Key Parameters Category Description / Value Product Line Eaton Crouse-Hinds (Hazardous Location Equipment) Fixture Type Explosion-Proof Fluorescent Luminaire Lamp Type & Quantity T8 Fluorescent Lamps, typically 2 lamps, 24 inches (2-foot) long Rated Voltage 120 V AC (as indicated by "N3" code) Housing Color White (as indicated by "W") Hazardous Location Classifications Typically certified for Class I, Division 2 and Class II, Division 2 groups. May also be suitable for Class III. The exact certification must be verified from the product label and documentation. Enclosure Rating Typically NEMA 4X (Weatherproof and Corrosion-Resistant) Body Material Typically fiberglass-reinforced polyester or other non-corrosive material. Lens Material Polycarbonate or tempered glass.

Key Parameters Category Description / Value Product Line Eaton Power Quality (Active Harmonic Filters) Model / Series EMA71 Type Active Harmonic Filter (AHF) Key Functions • Harmonic Mitigation (e.g., 2nd to 25th order or higher) • Reactive Power Compensation (Power Factor Correction) • Load Balancing (for three-phase systems) Rated Current Available in various standard ratings (e.g., 50A, 100A, 150A, 200A, 300A). Rated Voltage 200-480V AC, 50/60 Hz (Three-Phase, 3-Wire or 4-Wire systems) Topology IGBT-based, PWM technology. Response Time Typically < 1 ms. Communication Standard communication interfaces (e.g., Modbus, Ethernet/IP) for monitoring and control. Mounting Wall-mounted or floor-standing cabinet. Standards Compliance IEEE 519, IEC 61000, UL, CE.

Key Parameters Category Description / Value Product Line Eaton Crouse-Hinds (Hazardous Location Equipment) Fixture Type Explosion-Proof Flood Light (Luminaire) Lamp Type & Wattage Typically 100W Metal Halide (MH) or High-Pressure Sodium (HPS) (as indicated by "R10" code). The exact lamp type and socket must be verified from the product datasheet. Rated Voltage 120 V AC (as indicated by "N3" code) Housing Color Silver / Grey (as indicated by "S") Hazardous Location Classifications Typically certified for Class I, Division 2 and Class II, Division 2 groups. May also be suitable for Class III. The exact certification must be verified from the product label and documentation. Enclosure Rating Typically NEMA 4X (Weatherproof and Corrosion-Resistant) Body Material Typically aluminum or other robust, corrosion-resistant material. Lens Material Tempered glass.

Key Parameters Category Description / Value Product Line Eaton Crouse-Hinds (Hazardous Location Equipment) Type Explosion-Proof Junction Box Body Material Typically Cast Aluminum or other non-corrosive, non-sparking material. Hazardous Location Classifications Typically certified for Class I, Division 1, Class II, Division 1, and Class III groups. The exact certification must be verified from the product label and documentation. Enclosure Rating Typically NEMA 4X (Weatherproof and Corrosion-Resistant) Conduit Entries Multiple threaded openings (e.g., 3/4" NPT). The exact number and size are defined by the "V65" code. Cover Bolted cover with an integral sealing surface to maintain explosion-proof integrity. Internal Volume Specific internal cubic capacity for housing connections.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM400 Rated Operational Current (Iₑ) at AC-3 400 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 200 kW / 268 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 475 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is a configurable parameter. The coil is available in a wide range of AC and DC voltages (e.g., 24V, 110V, 230V, 400V, 500V). The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads Arc Extinction System Sintered metal arc chute (as indicated by "S") Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Electrical Durability Hundreds of thousands of operations (dependent on load) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.

Key Parameters Category Description / Value Product Line Eaton NZM2 Model / Frame Size NZM2-XAD Release Type Fixed Thermal-Magnetic (Non-adjustable) Rated Current (Iₙ) 250 A (Fixed value) Poles 3-Pole & 4-Pole versions are commonly available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) High, typically 50 kA or more at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Release Characteristics Thermal (Long Delay): For overload protection. Magnetic (Instantaneous): For short-circuit protection. Both are factory-set and non-adjustable. Standards Compliance IEC/EN 60947-2 Mounting Fixed Mounting (for bolted installation in panels). Connection Screw terminals. Auxiliary Contacts & Accessories Compatible with the full range of NZM2 accessories, such as auxiliary contacts, undervoltage release, and shunt trip, which can be snapped onto the breaker.

Key Parameters Category Description / Value Product Line Eaton Air Circuit Breakers Series N4 Rated Current (Iₙ) 1000 A Poles 3-Pole & 4-Pole versions are available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Very high, typically 65 kA to 100 kA at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Trip Unit Type Standard "AS" Electronic Trip Unit • Provides adjustable protection functions (overload, short-circuit, and ground-fault). Operation Mechanism Manual stored-energy spring mechanism (allows for quick ON/OFF operation). Mounting Fixed Mounting (designed for bolted installation in switchgear panels) or Draw-out Version (available as an option). Standards Compliance IEC/EN 60947-2 Connection Primary power connections are typically made via busbars. Standard Accessories The "AS" version typically comes with a basic set of indicators and possibly a few built-in auxiliary contacts. A wide range of additional accessories are available.

Key Parameters Category Description / Value Product Line Eaton NZM3 Model / Frame Size NZM3-XKS Release Type Fixed Thermal-Magnetic (Non-adjustable) Rated Current (Iₙ) 185 A (Fixed value) Poles 3-Pole & 4-Pole versions are commonly available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 690 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Typically 50 kA at 400V AC (IEC 60947-2). The exact value should be verified from the technical data sheet. Release Characteristics Thermal (Long Delay): For overload protection. Magnetic (Instantaneous): For short-circuit protection. Both are factory-set and non-adjustable. Standards Compliance IEC/EN 60947-2 Mounting Fixed Mounting (for bolted installation in panels). Connection Screw terminals. Auxiliary Contacts & Accessories Compatible with a range of NZM3 accessories, such as auxiliary contacts, undervoltage release, and shunt trip.

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 series breakers of specific frame sizes. Function Shunt Trip Release (for remote opening) Rated Control Supply Voltage (Us) The "PK" suffix commonly indicates a standard voltage of 230V AC. However, the exact voltage must be confirmed by the order code sticker on the device itself, as other voltages (e.g., 24V DC, 110V AC, 400V AC) are available. Mounting Mounts directly onto the compatible NZM3 breaker.

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 series breakers of the specified frame size (Frame 4). Function Undervoltage Release (UVR) Rated Control Supply Voltage (Us) A common standard voltage is 400V AC, 50/60 Hz. However, the exact voltage must be confirmed by the order code sticker on the device itself, as other voltages (e.g., 230V AC, 110V AC) are available. Mounting Mounts directly onto the compatible NZM3 breaker. Operation The breaker can only be closed when the supply voltage is present and above the trip threshold. It automatically trips when the voltage drops below the threshold or is lost.
