Key Features:
Rated Current: 18A (suitable for medium-power motor loads).

Voltage Rating: 230V AC (typical for industrial control circuits).

Protection Functions:

Overload protection (adjustable trip settings).

Short-circuit protection (magnetic or thermal trip).

Phase-loss protection (optional, depending on model).

Control Logic:

Built-in electromechanical relay for switching.

Manual reset or auto-reset options after tripping.

Status Indication:

LED indicators for power, fault, and relay status.

Mounting & Wiring:

DIN rail-mounted for easy installation.

Screw terminals for secure connections.

Compliance & Safety:

Meets IEC/EN 60947-4-1 standards for motor starters.

UL & CE certified for global use.

Key Features:
✔ Energy Savings:

Built-in ABB’s Energy Optimizer reduces motor energy consumption.

Automatic motor adaptation (AMA) for optimal efficiency.

✔ Motor Protection & Safety:

Overload, overvoltage, undervoltage, short-circuit, and ground fault protection.

Thermal motor protection (PTC input for motor temp monitoring).

✔ User-Friendly Interface:

Built-in keypad for easy parameter setting.

LED display for real-time monitoring (speed, current, fault codes).

Optional control panel (ACP10 or ACP7).

✔ Flexible Control Options:

Analog (0-10V, 4-20mA), digital (24V DC), and relay I/O.

Modbus RTU (RS485) & BACnet MS/TP for building automation.

Optional fieldbus cards (Profibus, CANopen, Ethernet/IP).

✔ Application-Specific Features:

Pump & Fan Control: Built-in PID controller for flow/pressure regulation.

Industrial Automation: Multi-motor control, flying start, and brake chopper support.

Key Specifications:

Model: ACS510-01-290A-4

Rated Power: 160kW (215HP)

Output Current: 290A

Input Voltage: 3-phase 380-480V AC ±10%

Frequency Range: 50/60Hz ±5%

Output Frequency Range: 0-500Hz

Control Methods:

Scalar control (V/f)

Sensorless vector control

Efficiency: >97.5%

Protection Class: IP21 (standard)

Advanced Features:

Energy Optimization:

Automatic Energy Optimization (AEO) function

Sleep mode for pump applications

Motor Protection:

Built-in motor thermal protection

Short circuit, ground fault and overload protection

Under/over voltage protection

Control Options:

Built-in PID controller

Flying start and DC braking

Torque boost capability

Communication Protocols:

Standard RS485 interface

Modbus RTU protocol

Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen)

Key Specifications
Parameter Specification
Model ACS550-01-180A-4
Rated Power 90 kW (120 HP)
Output Current 180 A
Input Voltage 3-phase, 380-480V AC (±10%), 50/60 Hz
Output Voltage 0-480V AC (matches input)
Frequency Range 0-500 Hz
Control Method Scalar (V/f) & Sensorless Vector Control (SVC)
Overload Capacity 150% for 60 sec, 200% for 3 sec
Efficiency >98%
Protection Class IP21 (open chassis)
3. Key Features
✔ Motor Control & Performance

Sensorless Vector Control (SVC) for improved torque & speed accuracy

Automatic Motor Adaptation (AMA) for optimal motor tuning

Flying Start – can restart a spinning motor without stopping

Torque Boost for high-starting torque applications

✔ Energy Saving & Optimization

ABB Energy Optimizer reduces motor energy consumption by up to 30%

Sleep Mode for pump & fan applications (reduces idle power waste)

Brake Chopper support (for dynamic braking)

✔ Protection & Safety

Short-circuit, overload, overvoltage, and ground fault protection

Motor Thermal Protection (PTC input)

Safe Torque Off (STO) option (safety compliance)

✔ User Interface & Programming

Built-in keypad (LCD display)

Quick Setup Macro (pre-configured for pumps, fans, conveyors)

CopyCat function (easy parameter transfer between drives)

✔ Communication & Connectivity

Standard RS485 (Modbus RTU)

Optional fieldbus cards (Profibus DP, DeviceNet, CANopen, Ethernet/IP)

BACnet MS/TP for HVAC applications

Key Technical Specifications

Model Number: ACS510-01-290A-4

Rated Power: 160kW (215HP)

Output Current: 290A

Input Voltage: 3-phase 380-480V AC ±10%

Frequency Range: 50/60Hz ±5%

Output Frequency: 0-500Hz

Control Methods:

Scalar control (V/f)

Sensorless vector control

Overload Capacity: 150% for 60 seconds

Efficiency: >97.5%

Protection Class: IP21 (standard)

3. Advanced Features

Energy Saving Functions:

Automatic Energy Optimizer (AEO)

Sleep mode for pump applications

Adaptive programming for optimal efficiency

Motor Protection:

Built-in motor thermal protection

Short circuit protection (I²t)

Ground fault monitoring

Under/over voltage protection

Control Capabilities:

Built-in PID controller

Flying start function

Torque boost (0-30%)

DC braking

4. Communication & Connectivity

Standard RS485 interface

Modbus RTU protocol support

Optional fieldbus adapters available:

Profibus DP

DeviceNet

CANopen

5. Physical Characteristics

Dimensions: 482 × 350 × 262 mm (W×H×D)

Weight: Approximately 45kg

Cooling Method: Forced air cooling

Ambient Temperature Range: -15°C to +50°C

Relative Humidity: <95% non-condensing

Installation: DIN rail or panel mounting7. Certifications & Compliance

CE marked

UL listed

cULus certified

Complies with EN/IEC 61800-3

RoHS compliant

8. Ordering Information

Complete model designation: ACS510-01-290A-4

Standard delivery includes:

Drive unit

Installation guide

Basic control cables

Optional accessories:

External EMC filter

Braking resistor unit

Fieldbus communication modules

Remote control panel

Key Specifications

Model: ACS510-01-031A-4

Rated Power: 15kW (20HP)

Output Current: 31A

Input Voltage: 3-phase 380-480V AC ±10%

Frequency Range: 50/60Hz ±5%

Output Frequency: 0-500Hz

Control Methods:

Scalar (V/f) control

Sensorless vector control

Overload Capacity: 150% for 60 seconds

Efficiency: >97%

Protection Class: IP21 (standard)

3. Key Features

Energy Optimization:

Automatic Energy Optimizer (AEO)

Sleep mode function

Adaptive control algorithms

Motor Protection:

Motor thermal protection

Short circuit protection

Ground fault monitoring

Overvoltage/undervoltage protection

Control Functions:

Built-in PID controller

Flying start capability

Torque boost (0-30%)

DC braking

4. Communication Interfaces

Standard RS485 port

Modbus RTU protocol

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

5. Physical Characteristics

Dimensions: 198 × 195 × 190 mm (W×H×D)

Weight: 3.5kg

Cooling: Forced air cooling

Ambient Temperature: -15°C to +50°C

Humidity: <95% non-condensing

Mounting: DIN rail or panel mount

Key Specifications

Model Number: ACS550-01-031A-4

Rated Power: 15kW (20HP)

Output Current: 31A

Input Voltage: 3-phase 380-480V AC (±10%)

Frequency Range: 50/60Hz ±5%

Output Frequency: 0-500Hz

Control Methods:

Scalar (V/f) control

Sensorless Vector Control (SVC)

Overload Capacity: 150% for 60 seconds

Efficiency: >97.5%

Protection Class: IP21 (standard)

3. Advanced Features

Motor Control:

Automatic Motor Adaptation (AMA)

Flying Start function

Torque Boost (0-30%)

DC braking

Built-in PID controller

Energy Saving:

ABB Energy Optimizer

Sleep Mode function

Adaptive programming

Protection Features:

Motor thermal protection (PTC input)

Short circuit protection

Ground fault protection

Over/under voltage protection

Safe Torque Off (STO) option

4. Communication & Connectivity

Standard RS485 interface

Modbus RTU protocol

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Ethernet/IP

5. Physical Characteristics

Dimensions: 198 × 195 × 190 mm (W×H×D)

Weight: 3.5kg

Cooling Method: Forced air cooling

Ambient Temperature: -15°C to +50°C

Relative Humidity: <95% non-condensing

Installation: DIN rail or panel mounting

.Key Specifications

Model Designation: ACS800-01-0135-3+P901

Rated Power: 75kW (100HP)

Output Current: 135A

Input Voltage: 3-phase 380-500V AC (-15%/+10%)

Frequency Range: 48-63Hz

Output Frequency: 0-300Hz (standard)

Overload Capacity: 1.5× rated current for 60 seconds

3. Technical Features

Advanced Control:

Direct Torque Control (DTC) technology

0.1Hz speed control accuracy without encoder

200% starting torque at 0rpm

Built-in PID controller

System Integration:

Standard P901 control panel with:

Multilingual LCD display

Quick start-up macros

Copy function for parameter transfer

Multiple fieldbus options (PROFIBUS, Modbus, DeviceNet, etc.)

Protection & Safety:

Short circuit protection (I²t)

Motor thermal protection

Ground fault protection

Safe torque-off (STO) functionality

4. Physical Characteristics

Module Dimensions: 350 × 800 × 350mm (W×H×D)

Weight: Approximately 65kg

Cooling Method: Forced air cooling

Enclosure Rating: IP21 (standard)

Ambient Temperature: -15°C to +40°C (with derating above +40°C)

Key Specifications

System Configuration: Multi-drive cabinet solution

Input Voltage: 480V AC 3-phase (±10%)

Input Current: 770A

Power Range: Typically 400-600HP (exact rating depends on configuration)

Frequency Range: 48-63Hz input / 0-300Hz output

Control Technology: Direct Torque Control (DTC)

Efficiency: >98% at full load

3. Technical Features

Advanced Motor Control:

ABB's proprietary Direct Torque Control technology

±0.1% speed accuracy without encoder

200% starting torque capability

Built-in motor thermal protection

System Architecture:

Common DC bus configuration

Includes line-side converter unit

Intelligent cooling system

Pre-configured power cabinet

Protection & Safety:

Short-circuit protection

Ground fault monitoring

Overvoltage/undervoltage protection

Safe torque-off functionality (STO)

4. Physical Characteristics

Cabinet Dimensions: Customizable (typically 2000+ mm height)

Weight: Approximately 800-1200kg (depending on configuration)

Cooling Method: Forced air or liquid cooling options

Enclosure Rating: Typically IP21 or IP42 (custom options available)

Ambient Temperature: 0°C to +40°C (with derating above +40°C)

5. Control & Communication

Standard control panel included

Multiple fieldbus options:

PROFIBUS DP

Modbus RTU/TCP

DeviceNet

Ethernet/IP

PC interface for configuration and monitoring

Main Drive Unit: ACS800-104-0400-7 (400A capacity)

Control Options:

+C123: Extended encoder module

+C124: Fieldbus adapter (PROFIBUS DP)

+C126: I/O extension module

Protection Options:

+E205: Advanced EMI filter

+E213: Duplex communication module

Monitoring Option: +V991: Condition monitoring module

2. Core Specifications

Model Designation: ACS800-104-0400-7

Rated Current: 400A

Power Range: 250-315kW (335-420HP) @ 400V

Input Voltage: 3-phase 380-500V AC (-15%/+10%)

Control Technology: Direct Torque Control (DTC)

Overload Capacity: 1.5× rated current for 60 sec

3. Option Package Details

+C123: Extended Encoder Module

Supports absolute/inc. encoders

17-bit resolution

Sin/Cos 1Vpp interface

+C124: PROFIBUS DP Adapter

DP-V1 protocol support

12Mbps communication speed

Profile 3.0 compliant

+C126: I/O Extension Module

4 analog inputs (0-10V/4-20mA)

4 relay outputs

8 digital inputs/4 digital outputs

+E205: Advanced EMI Filter

Meets EN 61800-3 C2/C3

Reduces RFI emissions by 20dB

Integrated choke design

+E213: Duplex Communication

Redundant communication paths

Dual-port Ethernet support

<1ms switchover time

+V991: Condition Monitoring

Vibration monitoring

Temperature tracking

Predictive maintenance alerts

4. Performance Features

Motor Control:

±0.1% speed accuracy (with encoder)

200% starting torque

Adaptive motor tuning

System Integration:

Dual-channel safety (STO, SS1)

Web server interface

Energy consumption monitoring

5. Physical Specifications

Cabinet Dimensions: 800×2000×600mm (W×H×D)

Weight: ~450kg (complete system)

Cooling: Forced air (IP21) or liquid cooling options

Ambient Temp: 0°C to +40°C (with derating)
