Technical Parameters Category Specification Product Model XV-102-D6 Product Line Viking® Valve Type 5/2-way (5 ports, 2 positions) Actuation Type Solenoid (The "D" in D6 typically indicates single or double solenoid). Note: The exact configuration (single solenoid with spring return or double solenoid) should be confirmed from the datasheet. Port Size 1/4" (NPT standard) Operating Pressure Range 30 to 150 psi (2 to 10 bar) Media Compressed Air, as per ISO 8573-1:2010 [7:4:4] Voltage Options Various AC and DC voltages are available (e.g., 24 V DC, 110 V AC, 230 V AC). The specific voltage must be confirmed from the valve's label or ordering code. Standard CE, RoHS compliant Body Material Die-cast Zinc Seal Material NBR (Nitrile Rubber) Temperature Range Media & Ambient: 14° to 140°F (-10° to 60°C) Flow Coefficient (Cv) Approximately 1.8 (This is a typical value for this port size; confirms flow capacity) Mounting Base-mounted (Sub-base) Electrical Connection Standard DIN 43650 Form A (for solenoids)

Technical Parameters Category Specification Product Model XV-102-D6-57TVRC-1K Product Line Eaton Viking® Valve Type 5/2-way (5 ports, 2 positions) Actuation Type Double Solenoid (The "D6" confirms this) Port Size 1/4" NPT Operating Pressure Range 30 to 150 psi (2 to 10 bar) Media Compressed Air (Filtered, Lubricated or Non-Lubricated) Solenoid Voltage 24 V DC (This is specified by the "-1K" suffix in this context) Electrical Connection PVC Cable with Flying Leads, 2m length (Specified by "57TVRC") Standard CE, RoHS compliant Body Material Die-cast Zinc Seal Material NBR (Nitrile Rubber) Temperature Range Media & Ambient: 14° to 140°F (-10° to 60°C) Flow Coefficient (Cv) Approximately 1.8 Mounting Base-mounted (Sub-base)

Technical Parameters Parameter Specification Product Model XV-102-B5-35TQR-10-PLC Product Line Eaton Viking® Valve Type 5/2-way (5 ports, 2 positions) Actuation Type Single Solenoid, Spring Return Port Size 1/4" NPT Operating Pressure 30 to 150 psi (2 to 10 bar) Media Filtered Compressed Air (Lubricated or Non-Lubricated) Solenoid Voltage 120 V AC, 50/60 Hz (specified by the "-10" suffix) Electrical Connection Standard Plug Connector (DIN 43650 Form A) Special Features Pilot Light & Manual Override ("-PLC" suffix): - Indicator Light: Shows energization status. - Manual Override Button: Allows manual shifting for setup and troubleshooting. Standards CE, RoHS Compliant Body Material Die-Cast Zinc Seal Material NBR (Nitrile Rubber) Temperature Range Media & Ambient: 14° to 140°F (-10° to 60°C) Flow Coefficient (Cv) Approximately 1.8 Mounting Base-Mounted

Technical Parameters Parameter Specification Product Model XC-CPU101-C256K Product Family Eaton XC-100 Programmable Logic Controller (PLC) Type Compact CPU Module with Integrated I/O User Program Memory 256 KB Data Memory 64 KB (Typical value for this family) Integrated I/O - 14x Digital Inputs (24 V DC Sink/Source) - 10x Digital Outputs (Relay, 2 A) Program Execution Speed ~0.15 µs per binary instruction (Typical) Communication Ports - 1x RS-232 (COM1) for programming and HMI - 1x RS-485 (COM2) for networking (Modbus RTU, etc.) Expansion Capability Supports connection of up to 7 expansion I/O modules (XC-200 series) Real-Time Clock (RTC) Yes (With battery backup for time retention) Programming Software Eaton XV-103 (SoMachine Basic / EcoStruxure Machine Basic) Programming Languages Ladder Diagram (LD), Function Block Diagram (FBD), Instruction List (IL) Supply Voltage 24 V DC (Typically via the base connector) Physical Design Modular, DIN-rail mountable

Technical Parameters Parameter Specification Product Model XNE-16DO-24VDC-0.5A-P Product Family Eaton XN System (Electronic Module) Module Type Digital Output Module Number of Channels 16 Output Type Sourcing (PNP) Output Voltage 24 V DC (Nominal) Load Current per Channel 0.5 A (Maximum) Total Module Current 4 A (Maximum, sum of all channels) Short-Circuit Protection Yes (Per channel, electronically) Load Type Resistive, Inductive, Lamp Load Isolation Channel-to-Bus: Yes (Optically isolated) Connection Method Removable screw terminal block Module Power Supply 24 V DC (via the XN system base or terminal block) Status Indicators - PWR (Power): Green LED - SF (System Fault): Red LED - CHx (Channel Status): Green LED per channel IP Rating IP20 (for installation inside a control cabinet) Mounting On an XN system base unit, mounted on a standard 35 mm DIN rail Operating Temperature -25 °C to +60 °C (-13 °F to 140 °F) Standards & Certifications CE, UL, cULus, RoHS compliant

Technical Parameters Parameter Specification Product Model XC-CPU201-EC256K-8DI-6DO Product Family Eaton XC-200 Programmable Logic Controller (PLC) Type Compact CPU Module with Integrated I/O and Ethernet User Program Memory 256 KB Data Memory 128 KB Integrated I/O - 8x Digital Inputs (24 V DC, Sink/Source) - 6x Digital Outputs (24 V DC, Sourcing (PNP), 0.5 A) Program Execution Speed ~0.04 µs per binary instruction (Typical, faster than XC-100 series) Communication Ports - 1x Ethernet (RJ45) for programming, HMI, and PLC-to-PLC communication - 1x RS-485 for networking (Modbus RTU, etc.) Ethernet Protocol MODBUS TCP Expansion Capability Supports connection of up to 7 expansion I/O modules (XC-200 series) Real-Time Clock (RTC) Yes Programming Software EcoStruxure Machine Expert - Basic (formerly SoMachine Basic) Programming Languages Ladder Diagram (LD), Function Block Diagram (FBD), Instruction List (IL) Supply Voltage 24 V DC Physical Design Modular, DIN-rail mountable

Technical Parameters Category Specification Product Model XC-CPU201-EC256K-8DI-6DO Product Family Eaton XC-200 PLC Series CPU Performance 256 KB User Program Memory 128 KB Data Memory ~0.04 μs per binary instruction Integrated I/O • 8x Digital Inputs (24V DC, Sink/Source) • 6x Digital Outputs (24V DC, Sourcing/PNP, 0.5A) Communication Interfaces • 1x Ethernet (RJ45) - MODBUS TCP • 1x RS-485 - MODBUS RTU/ASCII Expansion Capability Up to 7 XC-200 series expansion modules Programming EcoStruxure Machine Expert - Basic Ladder Diagram (LD) Function Block Diagram (FBD) Instruction List (IL) Power Supply 24V DC Operating Temperature 0°C to +55°C Storage Temperature -25°C to +70°C Relative Humidity 5% to 95% (non-condensing) Vibration Immunity 2g (10-150 Hz) Shock Immunity 15g (11ms duration) Isolation 500V AC (Communication ports) 1500V AC (I/O circuits) Standards Compliance CE, cULus, RoHS, WEEE

Technical Parameters Parameter Specification Product Model EASY-E4-AC-12RC1 Product Family Eaton EASY-E4 Controller Type Micro-PLC (Programmable Logic Controller) Supply Voltage 100 - 240 V AC (Wide Range) Integrated I/O Total: 20 I/O Points - 12x Digital Inputs (24 V DC, Sink/Source) - 8x Relay Outputs: • 6x Changeover Contacts (CO) • 2x Normally Open Contacts (NO) Relay Contact Rating - 6A @ 250V AC (for CO contacts) - 2A @ 250V AC (for NO contacts) Program Memory Typically ~4 KB (for EASY-E4 series) Data Memory Typically ~2 KB (for EASY-E4 series) Programming - EASY-SOFT PC Software - Direct Device Programming via built-in display and keys Programming Language Function Block Diagram (FBD) / Circuit Diagram style Real-Time Clock (RTC) Yes Communication - EASY-LINK (for networking multiple EASY controllers) - USB Port for programming (on specific variants) Display Backlit LCD for status, values, and diagnostics Mounting Standard 35 mm DIN rail Operating Temperature -25 °C to +55 °C (-13 °F to 131 °F)

Technical Parameters Parameter Specification Product Model EASY-E4-DC-12RC1 Product Family Eaton EASY-E4 Controller Type Micro-PLC (Programmable Logic Controller) Supply Voltage 24 V DC Integrated I/O Total: 20 I/O Points - 12x Digital Inputs (24 V DC, Sink/Source) - 8x Relay Outputs: • 6x Changeover Contacts (CO) • 2x Normally Open Contacts (NO) Relay Contact Rating - 6A @ 250V AC (for CO contacts) - 2A @ 250V AC (for NO contacts) Program Memory Typically ~4 KB (for EASY-E4 series) Data Memory Typically ~2 KB (for EASY-E4 series) Programming - EASY-SOFT PC Software - Direct Device Programming via built-in display and keys Programming Language Function Block Diagram (FBD) / Circuit Diagram style Real-Time Clock (RTC) Yes Communication - EASY-LINK (for networking multiple EASY controllers) - USB Port for programming (on specific variants) Display Backlit LCD for status, values, and diagnostics Mounting Standard 35 mm DIN rail Operating Temperature -25 °C to +55 °C (-13 °F to 131 °F) Relative Humidity 95% (non-condensing)

Technical Parameters Category Specification Product Model EASY-E4-DC-12TC1 Product Family Eaton EASY-E4 Controller Series Controller Type Micro PLC with Integrated Temperature Control Power Supply 24V DC Integrated I/O • 12x Digital Inputs (24V DC) • 8x Relay Outputs (6x CO + 2x NO) Relay Ratings • 6A @ 250V AC (CO contacts) • 2A @ 250V AC (NO contacts) Temperature Inputs 2 channels for thermocouple or RTD sensors Temperature Ranges -200°C to 1800°C (depending on sensor type) Control Algorithms • ON/OFF control • PID control • Heating/Cooling control Program Memory 4 KB Data Memory 2 KB Real-Time Clock Integrated Programming EASY-SOFT software or front panel Programming Language Function Block Diagram (FBD) Display Backlit LCD with status indicators Communication EASY-LINK network capability Mounting 35 mm DIN rail Operating Temperature -25°C to +55°C Protection Rating IP20 (for cabinet installation)
