Key Specifications
Parameter Specification
Output Current 38A
Rated Power 18.5kW (400V, 4-pole motor)
Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz
Enclosure IP21 (open chassis)
Control Methods Sensorless Vector Control (SLVC) & V/f control
Overload 150% for 60 seconds
Communication Built-in Modbus RTU (RS485)
Advanced Features
✔ Energy Optimization - Automatic adaptation to load changes for maximum efficiency
✔ Intelligent Motor Protection - Thermal, short-circuit, and phase-loss protection
✔ User-Friendly Interface - LCD keypad with multilingual display (8 languages)
✔ Integrated PID Controller - For precise process control (pressure, flow, temperature)
✔ Compact Design - Space-saving for easy cabinet installation (DIN rail or panel mount)
✔ Fieldbus Options - Supports PROFIBUS DP and BACnet via optional modules

Model Number Breakdown
ACS510: Series designation (general-purpose drives)

01: IP21 enclosure rating

038A: 38A output current

4: 400V voltage class (380-480V)

Key Specifications
Output Current: 60A

Rated Power: 30kW (for 400V 4-pole motor)

Supply Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Enclosure Type: IP21 (open chassis)

Control Methods:

Sensorless Vector Control (SLVC)

V/f control

Overload Capacity: 150% for 60 seconds

Main Features
✔ Energy Optimization - Automatic energy-saving function specifically for pump and fan applications
✔ Advanced Motor Protection - Includes thermal overload, short circuit, and phase loss protection
✔ User-Friendly Interface - LCD keypad with multilingual support
✔ Built-in PID Controller - For closed-loop process control
✔ Fieldbus Communication - Standard Modbus RTU (RS485), with optional PROFIBUS DP and BACnet modules
✔ Compact Design - Space-saving for easy cabinet installation

Key Specifications
Parameter Specification
Output Current 157A
Rated Power 75 kW (400V, 4-pole motor)
Supply Voltage 3-phase, 380–480V AC (±10%), 50/60Hz
Enclosure IP21 (Open chassis, panel-mountable)
Control Method Sensorless Vector Control (SLVC) & V/f control
Overload Capacity 150% for 60 seconds
Communication Built-in Modbus RTU (RS485), optional fieldbus modules
Key Features
✔ High Power Output – Supports 75kW motors with 157A continuous current.
✔ Energy-Saving Mode – Automatic energy optimization for pumps, fans, and compressors.
✔ Advanced Motor Protection – Thermal overload, short-circuit, phase-loss, and ground fault protection.
✔ PID Control – Built-in closed-loop regulation for pressure, flow, and temperature control.
✔ User-Friendly Interface – LCD keypad with multilingual support for easy programming.
✔ Compact & Efficient Cooling – Forced-air cooling for stable operation under heavy loads.
✔ Fieldbus Connectivity – Supports Modbus, PROFIBUS, BACnet (optional) for system integration.

Model Number Breakdown
ACS510 → ABB’s general-purpose drive series.

01 → IP21 enclosure (basic protection, open chassis).

157A → 157A output current rating.

4 → 400V class (380–480V AC supply).

Key Specifications
Parameter Specification
Output Current 9A
Rated Power 4 kW (400V, 4-pole motor)
Supply Voltage 3-phase, 380–480V AC (±10%), 50/60Hz
Enclosure IP21 (Open chassis, panel-mountable)
Control Method Sensorless Vector Control (SLVC) & V/f control
Braking Torque Up to 150% (with optional brake resistor)
Communication Built-in Modbus RTU (RS485), optional PROFIBUS & BACnet
Main Features
✔ Energy-Saving Optimization – Automatic adaptation to load changes for maximum efficiency in pump & fan applications.
✔ Intelligent Motor Protection – Built-in thermal overload, short-circuit, and phase-loss protection.
✔ User-Friendly Interface – LCD keypad with multilingual support (English, Spanish, French, etc.).
✔ PID Control – Integrated PID regulator for closed-loop process control (pressure, flow, temperature).
✔ Compact & Space-Saving – DIN-rail or panel mounting for easy installation in control cabinets.
✔ Plug-and-Play Compatibility – Pre-configured for ABB motors but works with standard AC motors.

Model Number Breakdown
ACS510 → Series (ABB’s general-purpose drive for pumps & fans).

01 → IP21 enclosure (basic protection, open chassis).

09A4 → 9A output current, 4 kW power class.

4 → 400V supply voltage (380–480V AC).

Core Components
ACS510-01-060A-4 Drive Unit

Rated Output: 60A, 380-480V AC

Power Rating: ~30kW (400V 4-pole motor)

Control Features:

Sensorless vector control

Built-in PID controller

Pump/fan optimization logic

Motor thermal protection

B055 Brake Chopper Module

Function: Dissipates regenerative energy

Braking Power: 55kW peak (standard duty)

Connection: Pre-engineered for seamless integration

Protection: Over-temperature monitoring

Technical Advantages
Dynamic Braking Capability: Enables controlled deceleration of high-inertia loads

Energy Management: Protects drive DC bus from overvoltage during braking

Space Optimization: Compact combined footprint

Simplified Installation: Pre-configured compatibility

Key Specifications:
Output Current: 60A

Rated Power: ~30kW (for standard 400V 4-pole motor)

Supply Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Control Methods: Sensorless Vector Control (SLVC) & V/f control

Enclosure Type: IP21 (Open chassis, panel-mounted)

Cooling Method: Self-cooling (convection)

Advanced Features:
✔ Energy Savings Optimization - Automatic energy optimization algorithm for pumps and fans
✔ Intelligent Motor Control - Built-in motor thermal protection and adaptive programming
✔ User-Friendly Interface - LCD keypad with multilingual support (including English)
✔ Robust Protection - Overcurrent, overvoltage, motor overload, and short-circuit protection
✔ Fieldbus Connectivity - Built-in Modbus RTU (RS485), optional PROFIBUS DP & BACnet
✔ PID Controller - Integrated for closed-loop process control

Model Number Breakdown:
ACS510: Series name (ABB general-purpose drive)

01: IP21 enclosure rating

060A: 60A output current rating

4: 400V class (380-480V)

(0EM): Standard OEM configuration

Key Features:
Protection Functions: Instantaneous and time-delayed overcurrent protection (50/51)

Current Input: 1A or 5A nominal (configurable)

Four-Stage Protection: Three-phase and earth-fault protection stages

LED Indicators: Clear status indication for relay operation and alarms

Communication: RS485 interface with Modbus RTU protocol

Mechanical Design: Compact, DIN-rail mounted housing (1SVR form factor)

Operating Range: Wide auxiliary voltage range (24-250V DC/AC)

Technical Specifications:
Standards Compliance: IEC 60255, IEEE C37.90

Auxiliary Supply: 110V AC/DC (as indicated by "110" in model number)

Operating Temperature: -25°C to +55°C

Enclosure Rating: IP20

Key Specifications:
Output Current: 195A

Rated Power: Approximately 110kW (depending on motor specifications)

Supply Voltage: 380-480V AC, 3-phase

Enclosure: IP21 (open chassis type)

Control Method: Sensorless vector control and V/f control

Advanced Features:
✔ Energy Optimization: Built-in energy savings calculator and automatic energy optimization
✔ Intelligent Control: Adaptive programming for pump and fan applications
✔ Robust Protection: Comprehensive motor and drive protection features
✔ User-Friendly Interface: Easy-to-use control panel with multilingual support
✔ Flexible Connectivity: Standard Modbus RTU with optional fieldbus protocols

Key Features:
✔ Rated Output: 125A, 400V (3-phase) – Suitable for high-power motor control.
✔ Power Range: 75 kW (approx., depending on motor specs).
✔ Pump & Fan Optimization – Built-in ABB’s Intelligent Control (AIC) for automatic energy savings.
✔ Compact Design – Space-saving and easy to install in electrical cabinets.
✔ User-Friendly Interface – Simple keypad with multilingual display for quick setup.
✔ Robust Protection – Includes overload, short-circuit, and overheating protection.
✔ Fieldbus Connectivity – Supports Modbus, BACnet, PROFIBUS (optional).

✔ D-Curve Trip Characteristic – Ideal for circuits with high inrush currents (e.g., motors, transformers).
✔ Rated Current: 16A – Suitable for medium-load applications.
✔ Breaking Capacity: Up to 6 kA (depending on model variant).
✔ 2-Pole Design (S202) – Provides simultaneous phase + neutral protection.
✔ Compact & Modular – Easy installation in standard DIN rail panels.
✔ Compliance with IEC/EN 60898-1 – Ensures global safety standards.

Typical Applications:
