Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NZM Series Model Number NZM1-XTVD-0 Compatibility NZM1 series Molded Case Circuit Breakers Function Universal Draw-Out Mechanism Kit Mounting Installs into a compatible switchboard/panel Position Indication Typically includes indicators for CONNECTED, TEST, DISCONNECTED positions Standards Compliance Designed to comply with the same standards as the NZM1 breaker (IEC 60947-2)

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, EMT6 Series Model Number EMT6-DB Power Supply Voltage 24-240V AC/DC (Wide range, auto-sensing) Output Relay DPDT (2 CO) - 2 Changeover contacts Contact Rating: Typically 8A @ 250V AC Timing Ranges Multiple ranges selectable (e.g., from 0.05 seconds up to 100 hours) Functions Multiple timing functions selectable (e.g., On-delay, Off-delay, Interval, Flasher, etc.) Accuracy ±0.5% of set time ± 20 ms (typical for digital timers) Mounting DIN Rail (35mm) Display / Indication LED Status Indicators (Power, Output state) Standards Compliance IEC/EN 61812-1, UL 508, CSA C22.2 No. 14

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, ZB Series Model Number ZB32C-24 Output Voltage 24V DC Rated Output Power 32 W Rated Output Current 1.3 A Input Voltage Range 85-264V AC (Wide range, auto-sensing) Input Frequency Range 47-63 Hz Efficiency Typically >85% Power Factor (PF) Typically >0.9 Output Adjustment Range Typically ±10% (e.g., 21.6-26.4V DC) Mounting DIN Rail (35mm) Protection Overload Protection, Overvoltage Protection, Short-Circuit Protection Standards Compliance IEC/EN 61347-1, IEC/EN 61347-2-13, UL 1310, CSA C22.2 No. 223

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PL9 Series Model Number PL9-C32/2 Fuse Standard & Rating IEC gG (General Application) Rated Current: 32 A Number of Poles / Quantity 2 pieces (2-pole set) Rated Voltage 500V AC Breaking Capacity 50 kA (50,000 A) at 500V AC Standards Compliance IEC 60269-1, IEC 60269-2-1 Fuse Dimension 10 x 38 mm (Diameter x Length) Mounting Requires compatible fuse holder for 10x38mm fuses Utilization Category gG - Full-range breaking capacity for general applications

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, ZB Series Model Number ZB12C-10 Output Voltage 12V DC Rated Output Power 10 W Rated Output Current 0.83 A Input Voltage Range 85-264V AC (Wide range, auto-sensing) Input Frequency Range 47-63 Hz Efficiency Typically >80% Power Factor (PF) Typically >0.9 Output Adjustment Range Typically ±10% (e.g., 10.8-13.2V DC) Mounting DIN Rail (35mm) Protection Overload Protection, Overvoltage Protection, Short-Circuit Protection Standards Compliance IEC/EN 61347-1, IEC/EN 61347-2-13, UL 1310, CSA C22.2 No. 223

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PKZM4 Series Model Number PKZM4-58 Rated Operational Current (Ie) 58 A Rated Current Setting (Ir) Adjustable, typically up to 58A Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 690V AC Utilization Category AC-3 (Squirrel cage motor: Starting, switching off during running) Motor Power Rating (at 400V AC) 30 kW / 40 HP (Approximate) Short-Circuit Breaking Capacity (Icu) Typically 50 kA at 400V AC (Confirm with specific datasheet) Trip Class Class 10 (Standard for motor protection) Standards Compliance IEC/EN 60947-2, IEC/EN 60947-4-1 Mounting DIN Rail (35mm)

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, ZB Series Model Number ZB12C-1,6 Output Voltage 12V DC Rated Output Power 1.6 W Rated Output Current 0.13 A Input Voltage Range 85-264V AC (Wide range, auto-sensing) Input Frequency Range 47-63 Hz Efficiency Typically >70% Mounting DIN Rail (35mm) Protection Overload Protection, Short-Circuit Protection Standards Compliance IEC/EN 61347-1, IEC/EN 61347-2-13

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILRC Series Model Number DILRC-22 Rated Operational Current (Ie) 22 A (for AC-1 category, resistive loads) Poles 4-Pole (Typically 4 Normally Open (NO) contacts) Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage Available in multiple standard AC and DC voltages (e.g., 24V AC/DC, 110V AC, 230V AC, etc.). The specific voltage is not defined by "22" and must be specified when ordering. Utilization Categories AC-1: Non-inductive or slightly inductive loads AC-15: Control of electromagnetic loads (≤ 720 VA) DC-1: Non-inductive or slightly inductive loads DC-13: Control of electromagnetic loads Mechanical Life ~ 10 - 30 million operations (typical for this series) Electrical Life Varies by utilization category (e.g., ~ 1-3 million operations at rated AC-15 load) Mounting Standard 35mm DIN Rail (EN 60715) Standards Compliance IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14 Terminal Type Cage Clamp or Screw Clamp

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NZM Series Model Number NZMB1-4-A125 Rated Current 125 A (Frame Size) Poles 4-Pole Rated Operational Voltage (Ue) Up to 690V AC Rated Insulation Voltage (Ui) 800V AC Trip Unit Type Type A - Adjustable Electronic Trip Unit Protection Functions L - Long-time Delay (Overload) S - Short-time Delay (Short-Circuit) I - Instantaneous (Short-Circuit) Breaking Capacity (Icu) High interrupting capacity (e.g., 25kA, 35kA, or higher depending on specific rating and voltage) Standards Compliance IEC 60947-2

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NZM Series Model Number NZMN1-A63 Rated Current 63 A (Frame Size) Poles Typically 3-Pole (Pole configuration may vary, confirm with specific order code) Rated Operational Voltage (Ue) Up to 690V AC Rated Insulation Voltage (Ui) 800V AC Trip Unit Type Type A - Adjustable Electronic Trip Unit Protection Functions L - Long-time Delay (Overload) S - Short-time Delay (Short-Circuit) I - Instantaneous (Short-Circuit) Breaking Capacity (Icu) High interrupting capacity (Typically 25 kA to 50 kA depending on specific voltage rating) Standards Compliance IEC 60947-2
