Technical Parameters Power Supply Voltage: 24 V DC Digital Inputs: 12 inputs at 24 V DC Relay Outputs: 6 relay outputs Relay Output Rating: 8 A thermal per relay Rated Operational Voltage (Relay Contacts): Up to 250 V AC Heat Dissipation: Approximately 4 W Protection & Isolation Short-Circuit Protection: Requires external protection (e.g., B16 circuit breaker or 8 A slow-blow fuse) Isolation: Safe isolation between input circuits and relay contacts, compliant with industrial standards Wiring & Connections Wiring Capacity: Solid wire: 0.2–4.0 mm² (AWG 22–12) Flexible wire: 0.2–2.5 mm² Connection Method: Screw terminals Communication: easyLINK expansion interface Mechanical Specifications Mounting Type: 35 mm DIN rail Dimensions: Width: approx. 3.5 in Height: approx. 3 in Depth: approx. 4.5 in Weight: approx. 0.39 kg (0.86 lb) Environmental Specifications Operating Temperature: –25 °C to +55 °C Standards & Certifications: CE, UL, CSA, EN industrial control standards

Technical Parameters Parameter Specification Brand Eaton Product Model NZMN3-A450 Standard IEC 60947-2 Type Miniature Circuit Breaker (MCB) Number of Poles 3 Poles (3P) Rated Current (Iₙ) 50 A Tripping Characteristic / Curve Type C (Instantaneous trip: 5 to 10 x Iₙ) Rated Operational Voltage (Uₑ) 400 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 500 V AC Rated Impulse Withstand Voltage (Uᵢₘₚ) 6 kV Breaking Capacity (I꜀ᵤ) 10 kA (at 400V AC) Electrical Durability 10,000 cycles Mechanical Durability 20,000 cycles Terminal Capacity - Top & Bottom Terminals Solid: 50 mm² Stranded: 35 mm² Fine-stranded: 25 mm² Terminal Torque 3.0 N·m (Maximum) Mounting 35 mm DIN Rail (EN 60715) Degree of Protection IP20 (when installed in an enclosure) Ambient Temperature -25 °C to +60 °C (for reference, per standard) Approvals / Certifications CE, CCC, IEC 60947-2

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model NZMN3-A500 Standard IEC 60947-2 Type Miniature Circuit Breaker (MCB) Number of Poles 3 Poles (3P) Rated Current (Iₙ) 50 A Tripping Characteristic / Curve Type C (Instantaneous trip: 5 to 10 x Iₙ) Rated Operational Voltage (Uₑ) 400 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 500 V AC Rated Impulse Withstand Voltage (Uᵢₘₚ) 6 kV Breaking Capacity (I꜀ᵤ) 10 kA (at 400V AC) Electrical Endurance 10,000 cycles Mechanical Endurance 20,000 cycles Terminal Capacity - Top & Bottom Terminals Solid: 50 mm² Stranded: 35 mm² Fine-stranded: 25 mm² Terminal Torque 3.0 N·m (Maximum) Mounting 35 mm DIN Rail (EN 60715) Degree of Protection IP20 (when installed in an enclosure) Ambient Temperature -25 °C to +60 °C (for reference) Approvals / Certifications CE, CCC, IEC 60947-2

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model NZMN3-A630 Standard IEC 60947-2 Type Miniature Circuit Breaker (MCB) Number of Poles 3 Poles (3P) Rated Current (Iₙ) 63 A Tripping Characteristic / Curve Type C (Instantaneous trip: 5 to 10 x Iₙ) Rated Operational Voltage (Uₑ) 400 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 500 V AC Rated Impulse Withstand Voltage (Uᵢₘₚ) 6 kV Breaking Capacity (I꜀ᵤ) 10 kA (at 400V AC) Electrical Endurance 10,000 cycles Mechanical Endurance 20,000 cycles Terminal Capacity Solid: 50 mm² Stranded: 35 mm² Fine-stranded: 25 mm² Terminal Torque 3.0 N·m (Maximum) Mounting 35 mm DIN Rail (EN 60715) Degree of Protection IP20 (when installed in an enclosure) Ambient Temperature -25 °C to +60 °C (for reference) Approvals / Certifications CE, CCC, IEC 60947-2

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model DE1-124D3FN-N20N Product Type PLC Expansion I/O Module Compatible Series Eaton DE1 Series PLCs Number of Digital Inputs 16 Number of Digital Outputs 4 (Solid-state, DC) I/O Type Sinking/Sourcing (selectable per channel) Rated Supply Voltage 24 V DC (for inputs and outputs) Input Current Typically 3-5 mA per point (at 24V DC) Output Current 0.5 A per point (with a total module limit) Isolation Optical isolation between field side and logic side Connection Type Removable screw terminal block Status Indicators LED indicators for each input and output channel, and a module power/status LED Mounting 35 mm DIN Rail (EN 60715) Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34060NB-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 1.1 kW Horsepower (HP) 1.5 HP Output Current 3.0 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke (as indicated by "C" in model suffix) Control Method Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) standard Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34150NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 4.0 kW Horsepower (HP) 5 HP Output Current 7.5 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34110NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 1.5 kW Horsepower (HP) 2 HP Output Current 3.7 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34090NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 1.1 kW Horsepower (HP) 1.5 HP Output Current 2.8 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34075NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 0.75 kW Horsepower (HP) 1 HP Output Current 2.1 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS
