Parameter Description Specification Product Series DILM Series Contactor Relay Rated Operational Current AC-1 (Resistive Load) 22 A at 690V Motor Rating AC-3 (Squirrel Cage Motor) 7.5 kW at 400V/50 Hz Resistive Load Rating AC-1 15 kW at 400V Number of Poles Main Circuits 4 NO (Normally Open) Rated Insulation Voltage 1000 V Rated Operational Voltage Up to 690 V AC Coil Control Voltage AC Operation 230V AC, 50/60 Hz* Surge Suppression RA250 Module Integrated RC circuit Electrical Endurance AC-3 > 1 million operations Mechanical Durability > 10 million operations Mounting Method 35 mm DIN rail Connection Type Spring-loaded cage clamp Ambient Temperature Operation -25°C to +60°C Standards & Approvals IEC/EN 60947-4-1, UL 508, CE, CCC

Parameter Description Specification Product Series Networker ZM Series NZMS3 Modular UPS Configuration Code AE400 Standard configuration Topology Double Conversion Online Input Nominal Voltage 400/415V AC, 3Ph + N Input Voltage Range ±25% without battery operation Frequency 50/60 Hz auto-sensing Output Nominal Voltage 400/415V AC, 3Ph + N Voltage Regulation ±1% Frequency Regulation Synchronized to bypass Power Capacity Apparent Power 40 kVA (typical for this configuration)* Active Power 40 kW (typical for this configuration)* Efficiency Double Conversion Mode Up to 96.5% ECO Mode Over 99% Battery DC Voltage Configurable based on battery packs Runtime Expandable with external battery cabinets Modularity Power Modules Hot-swappable modules Redundancy N+1 configurable Communication Management Standard communication interfaces Protocols SNMP, Web/HTTP, Modbus, Dry contacts Standards Compliance IEC 62040, CE, UL

Parameter Description Specification Product Series Networker ZM Series NZMN4 Modular UPS Configuration AE1600 Power configuration code Topology -AS Double Conversion Online Input Nominal Voltage 400/415V AC, 3Ph + N Input Voltage Range ±25% without battery operation Frequency 50/60 Hz auto-sensing Input Current Designed for 1600A capacity* Output Nominal Voltage 400/415V AC, 3Ph + N Voltage Regulation ±1% Frequency Regulation Synchronized to bypass Power Capacity Apparent Power 1600 kVA (typical for this frame)* Active Power 1600 kW (typical for this frame)* Efficiency Double Conversion Mode Up to 97% ECO Mode Over 99% Battery DC Voltage Configurable DC bus voltage Runtime Expandable with external battery cabinets Modularity Power Modules Hot-swappable power modules Redundancy N+X configurable Communication Management Advanced monitoring capabilities Protocols SNMP, Web/HTTP, Modbus, JBus Physical Form Factor Tower/Static standalone Standards Compliance IEC 62040, UL, CE

Parameter Description Specification Product Series Networker ZM Series NZMN4 Modular UPS Configuration AE1250 Power configuration code Topology -AS Double Conversion Online Input Nominal Voltage 400/415V AC, 3Ph + N Input Voltage Range ±25% without battery operation Frequency 50/60 Hz auto-sensing Output Nominal Voltage 400/415V AC, 3Ph + N Voltage Regulation ±1% Frequency Regulation Synchronized to bypass Power Capacity Apparent Power 1250 kVA (typical for this frame)* Active Power 1250 kW (typical for this frame)* Efficiency Double Conversion Mode Up to 96.5% ECO Mode Over 99% Battery DC Voltage Configurable DC bus voltage Runtime Expandable with external battery cabinets Modularity Power Modules Hot-swappable power modules Redundancy N+X configurable Communication Management Advanced monitoring capabilities Protocols SNMP, Web/HTTP, Modbus, JBus Physical Form Factor Tower/Static standalone Operating Temperature 0°C to 40°C Standards Compliance IEC 62040, UL, CE, cETL

Parameter Description Specification Product Series Networker ZM Series NZMN4 Modular UPS Configuration AE800 Power configuration code Topology -AS Double Conversion Online Input Nominal Voltage 400/415V AC, 3Ph + N Input Voltage Range ±25% without battery operation Frequency 50/60 Hz auto-sensing Output Nominal Voltage 400/415V AC, 3Ph + N Voltage Regulation ±1% Frequency Regulation Synchronized to bypass Power Capacity Apparent Power 800 kVA (typical for this frame)* Active Power 800 kW (typical for this frame)* Efficiency Double Conversion Mode Up to 96.5% ECO Mode Over 99% Battery DC Voltage Configurable DC bus voltage Runtime Expandable with external battery cabinets Modularity Power Modules Hot-swappable power modules Redundancy N+X configurable Communication Management Advanced monitoring capabilities Protocols SNMP, Web/HTTP, Modbus, JBus Physical Form Factor Tower/Static standalone Operating Temperature 0°C to 40°C Standards Compliance IEC 62040, UL, CE, cETL

Parameter Description Specification Product Series Networker ZM Series NZMN4 Modular UPS Configuration AE630 Power configuration code Topology -AS Double Conversion Online Input Nominal Voltage 400/415V AC, 3Ph + N Input Voltage Range ±25% without battery operation Frequency 50/60 Hz auto-sensing Output Nominal Voltage 400/415V AC, 3Ph + N Voltage Regulation ±1% Frequency Regulation Synchronized to bypass Power Capacity Apparent Power 630 kVA (typical for this frame)* Active Power 630 kW (typical for this frame)* Efficiency Double Conversion Mode Up to 96.5% ECO Mode Over 99% Battery DC Voltage Configurable DC bus voltage Runtime Expandable with external battery cabinets Modularity Power Modules Hot-swappable power modules Redundancy N+X configurable Communication Management Advanced monitoring capabilities Protocols SNMP, Web/HTTP, Modbus, JBus Physical Form Factor Tower/Static standalone Operating Temperature 0°C to 40°C Standards Compliance IEC 62040, UL, CE, cETL

Parameter Description Specification Product Series Networker ZM Series NZMN4 Modular UPS Configuration AE800 Power configuration code Input Nominal Voltage 400/415V AC, 3Ph + N Input Voltage Range Wide input voltage range Frequency 50/60 Hz auto-sensing Output Nominal Voltage 400/415V AC, 3Ph + N Voltage Regulation Typically ±1-2% Power Capacity Apparent Power 800 kVA* Active Power 800 kW* Efficiency Normal Operation High efficiency design Battery Runtime Expandable with external battery cabinets DC Voltage Configurable DC bus voltage Modularity Power Modules Hot-swappable design Redundancy Configurable redundancy options Communication Management Advanced monitoring system Protocols Multiple protocol support Physical Form Factor Tower/Static standalone Standards Compliance International safety standards

Parameter Description Specification Product Series DILM Series Contactor Relay Rated Operational Current AC-1 (Resistive Load) 58 A at 690V Motor Rating AC-3 (Squirrel Cage Motor) 30 kW at 400V/50 Hz Resistive Load Rating AC-1 40 kW at 400V Number of Poles Main Circuits 4 NO (Normally Open) Rated Insulation Voltage 1000 V Rated Operational Voltage Up to 690 V AC Coil Control Voltage AC Operation 230V AC, 50/60 Hz* Electrical Endurance AC-3 > 1.5 million operations Mechanical Durability > 10 million operations Mounting Method 35 mm DIN rail Connection Type Spring-loaded cage clamp Terminal Capacity Main Circuits Up to 16 mm² Ambient Temperature Operation -25°C to +60°C Standards & Approvals IEC/EN 60947-4-1, UL 508, CE, CCC

Parameter Description Specification Product Series DILM Series Contactor Relay Rated Operational Current AC-1 (Resistive Load) 40 A at 690V Motor Rating AC-3 (Squirrel Cage Motor) 18.5 kW at 400V/50 Hz Resistive Load Rating AC-1 22 kW at 400V Number of Poles Main Circuits 4 NO (Normally Open) Rated Insulation Voltage 1000 V Rated Operational Voltage Up to 690 V AC Coil Control Voltage AC Operation 230V AC, 50/60 Hz* Electrical Endurance AC-3 > 1.3 million operations Mechanical Durability > 10 million operations Mounting Method 35 mm DIN rail Connection Type Spring-loaded cage clamp Terminal Capacity Main Circuits Up to 10 mm² Ambient Temperature Operation -25°C to +60°C Weight Approximate 0.8 kg Standards & Approvals IEC/EN 60947-4-1, UL 508, CE, CCC

Parameter Description Specification Product Series DILM Series Contactor Relay Generation Enhanced "A" Version Improved electrical endurance Rated Operational Current AC-1 (Resistive Load) 32 A at 690V Motor Rating AC-3 (Squirrel Cage Motor) 15 kW at 400V/50 Hz Resistive Load Rating AC-1 22 kW at 400V Number of Poles Main Circuits 4 NO (Normally Open) Rated Insulation Voltage 1000 V Rated Operational Voltage Up to 690 V AC Coil Control Voltage AC Operation 230V AC, 50/60 Hz* Electrical Endurance AC-3 > 2 million operations Mechanical Durability > 15 million operations Mounting Method 35 mm DIN rail Connection Type Spring-loaded cage clamp Terminal Capacity Main Circuits Up to 10 mm² Ambient Temperature Operation -25°C to +60°C Standards & Approvals IEC/EN 60947-4-1, UL 508, CE, CCC
