Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series EASY E4 Product Model EASY-E4-DC-8TE1 Product Type Programmable Control Relay Power Supply 24 V DC Number of Digital Inputs 8 Number of Relay Outputs 4 (typically) Display Text Display (for programming and diagnostics) Programming Via front panel or EASY-SOFT PC software (Ladder Diagram, Function Block Diagram) Program Memory Sufficient for complex switching programs Integrated Functions Timers, Counters, Real-Time Clock, Logic functions Mounting DIN Rail Mounting (35 mm) Connection Removable screw terminal blocks

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series SL7 Product Model / Catalog Number SL7-BL24-Y / 171388 Product Type 22mm Bi-Color LED Indicator Light Mounting Diameter 22 mm Lens Color Yellow (Primary indicated color) Light Source Bi-color LED (Capable of displaying two colors, e.g., Yellow and Green) Supply Voltage 24 V DC LED Technology High-brightness, long-life LED Electrical Connection Pre-wired leads or terminal base (specific type should be verified) Ingress Protection (IP) IP65 (front of panel when properly mounted) Approvals / Certifications CE, cULus

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series XN Product Model XNE-GWBR-CANOPEN Product Type Communication Gateway / Bus Coupler Primary Function Protocol conversion between XNE-BUS and CANopen Supported Protocols • XNE-BUS (to XN PLC CPU) • CANopen (to field devices) CANopen Conformance Supports CIA DRP-303-1 version 4.02 (or similar) Data Exchange Maps process data between XN system and CANopen network Mounting DIN Rail Mounting (on XN base unit) Power Supply Powered via the XN base unit Status Indication LEDs for power, network status, and error diagnosis Compatibility Eaton XN Series PLCs

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series P5 Product Model P5-125/V/SVB/HI10 Product Type Switched-Mode Power Supply (SMPS) with SVB and High Inrush Capability Output Power 125 W Output Voltage 24 V DC Rated Output Current 5.2 A Input Voltage Range 85...264 V AC (wide range) / 120...370 V DC Input Frequency 47...63 Hz Key Feature 1 Static Voltage Buffer (SVB) - Holdup time typically ≥ 20 ms after mains failure Key Feature 2 High Inrush Capability (HI10) - Can supply up to 10x the rated current (52A) for 100 ms at 40°C to start demanding loads. Efficiency High efficiency (typically > 93%) Mounting DIN Rail Mounting (35 mm) Connection Removable screw terminal block Operating Temperature -25 °C ... +70 °C (with derating) Approvals / Certifications CE, cULus, ATEX

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series NZM Product Model NZM3-XMC-MB Product Type Motor Protection Module (with Manual Reset) Compatibility Designed for specific frame sizes of NZM Series Circuit Breakers Protection Functions • Thermal Overload Protection (Class 10) • Phase Failure Protection • Jamming / Locked Rotor Protection Reset Mechanism Manual Reset (MB) Status Indication Trip Indicator (Flag) Control Supply Self-powered (derived from the main circuit) Mounting Side-mounted onto the NZM circuit breaker Connection Screw terminals for control wiring (e.g., trip output to contactor)

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series CAN-IO Modules (for CANopen networks) Product Model CAN-4AI/UI Product Type 4-Channel Analog / Universal Input Module Communication Protocol CANopen (CiA DRP-404) Number of Channels 4 Input Types (Configurable per channel) • Voltage: 0-10V, ±10V • Current: 0-20mA, 4-20mA • Resistance: e.g., for Pt100/1000 RTDs Resolution 16-bit Electrical Isolation Channel-to-channel and channel-to-bus isolation Power Supply 24 V DC (typical for fieldbus modules) Mounting DIN Rail Mounting (35 mm) Connection Removable screw terminal block Status Indication LEDs for power and network status

Technical Parameters Parameter Category Specification Details General Model EU5C-SWD-PF2-1 The full part number as listed. Product Line Crouse-Hinds Series / Power Xpert Metering Part of Eaton's comprehensive metering solution. Electrical Characteristics System Type Single-Phase, 2-Wire (1P2W) Rated Voltage 120/240V AC Maximum Voltage 277V AC Current Rating 50 Amps (Typically used with a 50:5 A current transformer - CT) Frequency 50/60 Hz Measurement Capabilities Voltage (V) Yes Current (I) Yes (via external Current Transformer) Power (kW, kVA) Yes (Real and Apparent) Energy (kWh, kVAh) Yes Power Factor (PF) Yes (as indicated by "-PF2-" in the model number) Frequency (Hz) Yes Demand Yes Communication Protocol Wi-Fi (IEEE 802.11 b/g/n) Data Interface Integrated Wi-Fi radio for network connection. Physical & Environmental Mounting Designed for hardwired installation into a dedicated meter socket within an Eaton enclosure or panelboard. Enclosure Rating The meter itself is typically installed inside an enclosure, which provides the IP rating. Standards & Compliance Accuracy ANSI C12.20 Class 0.5 (Revenue Grade Accuracy) Safety Standards UL Listed, CE Marked

Technical Parameters Parameter Category Specification Details General Model EU5C-SWD-DP Form 4S, Three-Phase, 4-Wire Meter with Advanced Features ("DP") Product Line Eaton Crouse-Hinds Series / Power Xpert Metering Electrical Characteristics System Type Three-Phase, 4-Wire (3P4W - Wye) Rated Voltage 347/600V AC (Line-to-Line) Current Input Via external Current Transformers (CTs). Common secondary ratings: 5A or 1A. Frequency 50/60 Hz Measurement Capabilities Basic Parameters Volts (L-N, L-L), Amps, Frequency, Real/Reactive/Apparent Power (kW, kvar, kVA), Power Factor, Demand (kW, kVA, A) Energy Import/Export kWh, kvarh Power Quality Total Harmonic Distortion (THD) for V & I, Individual Harmonics, Min/Max/Average recordings, Sag/Swell detection. Communication Communication Ports The "DP" variant typically includes multiple ports, often an Ethernet port and a RS-485 serial port. Protocols Commonly supports Modbus TCP/IP (over Ethernet), BACnet IP (over Ethernet), and Modbus RTU (over RS-485). Display Integrated backlit LCD, often graphical. Accuracy Standard ANSI C12.20 Class 0.2 (Revenue Grade) Voltage & Current ±0.1% of Reading Power & Energy ±0.2% of Reading Physical & Environmental Mounting Hardwired installation into a dedicated meter socket within an Eaton enclosure. Operating Temperature -40°C to +70°C (-40°F to +158°F)

Technical Parameters Parameter Category Specification Details General Model DIL-SWD-32-002 DIL Series, Side-Mount, Screw Terminal, 2NO Contact Block Compatible Main Devices Eaton DIL Contactors and Relays Must be used with specific DIL series models. Contact Characteristics Number of Contacts 2 NO (Normally Open) Contact Type Screw terminal. Rated Operational Current (Ith) Typically 6 A (e.g., at 250V AC). Rated Thermal Current (Ithe) 10 A. Rated Operational Voltage (Ue) Up to 250V AC / 30V DC. Mechanical Characteristics Mounting Side-mounted onto compatible DIL contactors/relays. Electrical Durability Typically > 10 million operations. Mechanical Durability Typically > 20 million operations. Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, CE, IEC/EN 60947-5-1.

Technical Parameters Parameter Category Specification Details General Model DIL-SWD-32-001 DIL Series, Side-Mount, Screw Terminal, 1NO+1NC Contact Block Compatible Main Devices Eaton DIL Contactors and Relays Must be used with specific DIL series models. Contact Characteristics Number of Contacts 1 NO (Normally Open) + 1 NC (Normally Closed) - One Form C (Changeover) contact. Contact Type Screw terminal. Rated Operational Current (Ith) Typically 6 A (e.g., at 250V AC). Rated Thermal Current (Ithe) 10 A. Rated Operational Voltage (Ue) Up to 250V AC / 30V DC. Mechanical Characteristics Mounting Side-mounted onto compatible DIL contactors/relays. Electrical Durability Typically > 10 million operations. Mechanical Durability Typically > 20 million operations. Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, CE, IEC/EN 60947-5-1.
