Key Features
✔ PROFIBUS DP-V1 Master Functionality

Full compliance with IEC 61158/61784 standards

Supports both cyclic and acyclic data communication

Automatic baud rate detection (9.6 kbps to 12 Mbps)

✔ Industrial Reliability

Operating temperature: -25°C to +60°C

500V galvanic isolation for noise immunity

Hot-swappable in redundant configurations

✔ Advanced Diagnostics

LED indicators for power, status, and communication

Comprehensive diagnostic capabilities

Supports PROFIBUS DP-V1 extended diagnostics

✔ Seamless Integration

Native compatibility with AC 800M controllers

Direct integration with System 800xA DCS

Supports up to 125 PROFIBUS DP slaves

Technical Specifications
Parameter Specification
Manufacturer P/N 3BSE041882R1
Interface Type PROFIBUS DP-V1
Connector 9-pin D-sub male
Communication RS-485
Power Supply 24V DC via backplane
Isolation 500V galvanic
Certifications CE, UL, ATEX (optional)
Typical Applications
Process Automation (oil & gas, chemical plants)

Manufacturing Systems (automotive production)

Power Generation (turbine control)

Water Treatment (pump station control)

Material Handling (conveyor systems)

Key Features
✔ PROFIBUS DP Master Functionality

Compliant with IEC 61158/61784 standards

Supports baud rates from 9.6 kbps to 12 Mbps

Automatic bus parameter detection

✔ Industrial-Grade Reliability

Operating temperature: -25°C to +60°C

500V galvanic isolation for noise immunity

Hot-swappable design for maintenance

✔ Advanced Diagnostics

LED status indicators for power and communication

Comprehensive fault detection and reporting

Supports PROFIBUS DP diagnostics

✔ Flexible Integration

Compatible with ABB AC 800M controllers

Supports System 800xA DCS

Connects up to 125 PROFIBUS DP slaves

Technical Specifications
Parameter Specification
Part Number 3BSE20510R1
Interface PROFIBUS DP (RS-485)
Connector 9-pin D-sub
Power Supply 24V DC
Isolation 500V
Certifications CE, UL
Typical Applications
Process automation systems

Manufacturing control

Power generation

Water treatment plants

Material handling systems

Key Features
✔ High-Density Input Configuration

32 isolated digital input channels

24V DC voltage sensing (sinking/sourcing configurable)

<1ms response time for fast signal processing

✔ Advanced Functionality

Individual channel diagnostics

Short-circuit and overload protection

Wire-break detection capability

✔ Industrial Reliability

Operating temperature: -25°C to +60°C

500V galvanic isolation (channel-to-system)

Hot-swappable in compatible systems

✔ Comprehensive Diagnostics

Per-channel LED status indicators

Detailed fault reporting via control system

Technical Specifications
Parameter Specification
Manufacturer P/N 3BSE028586R1
Input Type 24V DC (dry/wet contact)
Input Current 3-5mA typical
Isolation 500V between channels
Power Consumption 2.5W typical
Connection High-density terminal block
Certifications CE, UL, ATEX (optional)
Typical Applications
Process Automation (sensor monitoring, limit switches)

Manufacturing Systems (machine status inputs)

Power Generation (breaker status monitoring)

Safety Systems (emergency stop circuits)

Building Automation (access control systems)

Key Features:
Powerful Processing: Equipped with a high-speed processor for efficient execution of control algorithms.

Redundancy Support: Enables redundant configurations for mission-critical applications, ensuring system availability.

Multi-Protocol Communication: Supports industrial protocols like Profibus, Modbus, and OPC UA for seamless integration.

Large Memory Capacity: Ample storage for program code and data logging.

Robust Design: Built for harsh industrial environments with high resistance to electrical noise and temperature fluctuations.

Compatibility: Works with ABB’s S800 I/O modules and 800xA DCS for scalable automation solutions.

Typical Applications:
Process control in oil & gas, power generation, and chemical plants

Distributed control systems (DCS)

Supervisory control and data acquisition (SCADA)

Key Features
✔ Dual-CPU Redundancy

1:1 hot standby configuration

Automatic switchover (<100ms)

99.999% availability for critical processes

✔ Powerful Processing Capability

1.1 GHz dual-core processor

1 GB RAM for complex control strategies

Supports up to 500,000 I/O points (system-wide)

✔ Industrial Communication

Dual Ethernet ports (10/100/1000 Mbps)

Supports PROFIBUS DP, Modbus TCP, OPC UA

Optional PROFINET, FF HSE communication

✔ Robust Industrial Design

Operating temperature: -40°C to +70°C

Vibration and shock resistant (IEC 60068-2-6/27)

IP20 protection (higher protection optional)

✔ Cybersecurity

IEC 62443 compliant

Secure boot and firmware validation

Role-based access control

Technical Specifications
Parameter Specification
Processor 1.1 GHz dual-core
Memory 1 GB RAM / 256 MB Flash
Redundancy 1:1 hot standby
I/O Capacity Up to 500,000 points
Communication Ethernet, PROFIBUS DP, Modbus TCP, OPC UA
Power Supply 24V DC (redundant)
Certifications CE, UL, ATEX (optional)
Typical Applications
Oil & Gas (refineries, pipelines, offshore platforms)

Power Generation (turbine control, SCADA)

Chemical Processing (batch and continuous processes)

Pharmaceutical (GMP manufacturing)

Water Treatment (plant-wide control systems)

Key Features
✔ Extreme Processing Power

Quad-core 1.5 GHz processor for complex control tasks

2 GB RAM with error-correcting code (ECC) protection

Supports up to 1,000,000 I/O points system-wide

✔ Advanced Cybersecurity

IEC 62443-3-3 certified security level

Secure boot with hardware root of trust

Encrypted communication and role-based access

✔ Industrial Connectivity

Dual 1 Gbps Ethernet ports with switch functionality

Supports PROFINET IO, OPC UA, Modbus TCP

Optional TSN (Time-Sensitive Networking) capability

✔ Rugged Industrial Design

Extended temperature range: -40°C to +70°C

50g shock resistance (IEC 60068-2-27)

Corrosion-resistant aluminum housing

✔ Future-Ready Architecture

Containerized application support

Edge computing capability

Predictive maintenance features

Technical Specifications
Parameter Specification
Processor Quad-core 1.5 GHz ARM Cortex-A72
Memory 2 GB RAM / 8 GB Flash
Communication 2x 1Gbps Ethernet, PROFINET, OPC UA
I/O Capacity Up to 1,000,000 points
Power Supply 24V DC (18-32V range)
Power Consumption <15W typical
Certifications CE, UL, cULus, ATEX, IECEx
Typical Applications
Smart Manufacturing (Industry 4.0 implementations)

Energy Management Systems (microgrid control)

Pharmaceutical (batch process automation)

Oil & Gas (digital twin implementations)

Water/Wastewater (smart city infrastructure)

Key Features
✔ High-Performance Processing

Dual-core 1.2 GHz processor with 1 GB RAM

Supports up to 500,000 I/O points system-wide

Real-time deterministic control execution

✔ Enhanced Cybersecurity

IEC 62443-3-3 compliant security

Secure boot with hardware root of trust

Role-based access control with encryption

✔ Industrial Connectivity

2x Ethernet ports (10/100/1000 Mbps) with switch functionality

Supports OPC UA, Modbus TCP, PROFINET

Optional wireless communication modules

✔ Rugged Industrial Design

Operating temperature: -40°C to +70°C

Vibration resistant (5g @ 10-150Hz)

Compact form factor (50% smaller than previous generations)

✔ Future-Ready Features

Edge computing capability

Container support for advanced applications

Predictive maintenance functionality

Technical Specifications
Parameter Specification
Manufacturer P/N 3BSE053241R1
Processor Dual-core 1.2 GHz ARM Cortex-A9
Memory 1 GB RAM / 4 GB Flash
Communication 2x Ethernet, PROFINET, OPC UA
I/O Capacity Up to 500,000 points
Power Supply 24V DC (18-32V range)
Power Consumption <10W typical
Certifications CE, UL, cULus, ATEX Zone 2
Typical Applications
Process Industries (chemical, oil & gas)

Power Generation (turbine control)

Water/Wastewater Treatment

Pharmaceutical Manufacturing

Discrete Manufacturing (automotive, electronics)

Key Features
✔ Versatile I/O Configuration

16 digital inputs (24V DC)

16 digital outputs (24V DC, 0.5A)

4 analog inputs (0-10V/4-20mA)

✔ Robust Industrial Design

IP20 protection (panel-mounted)

Operating temperature: 0°C to +55°C

Vibration resistant construction

✔ Robot-Specific Features

Direct integration with ABB IRC5 controllers

RobotWare compatible configuration

Hot-pluggable design for easy maintenance

✔ Diagnostic Capabilities

LED status indicators for all I/O channels

Short-circuit protected outputs

Overvoltage protection

Technical Specifications
Parameter Specification
Manufacturer P/N 3HAC025779-001
Input Voltage 24V DC (±10%)
Input Current 3-8mA (digital)
Output Current 0.5A max per channel
Analog Resolution 12-bit
Communication DeviceNet interface
Mounting DIN rail
Certifications CE, UL
Typical Applications
Robotic Material Handling

Automated Welding Cells

Machine Tending Applications

Assembly Line Automation

Paint Robot Systems

Key Features
✔ High-Accuracy Temperature Measurement

Supports 2/3/4-wire RTD connections (Pt100, Pt1000, Ni100, etc.)

±0.1°C measurement accuracy

16-bit ADC resolution for precise readings

✔ Industrial-Grade Reliability

Galvanic isolation (500V) between channels

Operating temperature: -40°C to +85°C

EMC/RFI protected for noisy environments

✔ Advanced Functionality

Open/short circuit detection

Lead resistance compensation (for 2-wire RTDs)

Configurable filtering for signal stability

✔ Flexible Integration

Modbus RTU/TCP communication

DIN-rail mounting for easy installation

LED status indicators for all channels

Technical Specifications
Parameter Specification
Manufacturer P/N 1MRS050644A1
Input Type RTD (Pt100, Pt1000, Ni100, Cu10, etc.)
Measurement Range -200°C to +850°C
Accuracy ±0.1°C (Pt100)
Resolution 0.01°C
Isolation 500V channel-to-system
Power Supply 24V DC (±20%)
Communication Modbus RTU (RS-485), Modbus TCP
Certifications CE, UL, ATEX (optional)
Typical Applications
Process Industry Temperature Monitoring

HVAC System Control

Power Plant Equipment Protection

Food & Beverage Processing

Pharmaceutical Manufacturing

Key Features:
Multi-function Relay: Supports configurable output contacts (NO/NC) for flexible use in alarm, tripping, or control circuits.

Wide Compatibility: Interfaces with ABB’s protection relays (e.g., REF, SPAJ, REC series) and other automation equipment.

Compact Design: Space-saving form factor for easy installation in panels or cabinets.

High Reliability: Robust construction with galvanic isolation to ensure noise immunity and safety.

LED Indicators: Visual status monitoring for relay operation and power supply.Technical Specifications:
Supply Voltage: 24–250V AC/DC (depending on variant)

Contact Rating: Typically 5–8A, 250V AC/DC

Standards Compliance: IEC, UL, CE
