Parameter Specification Product Model T0-2-1/I1/SVB-SW Product Line Eaton T0 Series Contactors Rated Operational Current ~25 A (at AC-3, 400 V) Rated Operational Voltage 690 V AC Number of Main Poles 2 Poles Coil Voltage 400-415 V AC, 50/60 Hz Auxiliary Contacts 1 NO Mounting Style Base mounting with screw terminals (SVB) Electrical Life >1 million operations (at rated load) Mechanical Life >10 million operations Standards Compliance IEC 60947-4-1, UL 508

Parameter Specification Product Model MTL4541B Product Line Eaton MTL4500+ Series Signal Conditioners Function Single-channel signal isolator & conditioner Input Signal 4-20 mA Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Accuracy ±0.1% of span Line Fault Detection Configurable for open/short circuit indication Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C Compliance & Certifications CE, ATEX, IECEx (for industrial environments)

Parameter Specification Product Model DILMP63 Product Line Eaton DILM Series Contactors Rated Operational Current 63 A (at AC-3, 400 V) Rated Operational Voltage 690 V AC Number of Poles 3 Poles Coil Voltage Multiple options (e.g., 24 V DC, 230 V AC) Auxiliary Contacts Configurable (e.g., 1 NO + 1 NC) Electrical Life >1 million cycles (at rated load) Mechanical Life >10 million cycles Mounting DIN-rail or screw mounting Protection Rating IP20 (terminal cover optional for higher protection) Standards Compliance IEC 60947-4-1, UL 508

Parameter Specification Product Model SL-L-G Product Line Eaton SL Series Signal Towers Lens Color Green Voltage Options 24 V DC, 120 V AC, 230 V AC (depends on lamp/LED module) Lens Material Polycarbonate (impact-resistant) Mounting Stackable modular design (integrates with SL base unit) Protection Rating IP65 (dust-tight and water-resistant) Housing Material Thermoplastic (e.g., PC/ABS) Operating Temperature -25°C to 55°C Compatibility Compatible with SL series base units and accessories

Parameter Specification Product Model PKZMC-16 XTPR016BC1C Product Line Eaton PKZ Series Motor Protection Circuit Breakers Rated Current 16 A Rated Operational Voltage 690 V AC Number of Poles 3 Poles Trip Unit Type Thermal-magnetic (motor protection characteristics) Breaking Capacity 100 kA (at 400 V AC, IEC 60947-2) Overload Protection Adjustable (via trip unit setting) Short-Circuit Protection Magnetic instant trip Mounting DIN-rail (35 mm) Standards Compliance IEC 60947-2, UL 508, CSA

Parameter Specification Product Model 15100AQD07 Product Series Eaton Heavy-Duty Limit Switch Actuator Type Rotating Lever Arm (inferred from QD07) Contact Configuration 1 NO (Normally Open) (inferred from QD07) Rated Operational Current 10 A at 600 V AC Electrical Life >1 million operations (at rated load) Mechanical Life >10 million operations Enclosure Rating NEMA 4, 4X, 6P, 13; IP67 Housing Material Zinc die cast Terminal Type Screw terminals Operating Temperature -20°C to 120°C Standards Compliance UL, cULus, CE

Parameter Specification Product Model LS-02-ZB Product Type Inductive Proximity Sensor Sensing Distance 2 mm (nominal) Detection Object Ferrous metals (e.g., steel) Output Type DC 3-wire (typically PNP or NPN) Supply Voltage 10–30 V DC Current Rating ≤200 mA Switching Frequency 500 Hz Housing Material Nickel-plated brass Connection Type Pre-wired cable (2 m standard) Protection Rating IP67 Operating Temperature -25°C to 70°C

Parameter Specification Product Model PKM0-10 Product Line Eaton PKM0 Series UPS Topology Online double-conversion (VFI) Rated Power Capacity 10 kVA / 9 kW (at 230 V AC) Input Voltage Range 160–276 V AC (auto-sensing) Input Frequency Range 50/60 Hz (auto-sensing) Output Voltage 230 V AC (±1% steady state) Output Frequency 50/60 Hz (±0.5% in battery mode) Battery Runtime Configurable (typical 5–30 minutes with external battery packs) Efficiency >94% at full load Communication Interfaces Ethernet, RS-232, USB, dry contacts Form Factor Tower or rack-mountable (2U with kit) Operating Temperature 0–40°C Standards Compliance IEC 62040-3, CE, UL, RoHS

Parameter Specification Product Model M22-I2 Product Line Eaton M22 Series Product Type Indicator Light (Visual Signaling) Lens Color Red (inferred from I2) Mounting Hole Diameter 22 mm Voltage Options e.g., 24 V DC, 120 V AC (requires separate lamp holder/LED module) Protection Rating IP67 (dust-tight and waterproof) Lens Material Polycarbonate (typical) Housing Material Thermoplastic (e.g., PA66) Terminal Type Screw terminals or spring-cage Operating Temperature -25°C to +55°C

Parameter Specification Product Model M22-I4 Product Line Eaton M22 Series Product Type Indicator Light (Visual Signaling) Lens Color Green (inferred from I4) Mounting Hole Diameter 22 mm Voltage Options e.g., 24 V DC, 120 V AC (requires separate lamp holder/LED module) Protection Rating IP67 (dust-tight and waterproof) Lens Material Polycarbonate (typical) Housing Material Thermoplastic (e.g., PA66) Terminal Type Screw terminals or spring-cage Operating Temperature -25°C to +55°C
