Technical Parameters Parameter Category Description / Value Brand & Series Eaton, Z5 Series Model Number Z5-220/FF250 Rated Current 220 A Rated Voltage 500V AC Breaking Capacity 120 kA (at 500V AC) Fuse Type Square Body Fuse Link Utilization Category gG (General Application, full-range) Indicator Yes (Visual blown fuse indicator) Standards Compliance IEC 60269-1, IEC 60269-2

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, XTCG Series Model Number XTCG080E00DT Rated Current 80 A Number of Poles 2-Pole Rated Voltage 240V AC Breaking Capacity Typically 10 kA (Please confirm with specific catalog) Trip Characteristics Thermal-Magnetic Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60898-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM32C-XHI11 Rated Operational Current (Ie) 32 A at AC-3, 400V Thermal Current (Ith) 32 A Poles (Main Circuit) 3 (Normally Open) Auxiliary Contacts Typically 1 NO (Normally Open) + 1 NC (Normally Closed) - Convertible Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage DC operating coil (Specific voltage must be specified - e.g., 24V DC) Integrated Timer HI11 Multi-function Time Relay Timer Functions Multiple timing modes (On-delay, Off-delay, Interval, etc.) Motor Rating (at 400V AC) 15 kW / 20 HP Mechanical Life ~ 15 million operations Electrical Life (AC-3) ~ 1.5 million operations Mounting Standard 35mm DIN Rail (EN 60715) Standards Compliance IEC/EN 60947-4-1, IEC/EN 60947-5-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PLD9X Series Model Number PLD9X-63/2/D/003-A Rated Operational Current (Ie) 63 A Number of Poles 2-Pole Rated Operational Voltage (Ue) 400V AC Rated Insulation Voltage (Ui) 500V AC Utilization Categories AC-22 (Switching mixed resistive and inductive loads) AC-23 (Switching motor loads) Operation Type Rotary Handle Operation (D) Fuse Compatibility Designed for use with 10x38mm fuses Mounting DIN Rail (35mm) Mechanical Life ~ 10,000 operations Electrical Life ~ 1,500 operations (at rated current) Standards Compliance IEC/EN 60947-3

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM25-10 XTCE025C10 Rated Operational Current (Ie) 25 A at AC-3, 400V Thermal Current (Ith) 25 A Poles (Main Circuit) 3 (Normally Open) Auxiliary Contacts 1 NO (Normally Open) + 1 NC (Normally Closed) - Convertible Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage The XTCE025C10 suffix indicates a specific AC or DC coil voltage variant (exact voltage must be confirmed from datasheet, e.g., 230V AC or 24V DC). Utilization Categories AC-3: Squirrel cage motors: Starting, switching off during running AC-1: Non-inductive or slightly inductive loads Motor Rating (at 400V AC) 11 kW / 15 HP Mechanical Life ~ 15 million operations Electrical Life (AC-3) ~ 1.5 million operations Mounting Standard 35mm DIN Rail (EN 60715) or screw mounting Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Terminal Type Cage Clamp / Screw Clamp

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM1000-XHI11-SI Rated Operational Current (Ie) 1000 A at AC-3, 400V Poles (Main Circuit) 3 (Normally Open) Rated Operational Voltage (Ue) Up to 1000V AC Control Coil Voltage Standard AC voltages (e.g., 110V, 230V, 400V AC). Must be specified. Integrated Timer HI11 Multi-function Time Relay Supplementary Interface SI - Likely provides additional control inputs, outputs, or communication capabilities. Motor Rating (at 400V AC) 500 kW / 670 HP (Approximate) Mounting Fixed Mounting (Typically base-plate or frame mounting due to size and weight) Standards Compliance IEC/EN 60947-4-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NHI Series Model Number NHI-E-11-PKZ0 XTPAXFA11 Poles 3-Pole Trip Class Class 10 Current Setting Range 0.11 - 0.16 A Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Ambient Temperature Range -25°C to +60°C Standards Compliance IEC/EN 60947-4-1 Mounting Snap-on mounting to compatible Eaton contactors Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Reset Mode Manual reset

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NHI Series Model Number NHI-E-11-PKZ0 Poles 3-Pole Trip Class Class 10 Current Setting Range 0.11 - 0.16 A Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Ambient Temperature Range -20°C to +55°C (Without derating) Standards Compliance IEC/EN 60947-4-1 Mounting Snap-on mounting to compatible Eaton PKZ0 series contactors Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Reset Mode Manual reset

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, B3 Series Model Number B3.1/2-PKZ4 XTPAXCLKB2D Mounting Diameter 22.5 mm Function Illuminated Pushbutton Actuator Color Black Compatibility PKZ4 motor starter system Contact Configuration 1 NO (Normally Open) Rated Operational Voltage (Ue) AC-15: 240V AC DC-13: 60V DC Rated Thermal Current (Ith) 10 A Mounting Panel Mount Protection Degree Front panel: IP65 Mechanical Life > 1,000,000 operations Electrical Life > 100,000 operations (at rated load) Standards Compliance IEC/EN 60947-5-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NHI Series Model Number NHI-E-10-PKZ0 Poles 3-Pole Trip Class Class 10 Current Setting Range 0.10 - 0.14 A Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Ambient Temperature Range -20°C to +55°C (Without derating) Standards Compliance IEC/EN 60947-4-1 Mounting Snap-on mounting to compatible Eaton PKZ0 series contactors Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Reset Mode Manual reset
