Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM650 Rated Operational Current (Iₑ) at AC-3 650 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 355 kW / 480 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 800 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC, 50/60Hz. However, this is a configurable parameter. The coil is available in a wide range of AC and DC voltages. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads Electrical Durability Hundreds of thousands of operations (dependent on load) Mechanical Durability Millions of operations Arc Extinction System Heavy-duty arc chute (as indicated by "XH") Standard Auxiliary Contacts Included as per the "B" configuration (e.g., typically multiple NO and NC contacts). Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals or busbar connections for main power.

Key Parameters Category Description / Value Product Line Eaton NZMH (Air Circuit Breakers) Series / Frame Size NZMH4-AE Rated Current (Iₙ) 630 A (Fixed rating) Poles 3-Pole & 4-Pole versions are available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) High, typically 85 kA to 100 kA at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Trip Unit Type Standard "AS" Trip Unit • Provides fixed or semi-adjustable protection functions (overload and short-circuit). Operation Mechanism Manual stored-energy spring mechanism (allows for quick ON/OFF operation). Mounting Fixed Mounting (for bolted installation in switchgear panels). Standards Compliance IEC/EN 60947-2 Connection Primary power connections via busbars or large cable lugs. Standard Accessories The "AS" version typically includes basic indicators and possibly some built-in auxiliary contacts. A wide range of additional accessories are available, such as: • Additional Auxiliary Contacts • Undervoltage Release (UV) • Shunt Trip (ST) • Motor Operation Mechanism (for electrical closing) • Mechanical interlocks

Key Parameters Category Description / Value Product Line Eaton NZMH (Air Circuit Breakers) Series / Frame Size NZMH4-AE Rated Current (Iₙ) 1600 A (Fixed rating) Poles 3-Pole & 4-Pole versions are available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Very high, typically 85 kA to 100 kA at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Trip Unit Type Fixed "AS" Trip Unit • Provides standard non-adjustable or semi-adjustable protection functions (overload and short-circuit). Operation Mechanism Manual stored-energy spring mechanism (allows for quick ON/OFF operation independent of handling speed). Mounting Fixed Mounting (designed for bolted installation in switchgear panels). Standards Compliance IEC/EN 60947-2 Connection Primary power connections are typically made via busbars or large cable lugs bolted to the terminal pads. Standard Accessories The "AS" version typically comes with a basic set of indicators and possibly a few built-in auxiliary contacts. A wide range of additional accessories are available, such as: • Additional Auxiliary Contacts • Undervoltage Release (UV) • Shunt Trip (ST) • Motor Operation Mechanism (for electrical closing) • Mechanical interlocks

Key Parameters Category Description / Value Product Line Eaton NZMH (Air Circuit Breakers) Series / Frame Size NZMH4-AE Rated Current (Iₙ) 1250 A (Fixed rating) Poles 3-Pole & 4-Pole versions are available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Very high, typically 85 kA to 100 kA at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Trip Unit Type Fixed "AS" Trip Unit • Provides standard non-adjustable or semi-adjustable protection functions (overload and short-circuit). Operation Mechanism Manual stored-energy spring mechanism (allows for quick ON/OFF operation independent of handling speed). Mounting Fixed Mounting (designed for bolted installation in switchgear panels). Standards Compliance IEC/EN 60947-2 Connection Primary power connections are typically made via busbars or large cable lugs bolted to the terminal pads. Standard Accessories The "AS" version typically comes with a basic set of indicators and possibly a few built-in auxiliary contacts. A wide range of additional accessories are available, such as: • Additional Auxiliary Contacts • Undervoltage Release (UV) • Shunt Trip (ST) • Motor Operation Mechanism (for electrical closing) • Mechanical interlocks

Key Parameters Category Description / Value Product Line Eaton DILM Model Type DILM15-10C Rated Operational Current (Iₑ) at AC-3 9 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 4 kW / 5.5 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 16 A Poles 3 (Main Contacts) Coil Control Voltage 24 V DC (As specified by the "DC24V" designation. The "-10C" suffix is consistent with this DC voltage rating). Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads (e.g., heaters) Electrical Durability Millions of operations (dependent on load) Mechanical Durability ~ 10 - 15 million operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Snap-on mounting on 35 mm symmetrical top-hat rail (DIN rail) or via screw mounting using the integrated feet. Connection Cage Clamp terminal technology for easy wiring without tools. Auxiliary Contacts Typically, at least 1 normally open (NO) auxiliary contact is included as standard and can be mounted on the front. Additional auxiliary contact blocks (e.g., DILE...), mechanical interlocks, and timer modules are available as accessories.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM300A Rated Operational Current (Iₑ) at AC-3 300 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 160 kW / 220 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 410 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V AC, 50/60Hz. However, this is a configurable parameter. The coil is available in a wide range of AC and DC voltages (e.g., 24V, 110V, 230V, 400V, 500V). The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads Electrical Durability Hundreds of thousands of operations (dependent on load) Mechanical Durability Millions of operations Arc Extinction System Sintered metal arc chute (as indicated by "S") Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections and cage clamp terminals for auxiliary contacts and coil.

Key Parameters Category Description / Value Product Line Eaton DILM Model Type DILM17-01C Rated Operational Current (Iₑ) at AC-3 12 A (For squirrel-cage motors: Starting, switching off during running) Rated Operational Power at AC-3 ~ 5.5 kW / 7.5 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 25 A Poles 3 (Main Contacts) Coil Control Voltage DC - The specific voltage is indicated by the "-01C" suffix. Typically 24V DC, but other DC voltages (e.g., 48V, 110V, 220V DC) may be available under different order codes. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running) AC-1: Non-inductive or slightly inductive loads (e.g., heaters) Electrical Durability Millions of operations (dependent on load) Mechanical Durability ~ 10 - 15 million operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Snap-on mounting on 35 mm symmetrical top-hat rail (DIN rail) or via screw mounting using the integrated feet. Connection Cage Clamp terminal technology for easy wiring without tools. Auxiliary Contacts Typically, at least 1 normally open (NO) auxiliary contact is included as standard and can be mounted on the front. Additional auxiliary contact blocks (e.g., DILE...), mechanical interlocks, and timer modules are available as accessories.

Key Parameters Category Description / Value Product Line Eaton NZM3 Model / Frame Size NZM3-XKS Release Type Fixed Thermal-Magnetic (Standard "A" Release) • Non-adjustable overload and short-circuit protection. Rated Current (Iₙ) 125 A (This is a fixed value for this specific variant, e.g., NZM3-XKSA 125). The XKS frame typically covers ratings from 80A up to 125A. Poles 3-Pole & 4-Pole versions are commonly available. Rated Operational Voltage (Uₑ) 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 690 V AC Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Typically 50 kA at 400V AC (IEC 60947-2). The exact value should be verified from the technical data sheet. Release Characteristics Thermal (Long Delay): For overload protection. Magnetic (Instantaneous): For short-circuit protection. Both are factory-set and non-adjustable. Standards Compliance IEC/EN 60947-2 Connection Standard screw terminals. Mounting Fixed Mounting (for bolted direct installation in panels). Auxiliary Contacts & Accessories Compatible with a range of NZM3 accessories, which can be added on, such as: • Auxiliary Contacts (OF, SD) • Undervoltage Release (UV) • Shunt Trip (ST) • Rotary Handle Operator (for door mounting) • Padlockable Handle Locks

Key Parameters Category Description / Value Product Line Eaton NZM3 Model / Frame Size NZM3-XK Release Type Fixed Thermal-Magnetic (Standard "A" Release) • Non-adjustable overload and short-circuit protection. Rated Current (Iₙ) 63 A (This is a common fixed rating for the NZM3-XKA2 variant. Other ratings like 16A, 25A, 40A may exist). Poles 2-Pole (as indicated by the "2" in the model number) Rated Operational Voltage (Uₑ) 500 V / 690 V AC Rated Insulation Voltage (Uᵢ) 690 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Typically 35 kA to 50 kA at 400V AC (IEC 60947-2). The exact value must be verified from the datasheet for the specific current rating. Release Characteristics Thermal (Long Delay): For overload protection. Magnetic (Instantaneous): For short-circuit protection. Both are factory-set and non-adjustable. Standards Compliance IEC/EN 60947-2 Connection Screw terminals. Mounting Fixed Mounting (for bolted direct installation in panels). Auxiliary Contacts & Accessories Compatible with a range of NZM3 accessories, which can be added on, such as: • Auxiliary Contacts • Undervoltage Release (UV) • Shunt Trip (ST) • Rotary Handle Operator

Key Parameters Category Description / Value Product Line Eaton ZMN3 Model Type XTVDVR Rated Current (Iₙ) Typically available in a range up to 250A (The exact value is part of the full order code, e.g., ZMN3-XTVDVR 160). Poles 1P, 2P, 3P Rated Operational Voltage (Uₑ) - DC Up to 1000 V DC (The maximum voltage depends on the number of poles). Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) - DC High breaking capacity, e.g., up to 50 kA at specified DC voltages (e.g., 500V DC). The value is voltage-dependent. Release Type Thermal-Magnetic (TMD) • Thermal Trip (Long Delay) For overload protection. • Magnetic Trip (Instantaneous) For short-circuit protection. Integrated Accessories (as indicated by "VR") V = Undervoltage Release (UV) R = Shunt Trip (ST) This means the breaker comes from the factory with both these modules installed. Standards Compliance IEC/EN 60947-2 Connection Screw terminals. Mounting Fixed mounting in panel.
