Technical Parameters Parameter Value Notes Nominal Size 16 Standard Interface Dimension Rated Flow 18 L/min 4.75 US gpm Maximum Operating Pressure 350 bar 5,075 psi Case Drain Pressure 25 bar max 360 psi maximum Control Voltage 24V DC Proportional PWM Signal Spool Configuration 3-position, 4-way Spring-centered to neutral Hysteresis < 2.5% Typical Value Repeatability < 0.8% Typical Value Linearity < 3% Full stroke Electrical Specifications Parameter Specification Voltage Range 20-30V DC Current Consumption 1.2-2.0A (Typical) Duty Cycle 100% Protection Rating IP66 (Solenoid) Electrical Connection ISO 4400 Standard Feedback Signal 0-10V DC or 4-20mA (S2 option) S2 Option Enhanced Features Position Feedback: Spool position monitoring capability Diagnostic Capabilities: Enhanced system monitoring Closed-loop Ready: Compatible with closed-loop control systems Fault Detection: Advanced error detection and reporting Hydraulic Performance Parameter Specification Minimum Controlled Flow 1.0 L/min Pressure Drop at Rated Flow 10 bar (Typical) Internal Leakage < 80 mL/min Response Time < 40 ms (10-90% stroke) Frequency Response > 15 Hz at -3dB

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 2-position, 4-way Closed Center Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At Rated Pressure Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Response Time < 30 ms Connection Type ISO 4400 Manual Override Features (X6) Type: Mechanical push-button or rotary Operation: Independent of electrical power Position Indication: Visual status display Reset: Automatic or manual depending on configuration Force Required: 30-50 N typical Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Fluid Viscosity Range 10-100 mm²/s

Technical Parameters Parameter Value Notes Maximum Operating Pressure 250 bar 3,625 psi Rated Flow Capacity 30 L/min 7.9 US gpm Port Size 1/2" NPTF Standard Mobile Connections Spool Configuration 3-position, 4-way Spring-centered Actuation Type Mechanical Lever Manual Control Work Port Relief Adjustable (Both Spools) BW Spool Feature Internal Leakage < 40 mL/min At Rated Pressure Weight 3.5 kg 7.7 lb Mechanical Specifications Parameter Specification Actuation Force 25-45 N per lever Lever Travel 30-40° total Spool Type Sliding spool with metering notches Mounting Stackable modular design Enclosure Rating IP65 (Dust and water resistant) Hydraulic Performance Parameter Specification Pressure Drop at Rated Flow < 6 bar Response Time Immediate mechanical response Load Sensitivity Good load independence Metering Characteristics Excellent low-speed control Flow Range 2-30 L/min Installation Specifications Parameter Specification Mounting Pattern Standard DGMX2 interface Port Locations Side or bottom configuration Stacking Capability Multiple sections compatible Manifold Material Aluminum alloy Installation Torque 40-45 Nm

Technical Parameters Parameter Value Notes Maximum Operating Pressure 250 bar 3,625 psi Rated Flow Capacity 30 L/min 7.9 US gpm Port Size 1/2" NPTF Standard Mobile Connections Spool Configuration 3-position, 4-way Spring-centered Actuation Type Mechanical Lever Manual Control Work Port Relief Adjustable AW Spool Feature Internal Leakage < 40 mL/min At Rated Pressure

Technical Parameters Parameter Value Notes Nominal Size 16 Standard Interface Dimension Rated Flow 6 L/min 1.6 US gpm Maximum Operating Pressure 350 bar 5,075 psi Control Voltage 24V DC Proportional PWM Signal Spool Configuration 3-position, 4-way Spring-centered Pilot Pressure 20-25 bar Required for Operation Hysteresis < 3% Typical Value Repeatability < 1% Typical Value Operating Temperature -40°C to +85°C -40°F to +185°F

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Cracking Pressure 0.35 bar 5 psi (Free Flow) Pilot Ratio 3.5:1 Typical Maximum Flow 75 L/min 19.8 US gpm Port Size Cavity ISO 7789 Standard Cartridge Thread Size 11/16-16 UN Standard Installation Torque 95-110 Nm 70-81 lb-ft

Technical Parameters Parameter Value Notes Rated Current 20A Iₙ Rated Voltage 400V AC 50/60Hz Breaking Capacity 36kA Icu at 400V AC Rated Insulation Voltage 690V AC Ui Rated Impulse Voltage 8kV Uimp Number of Poles 3 Standard Tripping Characteristic Electronic S4 Curve Electrical Characteristics Parameter Specification Rated Frequency 50/60 Hz Utilization Category A Electrical Life 5,000 cycles Mechanical Life 20,000 cycles Termination Cable Lug or Bus Bar

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered, tandem center Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At rated pressure Response Time < 30 ms Solenoid actuation Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Coil Resistance 22 Ω ±10% Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Recommended Viscosity 10-100 mm²/s

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 15 L/min 4 US gpm (typical) Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 80 mL/min At rated pressure Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Response Time < 35 ms Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 6 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Fluid Viscosity Range 10-100 mm²/s

Technical Parameters Parameter Value Notes Maximum Operating Pressure 250 bar 3,625 psi Rated Flow Capacity 38 L/min 10 US gpm per section Port Size 3/4" NPTF Standard mobile connections Spool Configuration 3-position, 4-way Spring-centered Actuation Type Mechanical lever Manual control Pressure Rating - Work Ports 250 bar 3,625 psi - Inlet Port 210 bar 3,045 psi Internal Leakage < 30 mL/min At rated pressure Functional Characteristics Dual Spool Design: Independent control of two hydraulic functions Spring-Centered: Automatic return to neutral Parallel Circuit: Allows simultaneous operation Load Holding: Check valve functionality in neutral Manual Lever Control: Mechanical actuation Detent Mechanism: Position holding capability Spool Configuration Details Spool Code Function A Side A2W 3-position, spring-centered with detent B Side B2W 3-position, spring-centered with detent Mechanical Specifications Parameter Specification Actuation Force 30-50 N per lever Lever Travel 35-45° total Detent Force 15-25 N Spool Type Sliding spool Mounting Stackable design Weight Approx. 5.5 kg (12.1 lb)
