Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ RSS Reduced Section Control Valve Type Top-Entry, Sliding Stem, Post-Guided, Flangeless Body Globe Valve Primary Function Throttling (Modulating) Control for general-purpose process applications. Body Style Globe Body with a straight-through flow pattern. Size Range ½ inch to 6 inches (DN 15 to DN 150) Pressure Rating (ANSI) Class 150, 300, 600 End Connections Flangeless (Reduced Section). Requires separate companion flanges for installation between ANSI-rated pipeline flanges. Trim Post-Guided Plug. The plug is stabilized by a single guide post, providing adequate stability for general service. Leakage Class ANSI Class IV (standard metal seat). ANSI Class VI (bubble-tight shut-off) is available with a soft seat. Flow Characteristics Equal Percentage or Linear (determined by the contour of the plug). Temperature Range Standard: -20°F to 450°F (-29°C to 232°C). Extended ranges available with special materials. Actuator Compatibility Designed to be paired with Fisher pneumatic spring-and-diaphragm actuators (e.g., 585C series) and a positioner (e.g., a Fisher 480).

Specifications: Models: D (Double-Acting), DA (Spring-Return) Type: Piston Actuator, Scotch-Yoke design Action: Double-Acting (D) / Spring-Return (DA) Standard Travel: 90° quarter-turn (standard), 180° available for the D model. Mounting: Directly onto standard ISO 5211 mounting pads. Air Supply & Performance: Air Supply Pressure Range: D (Double-Acting): 2.8 to 8.6 bar (40 to 125 psig) DA (Spring-Return): 3.4 to 8.6 bar (50 to 125 psig) [Air pressure must overcome spring force] Ambient Temperature Range: -20° to 85°C (-4° to 185°F) with standard lubricant. Stroking Speed: Very fast, typically 1-2 seconds for 90° travel, depending on air supply and piping. Torque Output: Output: Torque output is a function of air supply pressure and actuator size. The DA model's torque varies between the air-side and spring-side of the stroke. Example Torque (for Size 30 @ 6.9 bar/100 psig): D Actuator: Approximately 70 Nm (50 lb-ft) at both ends of the stroke. DA Actuator: ~100 Nm (75 lb-ft) on the air end, ~60 Nm (45 lb-ft) on the spring end. Physical Data (Typical for Size 30): Body Material: Hard Anodized Aluminum Piston Rod & Yoke: Hardened Steel Weight: Approximately 5.4 kg (12 lbs) for the DA model. Accessories & Options: Positioners: Fisher FIELDVUE™ DVC6000 or other digital positioners can be mounted for precise modulating control. Limit Switches: Proximity or mechanical switches to indicate valve position. Solenoid Valves: Used for direct electrical control, essential for on-off and ESD applications. Air Filter Regulators: To clean and regulate the air supply. Manual Override: Optional handwheel for manual operation.

Specifications: Model: FB Pressure Regulator Type: Pilot-Operated Functions: Pressure Reducing, Backpressure Control, Relief Sizes & Connections: Valve Size: 1" to 8" (DN 25 to DN 200) Pressure Class: ANSI 125, 150, 300, 600 End Connections: Flanged (RF, RTJ) Performance & Ratings: Pressure Rating (Example): ANSI 150: 275 psi (19 bar) @ 100°F (38°C) ANSI 300: 720 psi (50 bar) @ 100°F (38°C) Temperature Range: -20° to 450°F (-29° to 232°C) [Standard; special packs available for extended range] Set Pressure Range: Varies widely based on the specific pilot and spring combination. Accuracy (Droop): High, typically 2% to 5% of the set point. Flow Coefficient (Cv): High Cv values. Specific values are determined by valve size and trim. Pilot Options: Proportional Pilot: Standard for most pressure reducing and backpressure applications. Bleed Pilot (Unloader): For applications with unstable loads or specific cycling requirements. Solenoid Stop Pilot: Allows for remote shutoff of the regulator. Dome-Loaded Pilot: Uses an external air supply for very precise set point control. Materials of Construction: Body: Carbon Steel (WCB) [Standard], Stainless Steel (CF8/CF8M), Ductile Iron. Trim (Plug, Seat): 316 Stainless Steel (standard), with optional hardened trim for erosive service.

Specifications: Model: FB Pressure Regulator Type: Pilot-Operated Functions: Pressure Reducing, Backpressure, Relief Sizes & Connections: Valve Size: 1" to 8" (DN 25 to DN 200) Pressure Class: ANSI 125 through 600 End Connections: Flanged (RF, RTJ) Performance & Ratings: Pressure Rating: Dependent on body class (e.g., for ANSI 150: 275 psi; for ANSI 300: 720 psi). Temperature Range: -20° to 450°F (-29° to 232°C) [Standard; special packs extend range] Set Pressure Range: Varies widely based on the specific pilot and spring used. Accuracy: High, with droop as low as 2-5% of the set point depending on the pilot. Pilot Options: Proportional Pilot: Standard for most pressure reducing and backpressure applications. Blind Pilot: For applications where the pilot does not need to sense a remote signal. Solenoid Stop Pilot: Allows for remote shutoff of the regulator. Dome-Loaded Pilot: For very precise set point control using an external air supply. Materials of Construction: Body: Carbon Steel (WCB) [Standard], Stainless Steel (CF8/CF8M), Ductile Iron. Trim (Plug, Seat): 316 Stainless Steel (standard), with optional hardened trim for erosive service. Diaphragm: Nylon-reinforced elastomer.

Specifications: Valve Size: 1/2" to 2" (DN 15 to DN 50) End Connections: NPT (National Pipe Taper) Pressure Rating: 275 PSIG (19 bar) @ 100°F (38°C) Temperature Range: -20° to 400°F (-29° to 204°C) [Dependent on seat material] Performance & Flow Characteristics: Shut-Off Class: ANSI Class VI (Bubble-tight) Flow Characteristic: Equal Percentage (inherent) Rangeability: Up to 100:1 Flow Coefficient (Cv): Ranges from approximately 5 to 50, depending on valve size and V-notch angle. Materials of Construction: Body: 316 Stainless Steel (standard), Carbon Steel Ball: 316 Stainless Steel Shaft: 316 Stainless Steel Seat: RPTFE (Reinforced PTFE) Actuator & Accessories: Actuator Types: Compatible with a wide range of compact Fisher and other rotary actuators due to its low torque. Pneumatic: Fisher 1051/1052 SRD (small sizes), Fisher 1053/1054, and other compact piston actuators. Electric: Electric Motor Actuators. Positioner: A Fisher FIELDVUE™ DVC6000 or other compact positioner can be mounted for precise modulating control.

Specifications: Valve Size: 1" to 8" (DN 25 to DN 200) Pressure Class: ANSI 150, 300 End Connections: Flanged (RF, RTJ) Temperature Range: -20° to 400°F (-29° to 204°C) [Dependent on seat material] Performance & Flow Characteristics: Shut-Off Class: ANSI Class VI (Bubble-tight) Flow Characteristic: Approximately Equal Percentage (inherent) Rangeability: Up to 200:1 Flow Coefficient (Cv): High Cv values. Specific values are determined by valve size and V-notch angle (e.g., 15°, 30°, 45°, 60°, 75°, 90°). Materials of Construction: Body: Cast Iron (epoxy coated standard), Ductile Iron, Carbon Steel (WCB), Stainless Steel (CF8M). Ball: 316 Stainless Steel (standard) Shaft: 17-4PH Stainless Steel (standard) Seat: Reinforced PTFE (RPTFE) (standard), UHMW-PE, PEEK. Actuator & Accessories: Actuator Types: Pneumatic: Fisher 1051/1052 SRD Piston Actuators (for on-off and modulating), Fisher 657/667 Diaphragm Actuators. Electric: Electric Motor Actuators. Positioner: A Fisher FIELDVUE™ DVC digital positioner is highly recommended for precise modulating control and diagnostic capabilities. Accessories: Limit switches, solenoid valves, filter regulators, etc.

Specifications: Model: 2100 Safety Relief Valve Type: Conventional Spring-Loaded, Full Nozzle Design Standard: ASME Boiler and Pressure Vessel Code, Section VIII Sizes & Connections: Valve Size (Inlet): 1" x 2" through 4" x 6" (common inlet x outlet sizes) Orifice Designations: D through T (per ASME/API standards) End Connections: Flanged (RF, RTJ) standard. Other connections available. Pressure Class: ANSI 150 through 2500 Performance & Ratings: Set Pressure Range: Varies by spring and valve design, typically from around 15 psig to over 1000 psig. Temperature Range: -20° to 800°F (-29° to 427°C) [Dependent on materials] Overpressure: Standard setting is 3% for steam/gas and 10% for liquid (per ASME code). Blowdown: Adjustable, typically 2-7%. Backpressure: Limited built-in backpressure capability. A balanced bellows design is available as an option for applications with significant backpressure. Materials of Construction: Body: Carbon Steel (WCB) [Standard], Stainless Steel (CF8/CF8M), Alloy Steels (WC6, WC9). Nozzle & Disc: Typically 316 Stainless Steel. Hardened trim (Stellite) is available for erosive or high-pressure services. Spring: Chrome Vanadium Steel.

Specifications: Models: L2 (Single-Acting, for Inlet Control), L2sj (Double-Acting, for Outlet Control) Type: Pilot-Operated Float Level Controller Operation: Mechanical / Pneumatic (Self-Contained) Process Connections & Mounting: Cage Size: Standard displacer cage lengths from 14 in to 120 in (355 mm to 3048 mm). Process Connection: Typically 2-inch or 3-inch NPT or flanged cage connections. Mounting: Internal cage, external cage, or bridle mounting. Pilot & Supply Pressure: Supply Pressure Range: 35 to 150 psig (2.4 to 10.3 bar) Pilot Output Pressure: Varies based on supply pressure and float position, used to actuate the main control valve. Materials of Construction: Cage/Body: Cast Iron (standard), Ductile Iron, Carbon Steel, Stainless Steel. Float: Stainless Steel. Internal Parts: Stainless Steel and Brass. Performance & Sizing: Control Sensitivity: Highly dependent on float size, lever arm length, and supply pressure. Capacity: The controllers themselves do not have a flow capacity (Cv). They are sized based on their ability to pilot and control a separate main control valve, which is selected based on the required flow rate.

Specifications: Valve Size: 3" to 12" (DN 80 to DN 300) Pressure Class: ANSI 150 End Connections: Wafer, Lugged Temperature Range: -20° to 400°F (-29° to 204°C) [Dependent on seat material] Performance & Flow Characteristics: Shut-Off Class: ANSI Class VI (Bubble-tight) Flow Coefficient (Cv): High Cv values. Specific values depend on valve size. Pressure Rating: 150 psi (10.3 bar) saturated steam; 275 psi (19.0 bar) for water, oil, and gas. Materials of Construction: Body: Ductile Iron (epoxy coated standard), Carbon Steel, Stainless Steel Disc: 316 Stainless Steel (standard) Stem: 17-4PH Stainless Steel (standard) Seat: Resilient materials such as Buna-N (Standard), EPDM, or Viton® for different fluid compatibilities and temperature ranges. Actuator & Accessories: Actuator Types: Pneumatic: Fisher 1051/1052 SRD spring-return and double-acting piston actuators, 657/667 spring-diaphragm actuators. Electric: Electric motor actuators. Positioner: A Fisher FIELDVUE™ DVC or other rotary positioner can be mounted for precise modulating control. Accessories: Limit switches, solenoid valves, filter regulators, etc.

General Specifications: Model: 3620JP Pilot-Operated Safety Relief Valve Design Standard: JIS B 8210 Operation Type: Pilot-Operated Main Valve Specifications: Valve Size: Larger JIS sizes to handle higher flows (e.g., 80A, 100A, 125A, 150A, 200A). Pressure Rating: JIS high-pressure classes (e.g., 16K, 20K, 30K, 40K, 63K). End Connections: JIS Flanges (e.g., JIS 20K, 30K RF flange facing). Orifice Area: Larger orifice sizes to meet high-capacity demands. Pilot Specifications: Pilot Types: Standard Pilot: For general steam and gas service. Balanced Piston Pilot: For applications with high or variable backpressure. Liquid Service Pilot: For liquid applications. Set Pressure Range: Capable of higher set pressures compared to the 3610JP series. Performance Characteristics: Accumulation (Overpressure): Typically 3% for steam (per JIS B 8210). Blowdown: Adjustable. Backpressure Capability: Standard: Limited built-in backpressure capability. Balanced: Can handle high levels of variable backpressure (e.g., up to 50% or more of inlet pressure) when equipped with a balanced pilot. Materials of Construction: Main Valve Body: SCPH 2 Cast Steel (Standard), with options for higher grades like SCPH 32 for high-temperature service. Internals (Piston, Seat): Stainless Steel with optional hardened trim for erosive services. Pilot: Stainless Steel and Brass.
