Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At rated pressure Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Response Time < 30 ms Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C

Technical Parameters Parameter Value Notes Displacement 141 cm³/rev 8.61 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Control Response Time < 40 ms 10-90% stroke Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (clockwise) Weight Approx. 48 kg (106 lb) Length ~325 mm (12.8 in) Width ~235 mm (9.3 in) Performance Data Parameter Value Theoretical Flow at 1800 rpm 253.8 L/min (67.0 US gpm) Actual Flow at 1800 rpm ≈ 246 L/min (65.0 US gpm) Input Power at 250 bar 106 kW (142 hp) Input Power at 280 bar 118 kW (158 hp) Noise Level < 80 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Electronic Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 1.8A maximum Hysteresis < 1.5% Linearity < 2% Repeatability < 0.5% Protection Rating IP65

Technical Parameters Parameter Value Notes Displacement 180 cm³/rev 10.98 in³/rev Maximum Operating Pressure 420 bar 6,090 psi (continuous) Rated Pressure 350 bar 5,075 psi Peak Pressure 450 bar 6,525 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2200 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Mechanical Efficiency ≥ 95% At rated conditions DF Control System Characteristics Electro-Hydraulic Proportional Control: Precise electronic displacement control Pressure Compensation: Automatic pressure regulation Flow Control: Proportional flow matching to system demand Load Sensing Compatibility: System pressure demand sensing Power Control: Horsepower limitation capability Multiple Control Modes: Programmable operating modes Physical Specifications Parameter Specification Electrical Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 2.0A maximum Response Time < 35 ms Hysteresis < 1.5% Linearity < 2% Protection Rating IP66 Shaft Type SAE Standard (19 mm) Mounting SAE 2-bolt type "D" Port Size SAE 1-1/2" (No. 16) Rotation Right-hand (clockwise) Weight Approx. 65 kg (143 lb) Length ~350 mm (13.8 in) Width ~280 mm (11.0 in)

Technical Parameters Parameter Value Notes Displacement 90 cm³/rev 5.49 in³/rev Maximum Operating Pressure 420 bar 6,090 psi (continuous) Rated Pressure 350 bar 5,075 psi Peak Pressure 450 bar 6,525 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 600 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions DF Control Characteristics Electro-Hydraulic Proportional: Precise electronic control of pump displacement Pressure Compensation: Automatic pressure control capability Flow Control: Proportional flow regulation Load Sensing: Optional system optimization Multiple Control Modes: Pressure, flow, power control Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Electrical Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 1.5A maximum Response Time < 30 ms Hysteresis < 1.5% Protection Rating IP65 Rotation Right-hand (clockwise) Weight Approx. 38 kg (83.8 lb) Length ~285 mm (11.2 in) Width ~220 mm (8.7 in)

Technical Parameters Parameter Value Notes Displacement 74 cm³/rev 4.52 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 700 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Mechanical Efficiency ≥ 94% At rated conditions

Technical Parameters Parameter Value Notes Maximum Operating Pressure 25 bar 362 psi (standard) Burst Pressure 75 bar 1,088 psi Rated Flow Capacity 75 L/min 19.8 US gpm Port Size 1-1/2" SAE Straight thread O-ring Filter Rating 10 micron Absolute (β₁₀≥75) Bypass Setting 2.1 bar 30 psi (±0.35 bar) Element Material Glass fiber Composite media Housing Material Steel Powder coated

Technical Parameters Parameter Value Notes Displacement 57 cm³/rev 3.48 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 800 rpm For proper lubrication Volumetric Efficiency ≥ 95% At rated conditions Overall Efficiency ≥ 90% At rated conditions Mechanical Efficiency ≥ 93% At rated conditions Available Control Options Pressure Compensation (Standard) Load Sensing (LS) Pressure-Flow Compensation (QIC) Electro-Proportional Controls Hydraulic Remote Controls Torque Limiting Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 3/4" (No. 8) Rotation Right-hand (standard) Weight Approx. 22 kg (48.5 lb) Length ~245 mm (9.6 in) Width ~185 mm (7.3 in) Performance Data Parameter Value Theoretical Flow at 1800 rpm 102.6 L/min (27.1 US gpm) Actual Flow at 1800 rpm ≈ 97.5 L/min (25.8 US gpm) Input Power at 250 bar 42.8 kW (57.4 hp) Input Power at 280 bar 47.9 kW (64.2 hp) Noise Level < 74 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Standard Control Ranges Parameter Adjustment Range Pressure Setting 50-250 bar Flow Setting 0-100% of maximum flow Response Time < 60 ms typical Hysteresis < 3%

Technical Parameters Parameter Value Notes Displacement 141 cm³/rev 8.61 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Mechanical Efficiency ≥ 95% At rated conditions Available Control Options Pressure Compensation (Standard) Load Sensing (LS) Pressure-Flow Compensation (QIC) Electro-Proportional Controls Hydraulic Remote Controls Torque Limiting Power Control Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (standard) Weight Approx. 48 kg (106 lb) Length ~325 mm (12.8 in) Width ~235 mm (9.3 in)

Technical Parameters Parameter Value Notes Displacement 131 cm³/rev 7.99 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Mechanical Efficiency ≥ 95% At rated conditions Available Control Options Pressure Compensation (Standard) Load Sensing (LS) Pressure-Flow Compensation (QIC) Electro-Proportional Controls Hydraulic Remote Controls Torque Limiting Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (standard) Weight Approx. 42 kg (92.6 lb) Length ~298 mm (11.7 in) Width ~215 mm (8.5 in) Performance Data Parameter Value Theoretical Flow at 1800 rpm 235.8 L/min (62.3 US gpm) Actual Flow at 1800 rpm ≈ 226 L/min (59.7 US gpm) Input Power at 250 bar 98 kW (131 hp) Input Power at 280 bar 110 kW (147 hp) Noise Level < 78 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Standard Control Ranges Parameter Adjustment Range Pressure Setting 50-250 bar Flow Setting 0-100% of maximum flow Response Time < 45 ms typical Hysteresis < 3%

Technical Parameters Parameter Value Notes Displacement 98 cm³/rev 5.98 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 600 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Available Control Options Pressure Compensator (Standard) Load Sensing (Optional) Pressure-Flow Compensator (QIC) Electro-Proportional Controls (Various) Hydraulic Remote Controls Physical Specifications Parameter Specification Shaft Type Standard SAE Mounting SAE 2-bolt type "C" Port Size SAE No. 10 Rotation Right-hand (standard) Weight Approx. 32 kg (70.5 lb) Performance Data Parameter Value Theoretical Flow at 1800 rpm 176.4 L/min (46.6 US gpm) Actual Flow at 1800 rpm ≈ 169 L/min (44.6 US gpm) Input Power at 250 bar 73.5 kW (98.6 hp) Noise Level < 76 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s
