Technical Parameters Parameter Specification Product Model FY-EM-T02-02 Product Family Eaton F&F (Field & Function) Series Device Type Programmable Energy & Power Monitoring Relay Supply Voltage 24 - 240 V AC/DC (Wide Range, Auto-sensing) Measurement Inputs Voltage: Up to 480 V AC (via potential transformer) Current: 0-1A or 0-5A AC (via current transformer) Measurement Channels 2 independent channels Measured Parameters Voltage (V), Current (I), Active Power (kW), Apparent Power (kVA), Reactive Power (kvar), Power Factor (cos φ), Frequency (Hz), Energy (kWh, kvarh) Outputs 2x Changeover Relay Contacts (CO) - Rated Load: 6 A / 250 V AC Communication Interface RS-485 with Modbus RTU protocol Programming & Display - Front-face buttons and LCD display - Configuration software (e.g., Eaton SOFISYS) Primary Functions - Under/Over voltage & current monitoring - Power & Power Factor monitoring - Energy (kWh) metering & tariff control - Asymmetry & Phase Sequence monitoring - Timer & Threshold functions Mounting Standard 35 mm DIN rail Operating Temperature -25 °C to +55 °C (-13 °F to 131 °F) Safety Standards IEC/EN 61010-1, UL 508

Technical Parameters Parameter Specification Product Model XIOC-8AI-12 Compatible Systems Eaton XP, XR, and XC Series PLCs Module Type Analog Input Module Number of Channels 8 Input Type Voltage Input Range 0 to 10 V DC (Standard factory default; other ranges like ±10V may be configurable) Resolution 12-bit (or higher, depending on the specific PLC system's processing capabilities) Conversion Time Typically a few milliseconds per channel (varies based on the master PLC) Connection Method Removable screw terminal block Isolation Channel-to-Bus: Yes (Opto-coupled) Channel-to-Channel: Typically not isolated Power Supply Powered by the 5 V DC backplane of the PLC rack/base unit Status Indicators - RUN/PWR: Green LED (indicates operational status) - ERR: Red LED (indicates a fault) - Ix: Status LED per channel (may be present) Mounting Mounts onto the XP/XR/XC series base unit or rack Operating Temperature 0 °C to +55 °C (32 °F to 131 °F)

Technical Parameters Parameter Specification Product Model XIOC-8DI Compatible Systems Eaton XP, XR, and XC Series PLCs Module Type Digital Input Module Number of Channels 8 Input Type 24 V DC, Sink/Source (Universal) Nominal Input Voltage 24 V DC Rated Input Voltage "1" 15 V DC to 30 V DC Rated Input Voltage "0" -30 V DC to 5 V DC Input Current Typically 3-5 mA per input (at 24 V DC) Connection Method Removable screw terminal block Isolation Channel-to-Bus: Yes (Optically isolated) Power Supply Powered by the 5 V DC backplane of the PLC rack/base unit Status Indicators - RUN/PWR: Green LED (indicates operational status) - ERR: Red LED (indicates a fault) - INx: Green LED per channel (indicates input status) Mounting Mounts onto the XP/XR/XC series base unit or rack Operating Temperature 0 °C to +55 °C (32 °F to 131 °F) Standards CE, cULus, RoHS

Technical Parameters Category Specification Product Model ERC3-DO-CB-A-V100BI Product Family Eaton ERC3 System Module Type Digital Output Communication Board Output Configuration 4 independent channels Output Type Relay contacts (Changeover) Contact Rating 16A @ 250V AC Load Type Resistive, inductive, lamp loads Control Voltage 230V AC (via main unit) - Communication KNX TP1 (Twisted Pair) Protocol KNX Standard Programming ETS (KNX Engineering Tool Software) Configuration Application program "A" Mounting DIN rail (within ERC3 enclosure) Operating Temperature -5°C to +45°C Storage Temperature -25°C to +70°C Relative Humidity ≤ 93% (non-condensing) Protection Class IP20 (when installed in enclosure) Standards Compliance KNX Standard, EN 50090, EN 60669-1 Electrical Characteristics Rated Impulse Voltage: 4kV Dielectric Strength: 2.5kV AC (50Hz) Insulation Resistance: >100MΩ Power Consumption: <1W (standby), <2W (active) Communication Features KNX Address: Individual and group addressing Telegram Rate: Up to 9600 bps Bus Connection: KNX red/grey terminal Configuration: Via ETS software Application Functions Lighting control (on/off, dimming) Blind/shutter control Heating control Ventilation control Signal functions

Technical Parameters Parameter Specification Product Model NZM1-XA110-130AC/DC Product Family Eaton NZM1 Circuit Breaker Accessory Device Type Under-Voltage Release / Shunt Trip Release Rated Operational Voltage (Ue) 110 - 130 V AC/DC (Wide Range) Power Consumption Approx. 10 W / 20 VA (at moment of tripping) Mounting Position Can be mounted on either the left or right side of the NZM1 breaker Compatibility Designed for Eaton NZM1 Molded Case Circuit Breakers Function Remotely trips the circuit breaker when the control voltage is applied. Electrical Life Typically > 1000 operations (at rated voltage) Connection Via screw terminals on the accessory Standards IEC/EN 60947-2

Technical Parameters Parameter Specification Product Model MATSG-630/3 Product Family Eaton MATSG Automatic Transfer Switches Type 3-Pole Automatic Transfer Switch Rated Operational Current (Ie) 630 A Rated Insulation Voltage (Ui) 690 V AC Rated Operational Voltage (Ue) 400 V AC / 50 Hz Short-Circuit Withstand Typically 50 kA (Icw) according to IEC 60947-6-1 Utilization Category AC-33A (for motors or mixed loads) Mechanical Life Several thousand operations Electrical Life Typically 1000+ operations at rated current Control Voltage Standard options: 24 V DC, 110 V AC, 220 V AC Status Indication Source 1 ON, Source 2 ON, Intermediate (OFF) Position Standards & Certifications IEC/EN 60947-6-1, CE Marked

Technical Parameters Category Specification Product Model MATSG-200/4 Product Family Eaton MATSG Automatic Transfer Switch Series Rated Current 200A Number of Poles 4 Rated Operational Voltage 400V AC Rated Insulation Voltage 690V AC Rated Frequency 50/60 Hz Short-Time Withstand Current 10kA (1 second) Utilization Category AC-33A Mechanical Life 10,000 operations Electrical Life 1,000 operations at rated current Control Voltage 24V DC / 230V AC (depending on configuration) Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (for enclosure mounting) Standards Compliance IEC 60947-6-1, CE

Technical Parameters Category Specification Product Model MATSG-63/4 Product Family Eaton MATSG Automatic Transfer Switch Series Rated Current 63A Number of Poles 4 Rated Operational Voltage 400V AC Rated Insulation Voltage 690V AC Rated Frequency 50/60 Hz Short-Time Withstand Current 6kA (1 second) Utilization Category AC-33A Mechanical Life 10,000 operations Electrical Life 1,000 operations at rated current Control Voltage 24V DC / 230V AC (depending on configuration) Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (for enclosure mounting) Standards Compliance IEC 60947-6-1, CE

Technical Parameters Category Specification Product Model MATS G-250/4 Product Family Eaton MATS G Automatic Transfer Switch Series Rated Current 250A Number of Poles 4 Rated Operational Voltage 400V AC Rated Insulation Voltage 690V AC Rated Frequency 50/60 Hz Short-Time Withstand Current 15kA (1 second) Utilization Category AC-33A Mechanical Life 8,000 operations Electrical Life 800 operations at rated current Control Voltage 24V DC/230V AC (configurable) Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (requires enclosure) Standards Compliance IEC 60947-6-1, CE

Technical Parameters Category Specification Product Model 5PX2200IRT2UG2 Product Family Eaton 5PX UPS Series Topology Double Conversion Online Rated Capacity 2200VA/2000W Input - Voltage 200-240V AC - Frequency 50/60 Hz (auto-sensing) - Input Connector IEC 320 C14 Output - Voltage 200-240V AC - Frequency 50/60 Hz (±0.5% synchronous) - Waveform Pure Sine Wave - Output Connectors (8) IEC 320 C13 Battery - Type Sealed Lead-Acid (SLA) - Runtime Varies with load (typical 10-20 min at full load) - Recharge Time 3 hours to 90% capacity - Battery Module User-replaceable hot-swappable Physical Specifications - Form Factor 2U Rack-mount - Dimensions 88mm × 482mm × 660mm (H×W×D) - Weight 22.5 kg (with batteries) Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <45 dBA at 1 meter
