current (Iₙ) 6 A Tripping Characteristic (Overcurrent) C-Curve (Instantaneous trip between 5-10 x Iₙ) Number of Poles 1P + N (2-Pole) Rated Operational Voltage (Uₑ) 230 V AC (Single-Phase) Rated Residual Operating Current (IΔn) 30 mA (0.03 A) RCD Type Type A (For AC and pulsating DC residual currents) Tripping Characteristic (Residual Current) General Type (G) - Instantaneous tripping Breaking Capacity According to standard (e.g., 6 kA). Standards Compliance IEC/EN 61009-1 (RCBOs) Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Screw terminals.

Key Parameters Category Description / Value Product Line Eaton FI (Residual Current Releases) Type Residual Current Release (RCD Module) Compatible Main Device Specific Eaton load breakers (e.g., certain PK series switches). Poles For use with 4-pole (3P+N) main devices. Rated Operational Voltage (Uₑ) 400 V AC (Three-Phase + N) Rated Residual Operating Current (IΔn) 30 mA (0.03 A) RCD Type Type A (For AC and pulsating DC residual currents) Mounting Side-mounted onto the compatible load breaker. Connection Wiring for the current transformer and auxiliary connections.

Key Parameters Category Description / Value Product Line Eaton PLD (RCBOs) Rated Current (Iₙ) 40 A Tripping Characteristic (Overcurrent) D-Curve (Instantaneous trip between 10-20 x Iₙ) Number of Poles 4 Poles (3P + N) Rated Operational Voltage (Uₑ) 400 V AC (Three-Phase + N) Rated Residual Operating Current (IΔn) 30 mA (0.03 A) RCD Type Typically AC Type (Responds to alternating sinusoidal residual currents) Breaking Capacity According to standard (e.g., 6 kA, 10 kA). Standards Compliance IEC/EN 61009-1 (RCBOs) Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Screw terminals.

Key Parameters Category Description / Value Product Line Eaton NZM Accessories Compatible Breakers Specific models within the NZM series (e.g., certain frame sizes of NZM2, NZM3, NZM4). Compatibility must be verified. Function Motor Operator (Electric Drive) for remote OPEN and CLOSE operations. Control Voltage A common standard voltage for this type of accessory is 230V AC. However, the exact voltage must be confirmed by the order code and device label. Operation Electrically charges the breaker's spring-energy mechanism for a "CLOSE" operation. The "OPEN" command trips the breaker. Mounting Mounts directly onto the compatible NZM breaker. Control Connections Terminals for the power supply and control signals (e.g., Open, Close, Common). Manual Override Typically includes a manual crank or lever for local operation in case of power loss or for maintenance.

Key Parameters Category Description / Value Product Line Eaton NZM2 Accessories Compatible Breakers NZM2 series breakers of the specified frame size (Frame 4). Function Undervoltage Release (UVR) Rated Control Supply Voltage (Us) A common standard voltage is 400V AC, 50/60 Hz. However, the exact voltage must be confirmed by the order code sticker on the device itself, as other voltages (e.g., 230V AC, 110V AC) are available. Mounting Mounts directly onto the compatible NZM2 breaker. Operation The breaker can only be closed when the supply voltage is present and above the trip threshold. It automatically trips when the voltage drops below the threshold or is lost.
