Key Specifications & Parameters Parameter Specification / Description Technology Type Multi-stage anti-cavitation and noise reduction trim Design Principle Multi-path, multi-stage pressure control using stacked plates or drilled hole patterns to create sequential pressure drops Noise Reduction Up to 15-20 dBA compared to standard single-stage trim Cavitation Control Manages and contains cavitation within the trim structure to prevent damage to valve components and downstream piping Pressure Drop Capability Suitable for very high pressure drop applications (ΔP > 1000 psi / 69 bar in some configurations) Size Range Typically available for valves from 1" to 12" (DN 25 to DN 300) Compatible Valves Designed for Fisher cage-style globe valves (e.g., ES, ET, easy-e™, GX, and other similar designs) Flow Characteristic Modifiable characteristic through cage design (typically equal percentage or linear) Materials Standard: 316 Stainless Steel Options: Hardened alloys (17-4PH, Stellite) for severely erosive services Leakage Class Dependent on the main valve's seat design (typically Class IV or VI) Temperature Range Limited by the base valve materials, typically -20° to 800°F (-29° to 427°C)

Key Specifications & Parameters Parameter Specification Model Baumann 24003 Little Scotty Valve Type Cage-style Control Valve Sizes 1/2 inch to 2 inches (DN 15 to DN 50) End Connections NPT, ANSI Flanged (150 & 300 lb) Pressure Rating Up to 600 psi (41 bar) depending on size and materials Temperature Range -20° to 450°F (-29° to 232°C) Flow Characteristics Equal percentage or linear Valve Capacity (Cv) 0.3 to 45 (depending on size and trim) Body Materials Carbon steel, stainless steel, bronze Trim Materials Stainless steel, with PTFE soft seat for shutoff Leakage Class ANSI Class IV (metal seat) or Class VI (soft seat) Actuator Options Pneumatic spring-diaphragm or piston actuators

Key Specifications & Parameters Parameter Specification Model Series DVC6200 (Base model), DVC6200S (SIS version), DVC6210 (Foundation Fieldbus), DVC6220 (PROFIBUS PA) Type Digital Valve Controller / Positioner Input Signal Standard: 4-20 mA DC with HART® 7 protocol Digital Options: Foundation Fieldbus H1 (31.25 kbit/s), PROFIBUS PA Output Signal Pneumatic Output: Single or double for single/double-acting actuators Supply Air Range: 1.4 to 10.0 bar (20 to 150 psig) Air Consumption: <0.028 Nm³/h (0.016 SCFM) steady state Flow Capacity Standard: Cv = 0.086 (GP) High Flow: Cv = 0.32 (HF) available Stem Travel Linear: 3 to 150 mm (0.12 to 6.0 in) Rotary: 25° to 100° rotation Performance Linearity: ±0.5% of span Hysteresis: 0.3% of span Sensitivity: 0.05% of span Temperature Operating: -40° to 80°C (-40° to 176°F) Storage: -40° to 85°C (-40° to 185°F) Enclosure Rating: NEMA 4X, Type 4, IP66 Material: Aluminum with polyester coating Communications Local: Infrared with Fisher FIELDVUE DVC6200 PC Software Remote: HART 7, FOUNDATION Fieldbus, PROFIBUS PA Diagnostics Standard Monitoring: • Valve position • Supply pressure • Actuator pressures • Travel accumulation • Alarm conditions Advanced: Performance Analytics, Partial Stroke Testing

Key Specifications & Parameters Parameter Specification / Description Solution Type Engineered isolation package based on Fisher control valve platforms (easy-e™, GX, etc.) Primary Function Ultra-tight shut-off (Isolation) for critical on/off applications Leakage Class ANSI Class VI (bubble-tight) with standard PTFE soft seats Valve Sizes ½ inch to 8 inches (DN 15 to DN 200) Pressure Ratings ANSI Class 150 to 2500, dependent on base valve selection Temperature Range Standard: -20° to 400°F (-29° to 204°C) with PTFE High-temp: Up to 800°F (427°C) with specialized trim Actuator Type Spring-return piston actuator (single/double acting) with high thrust output Digital Controller FIELDVUE DVC Series (DVC6200, DVC6000) with: • HART®/Foundation Fieldbus communication • Partial Stroke Testing (PST) • Continuous performance monitoring • Automated diagnostics Diagnostic Capabilities • Valve signature analysis • Friction monitoring • Spring rate analysis • Seat load verification • Travel accumulation

Key Specifications & Parameters Parameter Specification / Description Model / Type A configured solution based on standard Fisher control valves (e.g., easy-e™, GX, | Primary Function | Ultra-Tight Shut-Off (Isolation) for on/off or start/stop service. Note: It is not designed for throttling or continuous control. | | Sizes | Typically 1/2 inch to 6 inches (DN 15 to DN 150), depending on the base valve selected. | | End Connections | Flanged (ANSI 150, 300), NPT, etc., as per the base valve. | | Pressure Ratings | Dependent on the base valve body rating (e.g., ANSI Class 150, 300, 600). | | Temperature Range | Dependent on the base valve and seat material. Standard PTFE seats are typically suitable for -20° to 400°F (-29° to 204°C). | | Body Materials | Carbon Steel (WCB), Stainless Steel (304, 316), etc., as per the base valve. | | Trim & Seating | Soft Seat: PTFE (Teflon) is standard for achieving ANSI Class VI (bubble-tight) shut-off. Metal Seats: Available for higher temperature services where PTFE is not suitable, though with a higher leakage rate (ANSI Class IV). | | Leakage Class | ANSI Class VI (Standard with PTFE soft seat) | | Actuator | Spring-Return (Fail-Safe) Piston Actuator is standard. This provides the high thrust required for tight shut-off and ensures the valve moves to a safe position (open or closed) upon loss of air supply. | | Digital Controller | FIELDVUE™ DVC Series (e.g., DVC6000, DVC6200) is typically mounted. This provides: - Valve Positioning (for open/close commands). - Diagnostics (monitors valve health and performance). - Partial Stroke Testing (PST): Allows the user to test the valve's response and health without a full process shutdown. | | Accessories | Solenoid valves, limit switches, supply pressure regulators, and other components to complete the automated on/off package. |

Key Specifications & Parameters Parameter Specification Model Series easy-e™ (Comprises a valve body and a 1055/1065 size diaphragm actuator) Valve Type Balanced, Cage-Guided Globe Valve Actuator Type Spring-and-Diaphragm, Field-Reversible (for Air-to-Open or Air-to-Close action) Sizes 1/2 inch to 3 inches (DN 15 to DN 80) End Connections Flanged: ANSI Class 150 & 300 RF (Standard) Screwed (NPT): Available Pressure Ratings ANSI Class: 150 & 300 Max. Shut-off Pressure (ΔP): Dependent on actuator size and spring range. Consult performance tables. Temperature Range Standard: -20° to 400°F (-29° to 204°C) Extended: -50° to 450°F (-46° to 232°C) with specialized packing. Body Materials Standard: Carbon Steel (A216 WCB) Common Options: Stainless Steel (CF8 / 304, CF8M / 316) Trim Materials Standard Trim (Cage, Plug, Stem): 316 Stainless Steel Seat Ring: 316 Stainless Steel Soft Seat: PTFE (Teflon) for bubble-tight shut-off (ANSI Class VI). Flow Characteristics Equal Percentage (Standard, via characterized cage) Linear (Optional) Note: Characteristic is changed by re-orienting the cage, not by replacing it. Flow Capacity (Cv) Ranges from approximately 1.8 (for 1/2") to over 120 (for 3"), depending on the trim level. Rangeability 50:1 Leakage Class ANSI Class VI (Bubble-tight) with standard PTFE soft seat. Actuator Size: 1055 (for smaller valves) and 1065 (for larger valves) Spring Ranges: Standard ranges (e.g., 3-15 psig, 6-30 psig, 9-45 psig). Accessories Positioners: DVC6000 (Digital), 3582i (Pneumatic) Limit Switches, Solenoid Valves, Air Sets, Fail-Safe Kits (for loss of air supply).

Key Specifications & Parameters Parameter Specification Notes Model Series YD (Diaphragm Pilot), YS (Piston Pilot) Type Pilot-Operated, Pressure Reducing Regulator Primary Function Pressure Reducing Sizes 1/2 inch to 8 inches (DN 15 to DN 200) Larger sizes available for specific requirements. End Connections Flanged: ANSI Class 125, 150, 250, 300 (depending on body material) NPT: Available in smaller sizes. Pressure Ratings Body Ratings: ANSI Class 125, 150, 250, 300 Max. Inlet Pressure (P1): Up to 400 psig (27.6 bar) for certain sizes/materials. Outlet Pressure (P2) Ranges: Various pilot springs available, typically covering ranges from 5 to 300 psig (0.3 to 20.7 bar). The wide range is achieved by changing the pilot spring. Temperature Range YD (Diaphragm Pilot): Up to 406°F (208°C) YS (Piston Pilot): Up to 800°F (427°C) The YS is the clear choice for high-temperature superheated steam. Body Materials Standard: Ductile Iron (for steam service) Common Options: Cast Iron, Carbon Steel (WCB), Bronze. Material selection is critical for the application fluid. Trim Materials Stainless Steel, Stainless Steel with Stellite hard-facing (for erosive service). Flow Capacity (Cv) Very High. Significantly higher than same-size direct-operated regulators. Specific Cv depends on size and trim. (e.g., a 2" YD/YS can have a Cv over 100). This is a key advantage of the pilot-operated design. Pilot Options Various internal and external pilots available for specific control needs, including absolute pressure pilots (for vacuum breaker or back-pressure service) and temperature pilots. This versatility allows the YD/YS to be used for more than just pressure reduction. Accessories Internal Check Valve: Prevents reverse flow. Separate Strainer: Recommended to protect the pilot from debris.

Key Specifications & Parameters Parameter Specification Model Series DVC2000 (e.g., DVC2000, DVC2000f - fieldbus) Type Digital Valve Controller / Positioner Input Signal Standard: 4-20 mA DC, with HART® 5/6/7 protocol Digital Option: Foundation Fieldbus H1 (31.25 kbit/s) Output Signal Pneumatic Output: to control the valve actuator Supply Air Pressure Minimum: 0.14 bar (2 psig) above actuator pressure requirement Maximum: 7.0 bar (100 psig) for standard models; 10.3 bar (150 psig) for high-pressure (HP) models Air Consumption Steady State: Less than 0.028 Nm³/h (0.02 SCFM) Stroking: Additional consumption based on actuator size and travel speed Flow Capacity (Cv) Gauge Pressure (GP) versions: 0.086 High Flow (HF) versions: 0.32 Note: This is the Cv of the positioner's pneumatic relay. Stem Travel Range Linear Actuators: 3 to 150 mm (0.12 to 6.0 in) Rotary Actuators: 25° to 100° of rotation Accuracy Linearity: ±0.5% of span Hysteresis: 0.3% of span Sensitivity 0.1% of span Ambient Temperature Range Standard Electronics: -40° to 85°C (-40° to 185°F) Extended Temperature: -40° to 95°C (-40° to 203°F) option available Enclosure Rating NEMA 4X (IP66) - Weatherproof, dust-tight, and hose-proof Materials Enclosure: Aluminum with polyester coating Cover: Polycarbonate Communications HART: Via 4-20 mA loop Foundation Fieldbus: Via H1 terminal block Local: Infrared communication using Fisher FIELDVUE DVC2000 Setup Software or AMS Device Manager Diagnostic Capabilities Monitors and reports: - Valve Travel - Travel Accumulation - Actuator Pressure - Supply Pressure - Alarm Conditions (e.g., high friction, low supply, signal failure)

Key Specifications & Parameters Parameter Specification Model SS-263 (with various trim options and actuator types) Valve Type Top-Entry, Segmented V-Notch Ball, Rotating Shaft Flow Characteristic Approximated Equal Percentage (inherent, due to the V-notch profile) Sizes 1 inch to 16 inches (DN 25 to DN 400) End Connections Flanged: ANSI Class 150, 300, 600, 900, 1500 (RF, RTJ) Butt Weld: Available Pressure Ratings ANSI Class: 150, 300, 600, 900, 1500 Max. Pressure: Dependent on size and class. Can handle very high pressures, e.g., up to 3700 psig (255 bar) for ANSI 1500 class. Temperature Range Standard: -50° to 800°F (-46° to 427°C) Extended: Options available for cryogenic services down to -320°F (-196°C) and high-temperature services up to 1200°F (649°C) with special components. Body Materials Standard: 316 Stainless Steel (CF8M) Common Options: Carbon Steel (WCB/WCC), Alloy 20 (CN7M), Hastelloy C, Duplex Stainless Steel, Monel, Inconel. Trim Materials Ball & Shaft: 316 Stainless Steel (standard) with hard-facing options (e.g., Stellite) for erosive service. Seat: Multiple Options: - Soft Seat: Reinforced PTFE (RPTFE), PEEK for tight shut-off and lower temperatures. - Metal Seat: 17-4PH SS, Stellite, for high temperatures and erosive services. Flow Capacity (Cv) Extremely high Cv values. Specific values depend on size and trim. (e.g., an 8" SS-263 can have a Cv over 2000). Rangeability Very High, typically 100:1 or greater. Leakage Class Soft Seat (PTFE, PEEK): ANSI Class IV (bubble-tight) Metal Seat: ANSI Class V Fire-Tested: Designs available to meet API 607/API 6FA fire test standards. Actuator Options Pneumatic: Piston actuators (e.g., 1061P) are standard for the high thrust requirements of the SS-263. Electro-Hydraulic: Design EH for precise digital control. Hydraulic: Also available. Accessories Positioners, limit switches, solenoid valves, supply pressure regulators, etc.

Key Specifications & Parameters Parameter Specification Model Series GX (Comprises a valve body and a 657/667 diaphragm actuator) Valve Type Globe Valve, Characterized Cage-Guided Actuator Type Spring-and-Diaphragm, Field-Reversible (for Air-to-Open or Air-to-Close action) Sizes Valve Body (Port Size): 1/2 inch to 3 inches (DN 15 to DN 80) Actuator Size: 3 sizes (e.g., 30, 45, 70) to match valve size and pressure requirements. End Connections Screwed (NPT): Standard Flanged: ANSI Class 150 & 300 RF Socket Weld: Available Pressure Ratings ANSI Class: 150, 300, 600 (depending on body size and material) Max. Shut-off Pressure (P₁ - P₂): Dependent on actuator size and spring range. Consult performance tables. Temperature Range Standard: -20° to 400°F (-29° to 204°C) Extended: -50° to 450°F (-46° to 232°C) with specialized packing. Body Materials Standard: Carbon Steel (A216 WCB) Options: Stainless Steel (CF8M / 316), Alloy 20 (CN7M), Bronze. Trim Materials Standard Trim (Cage, Plug, Stem): 316 Stainless Steel Seat Ring: 316 Stainless Steel Soft Seat: PTFE (Teflon) for bubble-tight shut-off (ANSI Class VI). Flow Characteristics Equal Percentage (Standard, via characterized cage) Linear (Optional) Flow Capacity (Cv) Ranges from approximately 1.5 (for 1/2") to over 200 (for 3"), depending on trim level. Rangeability 50:1 Leakage Class ANSI Class VI (Bubble-tight) with standard PTFE soft seat. Actuator Spring Ranges Multiple standard ranges (e.g., 3-15 psig, 6-30 psig, etc.) to provide the required thrust for the application. Accessories Positioners: DVC6200 (Digital), 3582i (Pneumatic) Limit Switches, Solenoid Valves, Air Sets, Fail-Safe Kits (for loss of air supply).
