Key Parameters
Core Drive
Power: 110kW (150HP)

Input: 3-phase 380-500V AC (±10%)

Output Current: 210A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Modules
D150 Control Panel

7" color touchscreen

USB parameter backup

Real-time trending

P901 Brake Chopper

Braking power: 110kW cont.

Peak: 165kW (60s)
Requires external resistor

Performance
Speed accuracy: ±0.1%

Torque accuracy: ±1%

Switching freq.: 1-4kHz

Physical
Dimensions: 800×2200×450mm (W×H×D)

Weight: 220kg

Cooling: Liquid cooling (standard)

IP Rating: IP21

Certifications
CE, UL, cUL

SIL3/PL e

Key Specifications
Power Rating: 11 kW (15 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 25 A

Overload Capacity: 150% for 60 seconds

Control Technology: DTC (Direct Torque Control)

Brake Chopper: Integrated (P901 module)

Switching Frequency: 1-12 kHz (adjustable)

Efficiency: >98%

Main Features
✔ Advanced Motor Control

Sensorless speed control (±0.1% accuracy)

Automatic motor adaptation

Torque control mode (±2% accuracy)

Flying start function

✔ Braking System (P901)

Handles regenerative energy

Requires external brake resistor

LED status indicator

150% braking torque capacity

✔ Application Flexibility

Multiple application macros

Built-in PID controller

Pump and fan control curves

Customizable application programming

✔ Protection Features

Motor thermal protection

Short circuit protection

Ground fault detection

DC bus overvoltage protection

Physical Characteristics
Dimensions: 245 × 482 × 227 mm (W×H×D)

Weight: 12 kg

Enclosure Rating: IP21

Cooling Method: Forced air

Ambient Temperature: 0-40°C (32-104°F)

Key Specifications
Power & Performance
Rated Power: 4 kW (5 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 9.5 A

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Braking Capacity (P901):

Continuous: 4 kW

Peak (60s): 6 kW

Switching Frequency: 1-12 kHz (adjustable)

Efficiency: >98%

Main Features
✔ Advanced Motor Control

DTC technology (±0.1% speed accuracy)

Automatic motor adaptation

Flying start capability

✔ Brake Chopper (P901)

Handles regenerative energy

Requires external brake resistor

LED status indicator

✔ Compact Design

Space-saving IP21 enclosure

Convection cooling (fanless)

Easy wall-mount installation

Key Parameters
Drive Unit
Power: 90kW (125HP)

Input: 3-phase 380-480V AC (±10%)

Output: 180A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Modules
D150 Control Panel

7" color touchscreen

USB parameter backup

Real-time trending

P901 Brake Chopper

Braking power: 90kW cont.

Peak: 135kW (60s)
Requires external resistor

Performance
Speed accuracy: ±0.1%

Torque accuracy: ±1%

Switching freq.: 1-12kHz

Physical
Dimensions: 800×2200×450mm

Weight: 185kg

Cooling: Forced air

IP Rating: IP21

Certifications
CE, UL, cUL

SIL3/PL e

Key Specifications
Power & Performance
Rated Power: 18.5 kW (25 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 38 A

Overload Capacity: 110% continuous

Control Method: Direct Torque Control (DTC)

Efficiency: >98% (IE4 equivalent)

Water Industry Features
✔ Pump-Specific Intelligence

Multi-pump controller (up to 4 pumps)

Dry-run protection with automatic restart

Anti-clogging cycle for wastewater

Leak detection algorithm

✔ Advanced Connectivity

Built-in Modbus RTU & PROFIBUS

IoT-ready with optional cellular module

SCADA integration templates

✔ Robust Protection

Corrosion-resistant (IP66/NEMA 4X)

Enhanced EMC filtering

50°C ambient operation capability

Physical Specifications
Dimensions: 350 × 482 × 227 mm (H×W×D)

Weight: 18 kg

Cooling: Convection (fanless)

Material: Stainless steel screws & coated PCB

Certifications
UL 61800-5-1

CE

cULus

IEC 61800-3 Cat C3

NEMA 4X/12 (optional)

Key Specifications
Parameter Value
Power Rating 15 kW (20 HP)
Input Voltage 3-phase 200-240V AC (±10%)
Output Current 45 A
Overload 110% continuous
Control Method Sensorless Vector Control
THDi <5% (with built-in filter)
HVAC-Specific Features
✔ Smart Control

Automatic energy optimization (saves up to 30%)

Adaptive PID for pressure/flow control

Pump cleaning cycle program

✔ Connectivity

Built-in BACnet MS/TP & Modbus RTU

Cloud monitoring via ABB Ability™

Optional wireless module

✔ Protection

Motor thermal protection (PTC/Pt100)

Surge protection (6kV/3kA)

Condensation prevention

Physical Specs
Dimensions: 245×482×227mm

Weight: 12 kg

Enclosure: IP21 (IP55 kit available)

Ambient Temp: -15°C to +50°C

Certifications
UL 61800-5-1

CE

cULus

EN 61800-3 Cat C2

Key Specifications
Parameter Value
Power Rating 0.75 kW (1 HP)
Input Voltage 3-phase 380-480V AC (±10%)
Output Current 2.4 A
Overload 110% continuous, 150% for 3s
Control Method Scalar (V/f)
Switching Freq. 1-16 kHz (adjustable)
Efficiency >96%
Main Features
✔ HVAC-Optimized Control

Automatic Energy Optimizer

PID controller with sleep/wake

Pump/fan preset curves

✔ Basic Connectivity

RS485 (Modbus RTU)

2 analog inputs (0-10V/4-20mA)

3 digital inputs

✔ Protection

Motor thermal protection

Short-circuit protection

Ground fault detection

Physical Specs
Dimensions: 150×200×165mm

Weight: 1.8 kg

Cooling: Natural convection

IP Rating: IP20

Key Parameters
Core Drive
Power: 7.5kW (10HP)

Input: 3-phase 380-480V AC (±10%)

Output: 18A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Modules
B056 - Basic Control Panel

LCD display

Keypad navigation

E202 - I/O Extension

+2AI (0-10V/4-20mA)

+2DI

+1RO

P901 - Brake Chopper

Braking power: 7.5kW cont.

Requires external resistor

Performance
Speed accuracy: ±0.1%

Switching freq.: 1-12kHz

Physical
Dimensions: 245×482×227mm (W×H×D)

Weight: 12kg

Cooling: Forced air

IP Rating: IP21

Certifications
CE, UL, cUL

Key Specifications
Power & Performance
Rated Power: 11 kW (15 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 25 A

Overload Capacity:

110% continuous

150% for 3 seconds

Control Method: Scalar (V/f) & Sensorless Vector Control

Efficiency: >97%

Switching Frequency: 2-16 kHz (adjustable)

Main Features
1. Motor Control
V/f control with torque boost

Automatic Energy Optimizer

DC braking capability

2. Application Features
3 preset speed settings

Basic PID controller

Customizable acceleration/deceleration

3. Protection & Safety
Motor thermal protection

Short-circuit protection

Ground fault detection

4. Connectivity
Standard:

RS485 (Modbus RTU)

2 analog inputs (0-10V/4-20mA)

3 digital inputs

1 relay output

5. Compact Design
Space-saving IP20 enclosure

Lightweight (7.5 kg)

Fanless cooling

Physical Specifications
Dimensions: 150 × 245 × 195 mm (W×H×D)

Weight: 7.5 kg

Cooling: Convection

Ambient Temperature: 0-40°C (32-104°F)

Key Specifications
Power & Performance
Rated Power: 200 kW (268 HP)

Input Voltage: 3-phase 380-500V AC (±10%), 50/60 Hz

Output Current: 430 A

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Efficiency: >98.5%

Switching Frequency: 1-4 kHz (adjustable)

Main Features
1. Advanced Motor Control
DTC technology for precise speed (±0.1%) and torque (±1%) control

Automatic motor adaptation

Flying start and torque boost functions

2. Robust Design
Heavy-duty power components for 24/7 operation

Coated PCBs for harsh environments

Modular design for easy maintenance

3. Application Flexibility
10 pre-programmed macros

Customizable application programs

Built-in PID controller

4. Protection & Safety
Motor thermal protection (PTC/KTY)

Short-circuit protection (IGBT monitoring)

Ground fault detection

Safe Torque Off (STO)

5. Connectivity
Standard:

RS485 (Modbus RTU)

Ethernet

Optional fieldbus:

PROFIBUS DP

PROFINET

EtherNet/IP

Physical Specifications
Dimensions: 800 × 2200 × 450 mm (W×H×D)

Weight: 185 kg

Enclosure Rating: IP21 (IP54 kit available)

Cooling: Liquid cooling (standard)

Ambient Temperature: 0-40°C (32-104°F)
