Technical Parameters Category Specification Model A22-RPV/KC/I Product Type Illuminated Pushbutton (Modular) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Rectangular Lens Color Green (as indicated by "V") Illumination Incandescent Bulb (typical for this vintage code) Contact Block KC (Typically 2 NO contacts) Contact Rating Typically 5A @ 250V AC Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 12V, 24V, 48V, 100V, 110V, 120V, 200V, 220V, 240V). Must be specified separately.

Technical Parameters Category Specification Model EMT6-DB(230V) Product Type Solid-State Soft Starter Rated Operational Voltage (Ue) 230V AC (for the main power terminals) Current Rating Frame DB (e.g., for motors up to 32A at 230V - Must verify exact current from datasheet) Control Supply Voltage Typically a separate value (e.g., 100-240V AC/DC) for the control circuit. Key Features Start Control Adjustable initial torque & ramp-up time. Stop Control Optional soft-stop (ramp-down). Protection Integrated overload, phase loss, and overcurrent protection. Control Method Voltage ramp control. Status Indication LED indicators for Power, Run, Fault, etc. Mounting DIN Rail or Panel Mount. Standards IEC/EN 60947-4-2, UL 508

Technical Parameters Category Specification Model M22-WRLK3-R Product Type Ultrasonic Proximity Sensor Housing Thread M22 x 1 Sensing Range Typically up to 600 mm (0.6 meters) or similar, programmable. Sensing Object Virtually any solid or liquid material (sound-reflective). Output Type Typically 1 PNP and 1 NPN output, programmable for NO/NC operation. Output Configuration 4-wire (2 for power supply, 1 PNP output, 1 NPN output). Supply Voltage 10-30V DC Current Consumption Typically < 30 mA Connection Type Fixed Cable (R), standard length (e.g., 2m). Housing Material Typically brass or stainless steel with PTFE/POM sensing face. IP Rating IP67 (Dust-tight and protected against temporary immersion) Key Features Programmability Teach-in function for easy setting of switching points. Temperature Compensation Built-in for stable performance in varying temperatures.

Technical Parameters Category Specification Model M22-DZ-B-GB14 Product Type 2-Wire AC Inductive Proximity Sensor Housing Thread M22 x 1 Sensing Distance 4 mm (Nominal) Output Type 2-wire AC Supply Voltage 20-253V AC, 50/60 Hz Rated Current Typically 5-200 mA (depending on model) Leakage Current Typically < 1.8 mA Connection Type Fixed Cable Housing Material Nickel-Plated Brass Target Material Ferrous Metals (e.g., Steel) IP Rating IP67 (Dust-tight and protected against temporary immersion)

Technical Parameters Category Specification Model M22-WRK3/K20 Product Type Ultrasonic Proximity Sensor Housing Thread M22 x 1 Sensing Range Defined by "/K20", typically up to 200 mm (0.2 meters). Sensing Object Virtually any solid or liquid material (sound-reflective). Output Type Typically 1 PNP and 1 NPN output, programmable for NO/NC operation. Output Configuration 4-wire (2 for power supply, 1 PNP output, 1 NPN output). Supply Voltage 10-30V DC Current Consumption Typically < 30 mA Connection Type Fixed Cable or Quick-Disconnect, defined by suffix. Housing Material Typically brass or stainless steel with PTFE/POM sensing face. IP Rating IP67 (Dust-tight and protected against temporary immersion) Key Features Programmability Teach-in function for easy setting of switching points. Temperature Compensation Built-in for stable performance in varying temperatures.

Technical Parameters Category Specification for MCS11 Series Model / Series MCS11 Product Type Modular Control and Signalling Station Mounting Panel Mount (Base frame snaps into a rectangular cutout) Front Panel Protection Typically IP65 (Dust-tight and protected against water jets) when properly installed. Module Types Actuators Pushbuttons (illuminated/non-illuminated), selector switches, key-operated switches, emergency stop. Contact Blocks Various contact configurations (e.g., 1NO, 1NC, 1NO+1NC). Pilot Lights Various lens colors and voltages for status indication. Contact Rating (Typical) 10A @ 250V AC (for contact blocks) Electrical Life Typically > 1,000,000 mechanical operations. Material Thermoplastic (PA) for high mechanical strength and chemical resistance. Agency Approvals UL Listed, CSA Certified, CE Marked

Technical Parameters Category Specification Model M22-WRLK3-W Product Type Ultrasonic Proximity Sensor Housing Thread M22 x 1 Sensing Range Typically up to 600 mm (0.6 meters) or similar, programmable. Sensing Object Virtually any solid or liquid material (sound-reflective). Output Type Typically 1 PNP and 1 NPN output, programmable for NO/NC operation. Output Configuration 4-wire (2 for power supply, 1 PNP output, 1 NPN output). Supply Voltage 10-30V DC Current Consumption Typically < 30 mA Connection Type Quick-Disconnect (Connector) (W), allowing for easy sensor replacement. Housing Material Typically brass or stainless steel with PTFE/POM sensing face. IP Rating IP67 (Dust-tight and protected against temporary immersion) Key Features Programmability Teach-in function for easy setting of switching points. Temperature Compensation Built-in for stable performance in varying temperatures.

Technical Parameters Category Specification Model DILM32-01C (XTCE032CC01) Product Type Contactor Rated Operational Current (Ie) 32 A at AC-3, 400V Rated Operational Voltage (Ue) 690V AC Poles 3 (Main Contacts) Auxiliary Contacts 1 NO + 1 NC (Convertible) Coil Voltage 24V AC, 50/60 Hz (for "01C" variant) Rated Power Consumption Typically 9 VA (AC) Electrical Durability Typically 1.5 million operations at rated current Mechanical Durability Typically 10-15 million operations Mounting DIN Rail (35mm) or Screw Mount Standards IEC/EN 60947-4-1, UL 508

Technical Parameters Category Specification Model M22WRLK-W Product Type Ultrasonic Proximity Sensor Housing Thread M22 x 1 Sensing Range Typically up to 600 mm (0.6 meters) or similar, programmable. Sensing Object Virtually any solid or liquid material (sound-reflective). Output Type Typically 1 PNP and 1 NPN output, programmable for NO/NC operation. Output Configuration 4-wire (2 for power supply, 1 PNP output, 1 NPN output). Supply Voltage 10-30V DC Current Consumption Typically < 30 mA Connection Type Quick-Disconnect (Connector) (W), allowing for easy sensor replacement. Housing Material Typically brass or stainless steel with PTFE/POM sensing face. IP Rating IP67 (Dust-tight and protected against temporary immersion) Key Features Programmability Teach-in function for easy setting of switching points. Temperature Compensation Built-in for stable performance in varying temperatures.

Technical Parameters Category Specification Model LSM-11D Product Type Linear Position Sensor / String Potentiometer Measurement Range Specific to model variant (e.g., 100mm to 2000mm) Output Signal Potentiometer (e.g., 0-5kΩ, 0-10kΩ) Linearity Typically ±0.1% to ±0.5% of full scale Repeatability Very high, typically < 0.01 mm Supply Voltage N/A (as a passive potentiometer, it requires an external excitation voltage if used for voltage output) Cable Speed Typically up to 2 m/s Electrical Connection Pre-wired cable or connector (specific to variant) Housing Material Anodized aluminum IP Rating Typically IP54 or higher Operating Temperature -20°C to +80°C
