EATON
M22-PVT
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, M22 Series Model Number M22-PVT Sensor Type Inductive Proximity Sensor Housing Material Typically Nickel-plated brass or Stainless Steel Thread Size M22 x 1.5 Connection Type PVC Cable (Specific length and conductor count vary - e.g., 2m 3-core) Sensing Distance 5 mm (Standard for M22 inductive sensors) Output Type DC 3-wire (Typically PNP or NPN, selectable or fixed - check datasheet) Supply Voltage 10-30V DC Rated Operating Current Typically ≤ 200 mA Switching Frequency Typically ≤ 500 Hz Protection Degree IP67 Standards Compliance IEC 60947-5-2

More details >> Request a Quote >>
EATON
DILM9-10
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM9-10 Rated Operational Current (Ie) 9 A at AC-3, 400V Thermal Current (Ith) 9 A Poles (Main Circuit) 3 (Normally Open) Auxiliary Contacts 1 NO (Normally Open) + 1 NC (Normally Closed) - Convertible Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage Available in multiple standard AC voltages (e.g., 24V, 110V, 230V, 400V AC). The specific voltage must be specified when ordering. Utilization Categories AC-3: Squirrel cage motors: Starting, switching off during running AC-1: Non-inductive or slightly inductive loads Motor Rating (at 400V AC) 4 kW / 5.5 HP Mechanical Life ~ 15 million operations Electrical Life (AC-3) ~ 1.5 million operations Mounting Standard 35mm DIN Rail (EN 60715) or screw mounting Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Terminal Type Cage Clamp / Screw Clamp

More details >> Request a Quote >>
EATON
ETR4-70-A
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, ETR4 Series Model Number ETR4-70-A Poles 3-Pole Trip Class Class 10 Current Setting Range 53 - 70 A Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Ambient Temperature Range -25°C to +60°C (Derating may apply above +50°C) Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Snap-on mounting to compatible Eaton DIL contactors Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) - Convertible Reset Mode Manual reset (Automatic reset optional)

More details >> Request a Quote >>
EATON
DILM65C
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM65C Rated Operational Current (Ie) 65 A at AC-3, 400V Thermal Current (Ith) 65 A Poles (Main Circuit) 3 (Normally Open) Auxiliary Contacts Typically 1 NO (Normally Open) - Fixed (configurable with additional blocks) Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage "C" denotes a standard DC voltage range. The specific voltage must be ordered (e.g., 24V DC, 110V DC). Utilization Categories AC-3: Squirrel cage motors: Starting, switching off during running AC-1: Non-inductive or slightly inductive loads Motor Rating (at 400V AC) 37 kW / 50 HP Mechanical Life ~ 10 million operations Electrical Life (AC-3) ~ 1 million operations Mounting Standard 35mm DIN Rail (EN 60715) or screw mounting Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Terminal Type Screw Clamp

More details >> Request a Quote >>
EATON
M22-R4K7
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, M22 Series Model Number M22-R4K7 Sensor Type Inductive Proximity Sensor Housing Material Typically Nickel-plated brass or Stainless Steel Thread Size M22 x 1.5 Connection Type Pre-wired cable (Specific length varies) Integrated Resistor 4.7 kΩ Sensing Distance 5 mm (Standard for M22 inductive sensors) Output Type Analog or Special Configuration Supply Voltage 10-30V DC Protection Degree IP67 Standards Compliance IEC 60947-5-2

More details >> Request a Quote >>
EATON
NZMN2-A200
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NZM Series Model Number NZMN2-A200 Number of Poles 2-Pole Rated Current 200 A (Frame Size) Rated Operational Voltage (Ue) Up to 480V AC Rated Insulation Voltage (Ui) 690V AC Rated Ultimate Breaking Capacity (Icu) Typically 25 kA / 35 kA at 480V AC (Confirm with specific datasheet) Trip Unit Type Type A - Adjustable Electronic Trip Unit Protection Functions L - Long-time Delay (Overload) S - Short-time Delay (Short-Circuit) I - Instantaneous (Short-Circuit) Standards Compliance IEC 60947-2

More details >> Request a Quote >>
EATON
EMT6-K
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, EMT6 Series Model Number EMT6-K Power Supply Voltage 24-240V AC/DC (Wide range, auto-sensing) Output Relay DPDT (2 CO) - 2 Changeover contacts Contact Rating: Typically 8A @ 250V AC Timing Ranges Multiple ranges selectable (e.g., from 0.05 seconds up to 100 hours) Functions Specific set of timing functions selectable (e.g., On-delay, Off-delay, Interval, Flasher, etc. - defined by the "K" variant) Accuracy ±0.5% of set time ± 20 ms (typical for digital timers) Mounting DIN Rail (35mm) Display / Indication LED Status Indicators (Power, Output state) Standards Compliance IEC/EN 61812-1, UL 508, CSA C22.2 No. 14

More details >> Request a Quote >>
EATON
M22-R10K
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, M22 Series Model Number M22-R10K Sensor Type Inductive Proximity Sensor Housing Material Typically Nickel-plated brass or Stainless Steel Thread Size M22 x 1.5 Connection Type Pre-wired cable (Specific length varies) Integrated Resistor 10 kΩ Sensing Distance 5 mm (Standard for M22 inductive sensors) Output Type Analog or Special Configuration Supply Voltage 10-30V DC Current Consumption Typically ≤ 15 mA Switching Frequency Typically ≤ 500 Hz Hysteresis Typically ≤ 10% of sensing distance Protection Degree IP67 Ambient Temperature -25°C to +70°C Standards Compliance IEC 60947-5-2

More details >> Request a Quote >>
EATON
P3-63-63/EA/SVB
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, P3 Series Model Number P3-63-63/EA/SVB Rated Current (In) 63 A Number of Poles 3-Pole Tripping Characteristic Type C (Instantaneous trip: 5-10 x In) Rated Operational Voltage (Ue) 400/415V AC (Three-Phase) Rated Insulation Voltage (Ui) 500V AC Breaking Capacity (Icn) Typically 10 kA / 15 kA (Please confirm with specific catalog) Auxiliary Function EA - Alarm Switch (Signals trip condition via a separate contact) Terminal Type SVB - Shrouded Terminal Barrier (Finger Protection) Mounting Standard 35mm DIN Rail (EN 60715) Standards Compliance IEC/EN 60898-1

More details >> Request a Quote >>
EATON
SVB-SW-T0
Technical Parameters Parameter Category Description / Value Brand & Series Eaton, SVB Series Model Number SVB-SW-T0 Accessory Type Shrouded Terminal Barrier Function Finger Protection / Touch Protection Compatibility Designed for specific Eaton switch disconnectors (exact compatible models to be verified) Protection Degree Provides IP20 protection when properly installed Material Thermoplastic (Typically UL94 V-0 rated for flame retardancy) Color Typically Orange or safety color for high visibility Mounting Snap-on installation to compatible Eaton devices Standards Compliance IEC/EN 60529 (IP Code), relevant parts of IEC/EN 60947 series

More details >> Request a Quote >>
