Key Parameters Category Description / Value Product Line Eaton NZM2 Model / Frame Size NZM2-XAD Release Type Fixed Thermal-Magnetic (Non-adjustable) Rated Current (Iₙ) 250 A (Fixed value) Poles 3-Pole & 4-Pole versions are commonly available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) High, typically 50 kA or more at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Release Characteristics Thermal (Long Delay): For overload protection. Magnetic (Instantaneous): For short-circuit protection. Both are factory-set and non-adjustable. Standards Compliance IEC/EN 60947-2 Mounting Fixed Mounting (for bolted installation in panels). Connection Screw terminals. Auxiliary Contacts & Accessories Compatible with the full range of NZM2 accessories, such as auxiliary contacts, undervoltage release, and shunt trip, which can be snapped onto the breaker.

Key Parameters Category Description / Value Product Line Eaton Air Circuit Breakers Series N4 Rated Current (Iₙ) 1000 A Poles 3-Pole & 4-Pole versions are available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Very high, typically 65 kA to 100 kA at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Trip Unit Type Standard "AS" Electronic Trip Unit • Provides adjustable protection functions (overload, short-circuit, and ground-fault). Operation Mechanism Manual stored-energy spring mechanism (allows for quick ON/OFF operation). Mounting Fixed Mounting (designed for bolted installation in switchgear panels) or Draw-out Version (available as an option). Standards Compliance IEC/EN 60947-2 Connection Primary power connections are typically made via busbars. Standard Accessories The "AS" version typically comes with a basic set of indicators and possibly a few built-in auxiliary contacts. A wide range of additional accessories are available.

Key Parameters Category Description / Value Product Line Eaton NZM3 Model / Frame Size NZM3-XKS Release Type Fixed Thermal-Magnetic (Non-adjustable) Rated Current (Iₙ) 185 A (Fixed value) Poles 3-Pole & 4-Pole versions are commonly available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 690 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Typically 50 kA at 400V AC (IEC 60947-2). The exact value should be verified from the technical data sheet. Release Characteristics Thermal (Long Delay): For overload protection. Magnetic (Instantaneous): For short-circuit protection. Both are factory-set and non-adjustable. Standards Compliance IEC/EN 60947-2 Mounting Fixed Mounting (for bolted installation in panels). Connection Screw terminals. Auxiliary Contacts & Accessories Compatible with a range of NZM3 accessories, such as auxiliary contacts, undervoltage release, and shunt trip.

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 series breakers of specific frame sizes. Function Shunt Trip Release (for remote opening) Rated Control Supply Voltage (Us) The "PK" suffix commonly indicates a standard voltage of 230V AC. However, the exact voltage must be confirmed by the order code sticker on the device itself, as other voltages (e.g., 24V DC, 110V AC, 400V AC) are available. Mounting Mounts directly onto the compatible NZM3 breaker.

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 series breakers of the specified frame size (Frame 4). Function Undervoltage Release (UVR) Rated Control Supply Voltage (Us) A common standard voltage is 400V AC, 50/60 Hz. However, the exact voltage must be confirmed by the order code sticker on the device itself, as other voltages (e.g., 230V AC, 110V AC) are available. Mounting Mounts directly onto the compatible NZM3 breaker. Operation The breaker can only be closed when the supply voltage is present and above the trip threshold. It automatically trips when the voltage drops below the threshold or is lost.

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 series breakers (specific frame sizes) Function Undervoltage Release (UVR) Rated Control Supply Voltage Typically available in multiple voltages: • 230V AC • 400V AC • 110V AC Exact voltage must be verified from device label Trip Threshold Typically 35%-70% of rated voltage Mounting Direct mounting onto compatible NZM3 breaker Standards IEC/EN 60947-2

Key Parameters Category Description / Value Product Line Eaton Inductive Proximity Sensors Series C22 Sensor Type Inductive (detects metallic objects) Sensing Distance 2 mm Housing Size / Thread M12 x 1 Mounting Shielded (Flush-mountable) Output Configuration NPN, Normally Open (NO) Connection Pre-wired 2-meter cable Rated Operating Voltage 10-30 V DC Output Current ≤ 200 mA Housing Material Nickel-plated brass or stainless steel Protection Class IP67

Key Parameters Category Description / Value Product Line Eaton IZM (Miniature Circuit Breakers) Rated Current (Iₙ) 65 A Number of Poles 3-Pole Tripping Characteristic Special F-Characteristic (Very high magnetic trip setting for high inrush currents) Rated Operational Voltage (Uₑ) 400/415 V AC (Three-Phase) Rated Insulation Voltage (Uᵢ) 500 V Rated Impulse Withstand Voltage (Uᵢₘₚ) 4 kV Breaking Capacity According to IEC/EN 60898 standard (e.g., 10 kA, 15 kA). Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Suitable for busbar connection and cable lugs.

Key Parameters Category Description / Value Product Line Eaton IZM (Miniature Circuit Breakers) Rated Current (Iₙ) 65 A Number of Poles 3-Pole Tripping Characteristic Special F-Characteristic (Very high magnetic trip setting for high inrush currents) Rated Operational Voltage (Uₑ) 400/415 V AC (Three-Phase) Rated Insulation Voltage (Uᵢ) 500 V Rated Impulse Withstand Voltage (Uᵢₘₚ) 4 kV Breaking Capacity According to IEC/EN 60898 standard (e.g., 10 kA, 15 kA). Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Suitable for busbar connection and cable lugs.

Key Parameters Category Description / Value Product Line Eaton IN (Miniature Circuit Breakers) Rated Current (Iₙ) 65 A Number of Poles 3-Pole Tripping Characteristic C-Curve (Standard characteristic for medium inrush currents) Rated Operational Voltage (Uₑ) 400/415 V AC (Three-Phase) Breaking Capacity According to IEC/EN 60898 standard (typically 6-10 kA) Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Suitable for standard cable connections
