Parameter Specification Product Model M22-CK01 Product Line Eaton M22 Series Accessories Product Type Control Knob Compatibility M22 series rotary devices (e.g., selector switches, potentiometers) Shaft Hole Diameter 6 mm (standard for M22 series) Material Thermoplastic (e.g., PA66) Color Black (typical) Mounting Press-fit onto shaft Operating Temperature -25°C to 85°C

Parameter Specification Product Model A22-RWK3R Product Line Eaton A22 Series Actuator Type Mushroom head, red Contact Configuration 1 NC (Normally Closed) (typical for E-stop function) Rated Operational Current 5 A at 250 V AC Voltage Rating Up to 250 V AC Illumination Voltage e.g., 24 V DC, 120 V AC (requires separate lamp/LED module) Mounting Hole Diameter 22.5 mm Protection Rating IP65 (front panel) Terminal Type Screw terminals Operating Temperature -25°C to 55°C Mechanical Life >1 million operations

Parameter Specification Product Model M22-D-G-X1/KC1 Product Line Eaton M22 Series Actuator Type Knob (D), Black Lens Color Green Contact Configuration 1 NO + 1 NC (inferred from KC1) Switch Operation Maintained (latching) Rated Operational Current 4 A at 250 V AC Mounting Hole Diameter 22 mm Protection Rating IP67 Terminal Type Screw terminals Operating Temperature -25°C to 55°C

Parameter Specification Product Model PKE65/AK Product Line Eaton PKE Series UPS Topology Online double-conversion (VFI) Rated Power Capacity 65 kVA / 58.5 kW (at 230 V AC) Input Voltage Range 304–478 V AC (3-phase, auto-sensing) Input Frequency Range 50/60 Hz (auto-sensing) Output Voltage 230/400 V AC (±1% steady state) Output Frequency 50/60 Hz (±0.1% in battery mode) Battery Runtime Configurable (typical 5–30 minutes with external battery modules) Efficiency >96% at full load Communication Interfaces Ethernet, RS-232, USB, dry contacts Form Factor Tower (optional rack-mount kit) Operating Temperature 0–40°C Standards Compliance IEC 62040-3, CE, UL, RoHS

Parameter Specification Product Model K3DG/P 1818069 Product Line Eaton K3DG Series Panel Instruments Display Type Digital LCD or LED Measured Parameters Voltage, current, power, frequency (configurable) Input Types Voltage: 0–600 V AC/DC, Current: 0–5 A AC (via CT) Power Supply 85–265 V AC/DC (typical) Accuracy ±0.5% of reading (typical) Mounting Panel cutout (standard DIN 96x48 mm) Operating Temperature -10°C to 55°C Protection Rating IP65 (front panel) Communication Optional RS-485 Modbus RTU

Parameter Specification Product Model MTL4575 Product Line Eaton MTL4500+ Series Signal Conditioners Function Single-channel signal isolator & converter Input Signal 4-20 mA Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Accuracy ±0.1% of span Line Fault Detection Configurable for open/short circuit indication Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C Compliance & Certifications CE, ATEX (for non-hazardous areas)

Parameter Specification Product Model MTL1143 Product Line Eaton MTL1000 Series Signal Conditioners Function Single-channel signal isolator & converter Input Signal 4-20 mA Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Accuracy ±0.1% of span Line Fault Detection Configurable for open/short circuit indication Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C Compliance & Certifications CE, ATEX (for non-hazardous areas)

Parameter Specification Product Model MTL4531 Product Line Eaton MTL4500+ Series Signal Conditioners Function Single-channel signal isolator & conditioner Input Signal 4-20 mA Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Accuracy ±0.1% of span Line Fault Detection Configurable for open/short circuit indication Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C Compliance & Certifications CE, ATEX, IECEx (for industrial environments)

Parameter Specification Product Model E57LAL12T110E M12NPN Product Line Eaton E57 Series Proximity Sensors Housing Diameter 12 mm Sensing Distance 1.1 mm (nominal) Detection Object Ferrous metals (e.g., steel) Output Type NPN (sinking), NO Supply Voltage 10–30 V DC Current Rating ≤200 mA Switching Frequency 1 kHz (typical) Connection M12 4-pin connector Protection Rating IP67 Housing Material Nickel-plated brass Operating Temperature -25°C to 70°C

Parameter Specification Product Model FWP-400C Product Line Eaton FWP Series Molded Case Circuit Breakers Rated Current 400 A Number of Poles 3 Poles Rated Voltage 600 V AC (50/60 Hz) Breaking Capacity 25 kA (at 480 V AC, per UL 489) Trip Unit Thermal-magnetic Mounting Fixed (panelboard installation) Operating Temperature -25°C to 70°C Standards Compliance UL 489, IEC 60947-2
