Core Specifications
Drive Module (ACS800-04-0610-7):

Output Power: 610kW (400V configuration)

Output Current: 1180A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Efficiency: 98.5% at full load

Switching Frequency: 1-3kHz (adjustable)

P901 Control Panel:

10" high-brightness industrial touchscreen

Multi-language interface (20 languages)

Integrated web server with secure remote access

64GB data logging capacity

Dual USB 3.1 configuration ports

Real-time predictive maintenance functions

Key System Features
Advanced Performance:
✔ Ultra-Precise Control: ±0.01% speed accuracy
✔ Adaptive Control: 20 application-specific macros
✔ Process Optimization: Quad PID controllers with AI tuning
✔ Harmonic Mitigation: <3% THD with active front end

Connectivity & Integration:

Standard Interfaces:

4× 1Gbps Ethernet ports (PROFINET IRT, EtherNet/IP)

OPC UA over TCP/IP

IEC 61850 protocol support

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Wireless LAN module

Safety Systems:

SIL3/PL e certified safety functions:

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Safe Brake Control (SBC)

Redundant safety processors

Continuous self-monitoring

Mechanical Specifications
Enclosure: IP21 (cabinet-mounted)

Cooling System: Liquid-assisted forced air cooling

Dimensions: 800 × 2200 × 600mm (W×H×D)

Weight: 450kg (complete system)

Noise Level: <70dB at 1m

Cooling Airflow: 3000m³/hr

Core Specifications
Drive Unit (ACS800-04P-0170-3):

Output Power: 170kW (400V)

Output Current: 330A continuous

Input Voltage: 3-phase 380-415V AC (±10%)

Overload Capacity:

150% for 60 seconds

200% for 3 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 98.1% at full load

Switching Frequency: 1-5kHz (adjustable)

P901 Control Panel:

7" high-brightness color touchscreen

Multi-language HMI interface (14 languages)

Integrated web server with remote monitoring

16GB non-volatile data storage

USB 3.0 configuration port

Real-time clock with battery backup

Key System Features
Advanced Performance:
✔ Precision Control: ±0.05% speed accuracy
✔ Adaptive Programming: 12 application macros
✔ Process Optimization: Dual PID controllers with fuzzy logic
✔ Energy Management: Power consumption monitoring (kWh/MWh)

Connectivity:

Standard Interfaces:

PROFINET IRT (2 ports)

EtherNet/IP

OPC UA over TCP/IP

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Modbus TCP

Safety Systems:

SIL3 certified safety functions:

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Redundant safety circuits

Automatic self-diagnostics

Mechanical Specifications
Enclosure: IP21 (NEMA 1)

Cooling System: Smart cooling with temperature-controlled fans

Dimensions: 450 × 850 × 350mm (W×H×D)

Weight: 72kg (complete system)

Noise Level: <63dB at 1m

Core Specifications
Drive Module (ACS800-04M-0210-3):

Output Power: 210kW (400V configuration)

Output Current: 410A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Efficiency: 98.3% at full load

P901 Control Panel:

7" high-resolution TFT touchscreen

Multi-language interface (18 languages)

Integrated web server with HTTPS security

32GB data logging capacity

USB 3.0 configuration port

Key System Features
Advanced Performance:
✔ Ultra-Precise Control: ±0.02% speed accuracy
✔ Adaptive Programming: 16 application macros
✔ Process Optimization: Triple PID controllers
✔ Harmonic Mitigation: <3% THD with active front end

Connectivity & Integration:

Standard Interfaces:

2× PROFINET IRT (TSN-ready)

OPC UA Pub/Sub

EtherNet/IP

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Modbus TCP

Safety Systems:

Integrated Safety:

Safe Torque Off (STO) - SIL3/PL e

Safe Stop 1 (SS1)

Safe Limited Speed (SLS)

Redundant Safety Circuits

Automatic Self-Testing

Mechanical Specifications
Enclosure: IP21 (cabinet-mounted)

Cooling System: Liquid/air hybrid cooling

Dimensions: 500 × 1000 × 400mm (W×H×D)

Weight: 85kg (complete system)

Noise Level: <62dB at 1m

Core Components
ACS800-01-0070-3 Main Drive Unit

Output Power: 55kW (75HP) at 380V

Output Current: 112A continuous

Input Voltage: 3-phase 380-415V AC (±10%)

Control Technology: Direct Torque Control (DTC)

Overload Capacity: 150% for 60 seconds

D150 Dynamic Braking Unit

Braking Capacity: 150% of drive rating

Peak Power: 110kW for 10% duty cycle

Response Time: <2ms

P901 Advanced Control Panel

7" color touchscreen HMI

Multi-language interface (16 languages)

Integrated web server functionality

16GB data logging capacity

Key System Features
Performance Enhancements:
✔ Precision Regulation: ±0.05% speed accuracy
✔ Rapid Deceleration: 200% braking torque capacity
✔ Process Optimization: Dual PID controllers with auto-tuning
✔ Energy Recovery: Regenerative braking capability

Technical Specifications:

Enclosure Rating: IP21 (NEMA 1)

Communication Protocols:

PROFIBUS DP (standard)

PROFINET IRT (optional)

OPC UA over Ethernet

Safety Systems:

Safe Torque Off (STO) - SIL3 certified

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Physical Specifications:

Dimensions: 400 × 900 × 350mm (W×H×D)

Weight: 48kg (complete system)

Cooling: Smart temperature-controlled fans

Noise Level: <68dB at 1m

Key Specifications
Parameter Specification
Output Current 169A
Rated Power 75kW (400V, 4-pole motor)
Input Voltage 3-phase 380-480V AC (±10%)
Overload 150% for 60 seconds
Control Method Direct Torque Control (DTC)
Efficiency >98% at full load
Enclosure IP21 (open chassis)
Advanced Features
Precision Control:
✔ Ultra-fast torque response (<5ms)
✔ Speed accuracy: ±0.01% of set value
✔ Adaptive motor tuning (AMT)

Connectivity:

Standard interfaces:

Dual Ethernet ports (1Gbps)

PROFINET IRT

OPC UA server

Optional modules:

PROFIBUS DP-V2

EtherNet/IP

BACnet MS/TP

Safety & Protection:

Integrated safety functions (STO, SS1, SLS)

SIL3/PL e certified

Advanced diagnostics with predictive maintenance

Mechanical Specifications
Dimensions: 350 × 800 × 300mm (W×H×D)

Weight: 42kg

Cooling: Smart fan control

Ambient Temperature: 0°C to +50°C

Core Components
ACS800-01-0050-5 Main Drive Unit

Power Rating: 37kW (50HP)

Output Current: 96A continuous

Input Voltage: 3-phase 200-240V AC (-15%/+10%)

Control Method: Direct Torque Control (DTC)

Overload Capacity: 150% for 60 seconds

Efficiency: 97.5% at full load

D150 Braking Module

Braking Power: 150% of drive rating

Peak Capacity: 75kW for 10% duty cycle

Dynamic Response: <5ms reaction time

E200 High-Resolution Encoder Interface

Resolution Support: Up to 24-bit

Protocols: EnDat 2.2, Hiperface DSL

Update Rate: 250kHz

Key System Features
Performance Enhancements:
✔ Ultra-Precise Control: ±0.01% speed accuracy with encoder
✔ Advanced Braking: Regenerative energy management
✔ Rapid Deceleration: 200% braking torque capacity
✔ Smart Cooling: Temperature-optimized airflow

Technical Specifications:

Enclosure Rating: IP21 (NEMA 1)

Communication:

PROFIBUS DP (standard)

Optional EtherNet/IP

Safety: STO (Safe Torque Off) certified

Dimensions: 350 × 700 × 300mm (W×H×D)

Weight: 32kg (complete system)

Core Specifications
Drive Unit (ACS800-04-0040-3):

Output Power: 40kW (400V)

Output Current: 78A continuous

Input Voltage: 3-phase 380-415V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: >97% at full load

Switching Frequency: 1-12kHz (adjustable)

P901 Control Panel:

7" color touchscreen display

Multi-language interface (12 languages)

Built-in web server for remote monitoring

8GB data logging capacity

USB port for configuration backup

Key System Features
Advanced Control:
✔ Precision Regulation: ±0.1% speed accuracy
✔ Application Macros: 8 pre-programmed configurations
✔ Process Control: Built-in PID with auto-tuning
✔ Energy Optimization: Adaptive motor control

Connectivity:

Standard interfaces:

PROFIBUS DP

Modbus RTU

Ethernet

Optional fieldbus modules available

Safety & Protection:

Safe Torque Off (STO) - SIL3 certified

Motor thermal protection

Ground fault monitoring

DC bus overvoltage protection

Mechanical Specifications
Enclosure: IP21 (NEMA 1)

Cooling: Forced air with temperature control

Dimensions: 300 × 600 × 250mm (W×H×D)

Weight: 25kg (complete system)

Core Specifications
Drive Unit (ACS800-04P-0320-3):

Output Power: 320kW (400V)

Output Current: 620A continuous

Input Voltage: 3-phase 380-415V AC (±10%)

Overload Capacity:

150% for 60 seconds

200% for 3 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 98.2% at full load

Switching Frequency: 1-3kHz (adjustable)

P901 Control Panel:

7" high-brightness TFT touchscreen

Multi-language HMI (16 languages)

Integrated web server (HTTP/HTTPS)

16GB data logging capacity

USB 3.0 configuration port

Real-time clock with battery backup

Key System Features
Advanced Performance:
✔ Ultra-Precise Control: ±0.05% speed accuracy
✔ Adaptive Control: 12 application-specific macros
✔ Process Optimization: Dual PID controllers with fuzzy logic
✔ Harmonic Mitigation: <3% THID with active front end option

Connectivity:

Standard interfaces:

PROFINET IRT (2 ports)

EtherNet/IP

OPC UA over TCP/IP

Optional modules:

PROFIBUS DP-V2

BACnet MS/TP

Modbus TCP

Safety Systems:

SIL3 certified safety functions:

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Redundant safety circuits

Automatic self-test routines

Mechanical Specifications
Enclosure: IP21 (NEMA 1)

Cooling System: Smart cooling with dual fans

Dimensions: 550 × 900 × 400mm (W×H×D)

Weight: 98kg (complete system)

Noise Level: <65dB at 1m

Key Specifications
Parameter Specification
Continuous Power 44kW
Peak Power 88kW (10% duty cycle)
DC Link Voltage 510-780V DC
Current Rating 85A continuous
Enclosure Rating IP20 (cabinet-mounted)
Cooling Method Forced air with temperature control
Protection Class I (with PE terminal)
Technical Features
✔ Advanced Braking Control

Automatic current limitation

Adaptive braking torque regulation

Pre-charge circuit for safe startup

✔ Monitoring & Protection

Thermal overload protection (Class 10)

Short-circuit and overvoltage protection

Fault relay output (NO/NC contacts)

LED status indicators (power, active, fault)

✔ Robust Construction

Industrial-grade power components

Coated PCB for harsh environments

DIN rail compatible mounting

Dimensions: 310 × 225 × 210mm (W×H×D)

Weight: 9.2kg

Compatibility
Designed for use with:

ACS580 series drives

ACS880 multi-drive systems

ACQ800 process drives

Requires external braking resistor (not included)

Certifications & Compliance
CE marked (EMC Directive 2014/30/EU)

Low Voltage Directive 2014/35/EU

RoHS 3 (2015/863/EU)

UL recognized component

Installation Requirements
Minimum clearance: 100mm sides, 150mm above

Ambient temperature:

Operation: 0°C to +50°C (derating above +40°C)

Storage: -40°C to +85°C

Relative humidity: 5-95% non-condensing

Altitude: ≤1000m (derating required above)

Ordering Information
Package Includes:

APBU-44CE braking unit

Mounting bracket set

Terminal covers

Installation manual (3BHE041543R0001)

Key Specifications
Parameter Specification
Compatibility ACS800, ACS880, ACQ800 series drives
Protocols PROFIBUS DP-V1, Modbus RTU, CANopen
Data Rate Up to 12Mbps (PROFIBUS)
Isolation 1500V AC reinforced isolation
Power Supply 24V DC (±10%)
Enclosure IP20 (for cabinet mounting)
Operating Temp -25°C to +70°C
Technical Features
✔ Multi-Protocol Support

Simultaneous protocol operation

Automatic baud rate detection

Parameter mapping for all major ABB drives

✔ Advanced Diagnostics

LED status indicators for all channels

Built-in error logging

Signal quality monitoring

✔ Robust Design

Industrial-grade components

DIN rail mounting

EMC compliant to EN 61800-3
