Key Parameters Item Specification / Description Valve Type Electro-proportional flow control cartridge valve (poppet type) Style / Orientation B style — side-in, nose-out Function (de-energized) Port-to-port flow blocked (normally closed) Function (energized) Flow allowed, rate proportional to coil current Cartridge / Cavity NG16, cavity C-16-3S Maximum Working Pressure 280 bar Rated Flow Capacity 0–160 L/min Operating Fluid Anti-wear hydraulic oils; standard Buna-N seals, Viton optional Fluid Viscosity Range 10–800 cSt Operating Temperature Range –30 °C to +90 °C Internal Leakage (max) ≤ 10 cm³/min at 140 bar Coil Supply Voltage 24 V DC Coil Current for Max Flow ~0.7 A @ 24 V DC Recommended Filtration 15/13/11 (high pressure) or 17/15/12 (lower pressure)

Key Parameters Item Specification / Description Valve Type Proportional pressure-compensated flow control cartridge valve Series / Size DGMPC‑3 (NG6 / CETOP 3 / ISO 4401-03 interface) Function Controls flow proportionally based on electrical input; maintains stable flow under varying load pressure Maximum Flow 40 L/min (approx.) Maximum Operating Pressure 350 bar (≈ 5000 psi) Pilot Pressure Requirement 20–30 bar typical (for spool operation) Control Signal 0–10 V DC or 4–20 mA (depending on coil/driver) Spool Type ABK (proportional spool) Seal Material Buna-N standard; Viton optional Fluid Compatibility Mineral-based hydraulic oils, anti-wear oils Recommended Filtration 17/15/12 µm or better Operating Temperature –20 °C to +70 °C Mounting Type Screw-in cartridge, manifold / subplate mount Electrical Connector Typically 7-pin connector (depends on variant)

Key Parameters Parameter Specification / Description Valve Type Solenoid-operated directional control valve (5/3-way) Series / Size DG4V-5M (subplate / modular mount) Spool Type / Center 2AJ spool, closed center Maximum Operating Pressure 350 bar (≈ 5000 psi) Maximum Flow Rate 160 L/min (≈ 42 US gpm) Coil Type / Voltage KUP5 solenoid, 24 V DC standard Electrical Connection 7-pin DIN connector (variant dependent) Seal Material H7 (Buna-N standard, compatible with mineral oil) Metering Function Meter-in or meter-out, depending on spool configuration Fluid Compatibility Mineral-based hydraulic oils, anti-wear oils Fluid Cleanliness Recommended 17/15/12 µm (or better) Operating Temperature –20 °C to +70 °C Mounting Subplate / manifold mount (ISO 4401 / CETOP 5)

Key Parameters Parameter Specification / Description Valve Type Proportional flow control cartridge valve Series / Size DGMC‑3 (NG6 / CETOP 3 / ISO 4401-03) Function Regulates flow proportionally based on electrical input; maintains consistent flow under varying load pressure Maximum Flow 40 L/min (approx.) Maximum Operating Pressure 350 bar (≈ 5000 psi) Pilot Pressure Requirement 20–30 bar typical (for spool operation) Electrical Control Signal 0–10 V DC or 4–20 mA (depending on coil/driver) Spool Type BT spool (proportional) Seal Material Buna-N standard; Viton optional Fluid Compatibility Mineral-based hydraulic oils, anti-wear oils Recommended Filtration 17/15/12 µm or better Operating Temperature –20 °C to +70 °C Mounting Type Screw-in cartridge, manifold / subplate mount Electrical Connector Typically 7-pin connector (variant dependent)

Key Parameters Parameter Specification / Description Valve Type Solenoid-operated directional control valve, 2-way, 2-position Series SBV series Function (de-energized) Normally closed — blocks flow Function (energized) Opens to allow flow Rated Flow 12 L/min (approx.) Maximum Operating Pressure 210 bar (≈ 3000 psi) Coil Voltage 24 V DC Electrical Connector DIN 43650-A / ISO 4400 standard connector Seal Material Buna-N (standard) Fluid Compatibility Mineral-based hydraulic oils, anti-wear oils Fluid Cleanliness Recommended 18/16/13 µm or better Operating Temperature –20 °C to +70 °C Mounting Type Subplate / manifold mount Port Size 1/4″ (or corresponding NG1 / CETOP 1 interface)

Key Parameters Parameter Specification / Description Valve Type Solenoid-operated directional control valve, 2-way, 2-position Series SBV series Function (de-energized) Normally open — allows flow Function (energized) Closes to block flow Rated Flow 12 L/min (approx.) Maximum Operating Pressure 210 bar (≈ 3000 psi) Coil Voltage 24 V DC Electrical Connector DIN 43650-A / ISO 4400 standard connector Seal Material Buna-N (standard) Fluid Compatibility Mineral-based hydraulic oils, anti-wear oils Fluid Cleanliness Recommended 18/16/13 µm or better Operating Temperature –20 °C to +70 °C Mounting Type Subplate / manifold mount Port Size 1/4″ (or corresponding NG1 / CETOP 1 interface)

Key Parameters Parameter Specification / Description Valve Type Proportional flow control cartridge valve Series / Size DGMX2‑3 (NG6 / CETOP 3 / ISO 4401-03 interface) Function Regulates flow proportionally based on electrical input; maintains stable flow under varying load pressure Maximum Flow 40 L/min (approx.) Maximum Operating Pressure 350 bar (≈ 5000 psi) Pilot Pressure Requirement 20–30 bar typical (for spool operation) Electrical Control Signal 0–10 V DC or 4–20 mA (depending on coil/driver) Spool Type PB (proportional) Seal Material Buna-N standard; Viton optional Fluid Compatibility Mineral-based hydraulic oils, anti-wear oils Recommended Filtration 17/15/12 µm or better Operating Temperature –20 °C to +70 °C Mounting Type Screw-in cartridge, manifold / subplate mount Electrical Connector Typically 7-pin connector (variant dependent)

Parameters Parameter Category Specification Product Type Variable Frequency Drive (VFD) / AC Drive Brand / Series Eaton DG1 Series Model Code DG17S4-018N50 Rated Output Power 18.5 kW (25 HP) Rated Output Current 38 A (at 400V) - Consult datasheet for full range Input Voltage 3-phase, 380 - 480 V AC, 50/60 Hz Output Voltage 0 to Input Voltage, 3-phase Frame Size 7S4 Control Method Sensorless Vector Control & V/Hz Control Key Features Built-in PID controller, PLC functionality, multiple digital & analog I/O, DC bus choke, keypad with display. Protection Features Overcurrent, Overvoltage, Undervoltage, Motor Overload, Short Circuit, Ground Fault, Heatsink Overtemperature. Communication Protocols Modbus RTU, BACnet MS/TP (on board). Optional cards for DeviceNet, PROFIBUS, EtherNet/IP. Typical Applications Pumps, Fans, Compressors, Conveyors, Mixers.

Key Parameters Product Type: Solenoid-Operated Directional Control Valve Brand: Eaton Series: DG4V Function: 4-way, 3-position Nominal Flow: 5 GPM (19 L/min) Maximum Operating Pressure: Typically 350 bar (5000 psi) Center Position Type: Closed Center (All ports blocked) Solenoid Type: Wet-armature, DC Coil Voltage: 12 V DC (as per C6 code) Port Size: Typically SAE 06 (Based on 5 GPM rating) Mounting: ISO 4401-03 (CETOP 3) standard interface Seal Material: Standard Nitrile (Buna-N). Option code may specify others like Viton.

Key Parameters Product Type: Sectional Control Valve Stack (One Section) Brand: Eaton Valve Series: KHDG5V5 Spool Configuration: 3-position, Float Center Power Beyond: Yes (standard with this spool type) Nominal Flow Rate: 80 L/min Maximum Operating Pressure: Typically up to 350 bar (varies by model and seals) Work Port Relief Valve: Included, fixed setting (e.g., ~210 bar) Actuation: Single Solenoid, Electrical Coil Voltage: 120V AC, 50/60 Hz System Type: Open Center
