Parameter Specification Product Series PKZ Zero (Moeller) Brand Eaton Product Type Thermal Overload Relay Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 690 V AC Application 3-phase AC Motor Protection Standards IEC/EN 60947-4-1, IEC/EN 60947-5-1 Protection Functions Overload, Phase Unbalance, Phase Loss (Single-Phasing) Ambient Temperature Compensation Yes Reset Mode Manual (Standard), Automatic (optional on some models) Mounting Snap-on mounting to Eaton XT/XT1 series contactors Auxiliary Contacts Typically 1 NO (97-98) + 1 NC (95-96) Trip Class Class 10 (Standard for standard duty motors)

Parameter Specification Product Series PL10 Brand Eaton Product Type Miniature Circuit Breaker (MCB) Number of Poles 2 Poles (2P) Rated Current (In) 10 A Tripping Characteristic C Curve (Instantaneous trip current: 5 to 10 times In) Rated Operational Voltage (Ue) 230/400 V ~ Rated Insulation Voltage (Ui) 500 V ~ Rated Impulse Withstand Voltage (Uimp) 6 kV Rated Breaking Capacity (Icn) 10 kA (at 230/400V AC according to IEC/EN 60898-1) Standards IEC/EN 60898-1 Electrical Life 10,000 cycles Mechanical Life 20,000 cycles Terminal Torque 2.0 N·m Mounting DIN Rail Mounting (35mm symmetrical rail according to EN 60715) Net Weight Approx. 0.2 kg (May vary)

Parameter Specification Product Series PLHT Brand Eaton Product Type Miniature Circuit Breaker (MCB) Number of Poles 3 Poles (3P) Rated Current (In) 125 A Tripping Characteristic C Curve (Instantaneous trip current: 5 to 10 times In) Rated Operational Voltage (Ue) 400 V / 415 V ~ Rated Insulation Voltage (Ui) 500 V ~ Rated Impulse Withstand Voltage (Uimp) 6 kV Rated Breaking Capacity (Icn) 10 kA / 15 kA (at 400/415V AC) Please check the specific datasheet for the confirmed value. Utilization Category A Standards IEC/EN 60898-1, IEC/EN 60947-2 Electrical Life 10,000 cycles Mechanical Life 20,000 cycles Terminal Torque 3.5 - 4.0 N·m （For larger cable sizes, please confirm with datasheet） Mounting DIN Rail Mounting (35mm symmetrical rail according to EN 60715) Net Weight Approx. 0.7 kg (May vary)

Parameter Specification Product Series PLHT Brand Eaton Product Type Miniature Circuit Breaker (MCB) Number of Poles 4 Poles (4P) Rated Current (In) 80 A Tripping Characteristic C Curve (Instantaneous trip current: 5 to 10 times In) Rated Operational Voltage (Ue) 400 V / 415 V ~ Rated Insulation Voltage (Ui) 500 V ~ Rated Impulse Withstand Voltage (Uimp) 6 kV Rated Breaking Capacity (Icn) 10 kA / 15 kA (at 400/415V AC) Please check the specific datasheet for the confirmed value. Utilization Category A (For cable protection) Standards IEC/EN 60898-1, IEC/EN 60947-2 Electrical Life 10,000 cycles Mechanical Life 20,000 cycles Terminal Torque 3.0 N·m (For copper cables 25mm² max) Mounting DIN Rail Mounting (35mm symmetrical rail according to EN 60715) Net Weight Approx. 0.8 kg (May vary)

Technical Parameters Parameter Specification Product Series Eaton NZMN1 Product Type Molded Case Circuit Breaker (MCCB) Rated Operational Current (Ie) 32 A Number of Poles 3 Trip Unit Type Fixed Thermal-Magnetic Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 800 V AC Rated Frequency 50/60 Hz Short-Circuit Breaking Capacity (Icu) Typically 25 kA (at 400V AC per IEC 60947-2) Utilization Category A (for non-specific applications) Mounting Fixed Mounting (DIN Rail or panel) Terminal Type Screw clamp Standards Compliance IEC 60947-2

Technical Parameters Parameter Specification Product Series Eaton NZMN1 Product Type Molded Case Circuit Breaker (MCCB) Rated Operational Current (Ie) 20 A Number of Poles 3 Trip Unit Type Fixed Thermal-Magnetic Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 800 V AC Rated Frequency 50/60 Hz Short-Circuit Breaking Capacity (Icu) Typically 25 kA (at 400V AC per IEC 60947-2) Utilization Category A (for non-specific applications) Mounting Fixed Mounting (DIN Rail or panel) Terminal Type Screw clamp Standards Compliance IEC 60947-2

Technical Parameters Parameter Specification Product Series Eaton NZMN1 Product Type Molded Case Circuit Breaker (MCCB) Rated Operational Current (Ie) 50 A Number of Poles 3 Trip Unit Type Fixed Thermal-Magnetic Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 800 V AC Rated Frequency 50/60 Hz Short-Circuit Breaking Capacity (Icu) Typically 25 kA (at 400V AC per IEC 60947-2) Utilization Category A (for non-specific applications) Mounting Fixed Mounting (DIN Rail or panel) Terminal Type Screw clamp Standards Compliance IEC 60947-2

Technical Parameters Parameter Specification Product Series Eaton NZMN Product Type Molded Case Circuit Breaker (MCCB) Rated Operational Current (Ie) 80 A Trip Unit Type Fixed Thermal-Magnetic Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 800 V AC Rated Frequency 50/60 Hz Short-Circuit Breaking Capacity (Icu) Typically 10-25 kA (depending on specific variant and voltage) Mounting Fixed Mounting (DIN Rail or panel) Terminal Type Screw clamp Standards Compliance IEC 60947-2

Technical Parameters Parameter Specification Product Series Eaton NZMN1 Product Type Molded Case Circuit Breaker (MCCB) Rated Operational Current (Ie) 100 A Number of Poles 3 Trip Unit Type Fixed Thermal-Magnetic Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 800 V AC Rated Frequency 50/60 Hz Short-Circuit Breaking Capacity (Icu) Typically 25 kA (at 400V AC per IEC 60947-2) Utilization Category A (for non-specific applications) Mounting Fixed Mounting (DIN Rail or panel) Terminal Type Screw clamp Standards Compliance IEC 60947-2

Technical Parameters Parameter Specification Product Series Eaton NZM4 Product Type Electronic Trip Unit with Communication Rated Current (In) 208-240A (as indicated by model suffix) Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 1000 V AC Rated Frequency 50/60 Hz Protection Functions L (Long-time), S (Short-time), I (Instantaneous), G (Ground Fault) Communication Protocol Modbus RTU (via RS-485 interface) Measurement Capabilities Current, Voltage, Power, Energy, Power Factor, Frequency Display Integrated LCD display Setting Adjustment Programmable via front interface or communication network Mounting Integrated into compatible NZM4 circuit breaker frame Standards Compliance IEC 60947-2
