Key Features
High Torque Density: Delivers exceptional torque in a compact form factor

Precision Performance: ±1 arc-minute positioning accuracy (model dependent)

Robust Construction: IP65-rated protection against dust and water jets

Smooth Operation: Low cogging design for vibration-free performance

Thermal Efficiency: Optimized cooling design for continuous duty operation

Technical Specifications
Frame Size: 90mm (EN23W standard)

Power Rating: 2kW (continuous)

Speed Range: 0-3000 RPM

Torque Output: 6.4 Nm (peak)

Feedback System: High-resolution encoder (20-bit absolute)

Voltage Rating: 200V AC (3-phase)

Protection Class: IP65

Connector Type: Waterproof industrial connector

Typical Applications
CNC machine tools

Robotics and automated assembly

Packaging machinery

Semiconductor manufacturing equipment

Printing and converting systems

Key Features
High Power Density: 1.5kW output in a compact 90mm frame size (EN23W standard)

Precision Performance: ±1 arc-minute positioning accuracy

Optimized Thermal Design: Advanced cooling for continuous duty operation

Robust Construction: IP65 protection rating (dust-tight and protected against water jets)

Smooth Operation: Low cogging design minimizes vibration

Integrated Feedback: High-resolution encoder (20-bit absolute) for precise positioning

Technical Specifications
Rated Power: 1.5kW

Rated Torque: 4.77Nm

Peak Torque: 14.3Nm

Speed Range: 0-3000 RPM

Voltage Rating: 200V AC (3-phase)

Frame Size: 90mm (EN23W)

Protection Class: IP65

Insulation Class: F

Bearing Type: Double shielded ball bearings

Connector: Waterproof industrial connector

Performance Characteristics
Torque Constant: 1.2Nm/A

Rotor Inertia: 1.8×10⁻³kg·m²

Electrical Time Constant: 2.5ms

Mechanical Time Constant: 5ms

Typical Applications
Industrial robotics

CNC machinery

Packaging equipment

Semiconductor manufacturing

Printing and converting systems

Automated assembly lines

Compatibility
Designed for seamless integration with ABB's:

ACSM1 servo drives

MicroFlex e150/e180 drives

Ability Motion Studio programming environment

Can be adapted to work with third-party servo drives

Certifications and Compliance
CE marked

UL recognized

RoHS compliant

REACH compliant

Environmental Specifications
Operating Temperature: 0°C to +40°C (ambient)

Storage Temperature: -20°C to +65°C

Altitude: Up to 1000m above sea level

Humidity: 20-80% RH (non-condensing)

Key Features
✔ High Dynamic Performance – Optimized for rapid acceleration/deceleration with low rotor inertia.
✔ Precision Positioning – Integrated high-resolution encoder (20-bit absolute) for ±1 arc-minute accuracy.
✔ Robust Construction – IP65 protection (dust-proof & resistant to water jets) for harsh environments.
✔ Efficient Cooling – Advanced thermal design for continuous duty operation without overheating.
✔ Smooth Operation – Low cogging and vibration for high-precision applications.

Technical Specifications
Parameter Specification
Rated Power 0.75 kW
Rated Torque 2.39 Nm
Peak Torque 7.16 Nm
Speed Range 0–3000 RPM
Voltage Rating 200V AC (3-phase)
Frame Size 90mm (EN23W standard)
Protection Class IP65
Feedback System 20-bit absolute encoder
Bearing Type Double-shielded ball bearings
Connector Type Industrial waterproof connector
Typical Applications
Industrial Robotics (articulated arms, SCARA, delta robots)

CNC Machining (milling, grinding, laser cutting)

Packaging Automation (pick-and-place, labeling, filling)

Semiconductor Handling (wafer transfer, chip placement)

Printing & Converting (web tension control, rotary die-cutting)Certifications & Compliance
CE Marked (EU compliance)

UL Recognized (North America)

RoHS & REACH Compliant (environmental standards)

Environmental & Mechanical Data
Operating Temp. 0°C to +40°C (derating above 40°C)

Storage Temp. -20°C to +65°C

Humidity 20–80% RH (non-condensing)

Weight ~5.2 kg

Key Features
✔ High Torque & Power Density – Optimized for compact installations without sacrificing performance.
✔ Precision Feedback – Integrated high-resolution encoder (17-bit or 20-bit optional) for closed-loop control.
✔ Robust Construction – IP65 protection (dust-tight & resistant to water jets) for harsh industrial environments.
✔ Low Cogging & Vibration – Ensures smooth motion in high-precision applications.
✔ Wide Speed Range – Suitable for both low-speed high-torque and high-speed operations.

Technical Specifications
Parameter Specification
Rated Power 0.6 kW (continuous)
Rated Torque 2.0 Nm
Peak Torque 6.0 Nm
Speed Range 0–3000 RPM (higher optional)
Voltage Rating 230V AC (3-phase)
Frame Size 60mm (compact flange design)
Protection Class IP65
Feedback System Incremental/absolute encoder
Bearing Type Preloaded ball bearings
Connector Type Waterproof MS/M12 connector
Typical Applications
Industrial Robots (articulated arms, delta robots)

CNC Machinery (milling, grinding, laser cutting)

Packaging Systems (pick-and-place, labeling, filling)

Semiconductor Equipment (wafer handling, wire bonding)

Medical Automation (lab instruments, surgical robots)Certifications & Compliance
CE Certified (EMC & Low Voltage Directive)

RoHS & REACH Compliant

UL Recognition (pending model-specific approval)

Environmental & Mechanical Data
Operating Temp. -10°C to +40°C (optional high-temp version available)

Storage Temp. -20°C to +70°C

Humidity 10–90% RH (non-condensing)

Weight ~3.8 kg

Key Specifications
Rated Power: 0.3kW

Rated Torque: 1.0Nm

Peak Torque: 3.0Nm

Speed Range: 0-3000rpm

Voltage Rating: 230V AC (3-phase)

Frame Size: 60mm flange type

Protection Class: IP65 (dustproof and water jet resistant)

Performance Features
High torque density design for space-constrained applications

Low cogging torque for smooth operation at low speeds

High-resolution encoder feedback (17-bit standard)

Excellent dynamic response with low rotor inertia

Optimized thermal characteristics for continuous duty operation

Mechanical Design
Double ball bearing construction

Standard 14mm shaft diameter with keyway

Flange mounting (B5 type)

Lightweight aluminum housing

Vibration-resistant construction

Electrical Characteristics
Class F insulation

Sinusoidal back EMF waveform

Low electrical noise generation

High efficiency (>90% typical)

Environmental Specifications
Operating temperature: 0°C to +40°C

Storage temperature: -20°C to +70°C

Humidity: 20% to 80% RH (non-condensing)

Altitude: Up to 1000m above sea level

Typical Applications
Small industrial robots

Precision assembly equipment

Semiconductor handling

Medical device manufacturing

Packaging machinery

Laboratory automation

Key Features
✔ Modular Design – Hot-swappable for easy maintenance and system scalability
✔ High-Speed Communication – Supports PROFIBUS, EtherCAT, or Modbus RTU/TCP (model-dependent)
✔ Wide Voltage Range – 24V DC operation with overvoltage/undervoltage protection
✔ Robust Construction – IP20/IP65 housing options for panel or field mounting
✔ Diagnostic LEDs – Real-time status monitoring (power, communication, I/O activity)

Technical Specifications
Parameter Specification
I/O Channels 8 digital inputs / 8 digital outputs (configurable)
Input Voltage 24V DC (sink/source compatible)
Output Type Relay / Transistor (model-specific)
Communication PROFIBUS DP / EtherCAT / Modbus
Operating Temp. -25°C to +60°C
Protection Rating IP20 (standard) / IP65 (optional)
Mounting DIN rail (TS-35/7.5)
Typical Applications
Factory Automation (conveyor control, assembly lines)

Process Control (chemical, water treatment)

Packaging Machinery (filling, labeling systems)

Energy Management (HVAC, power distribution)

Key Features & Benefits
✅ Ultra-High Power Handling

Voltage rating: 4500V

Current rating: 4000A (peak)

Optimized for high-power inverters & converters

✅ Advanced IGCT Technology

Low conduction & switching losses vs. traditional GTOs

Integrated gate driver for precise switching control

Short-circuit ruggedness for fault-tolerant operation

✅ Robust Mechanical Design

Press-pack housing for optimal thermal performance

Low-inductance terminal design

Forced-air or liquid-cooled configurations

✅ Industry-Leading Reliability

Designed for 24/7 operation in harsh environments

MTBF >100,000 hours in typical applications

Technical Specifications
Parameter Specification
Part Numbers 5SHY 3545L0016 (ABB ID)
3BHB020720R0002 (Order Code)
Device Type Asymmetric IGCT (with anti-parallel diode)
Voltage Rating VDRM = 4500V
Current Rating ITAV = 1200A (avg)
ITSM = 4000A (surge)
Switching Speed Turn-off time: <5µs
Thermal Resistance Rth(j-c) = 0.03 K/W
Mounting Bolt-clamped (press-pack)
Weight Approx. 2.5 kg
Typical Applications
⚡ Medium-Voltage Drives (e.g., ABB ACS 2000 series)
⚡ HVDC Power Transmission
⚡ Industrial Megawatt-Range UPS Systems
⚡ Renewable Energy Inverters (wind/solar farms)
⚡ Mining & Metals Industry (electrolytic processes)

Key Features
32-channel isolated digital input module

24V DC input voltage (sinking/sourcing configurable)

High-density design saves cabinet space

Galvanic isolation between channels and system

Hot-swappable for easy maintenance

Diagnostic LEDs per channel for status monitoring

Technical Specifications
Part Number: 3BSE008550R1

Input Type: Dry contact or wet contact (24V DC)

Input Current: 3-5mA typical

Isolation: 500V AC between channels

Response Time: <1ms

Operating Temperature: -25°C to +60°C

Protection Class: IP20 (panel-mounted)

Certifications: CE, UL, ATEX (optional)

Communication & Integration
Interfaces with ABB's S800 I/O system

Compatible with AC 800M controllers

Supports PROFIBUS DP and Foundation Fieldbus

Configurable via ABB Control Builder

Typical Applications
Process automation systems

Power generation plants

Oil & gas facilities

Chemical processing

Water treatment systems

Key Features
✔ PROFIBUS DP-V1 Master/Slave Support – Compliant with IEC 61158/61784
✔ High-Speed Data Exchange – Up to 12 Mbps (auto-negotiating)
✔ Redundancy Support – Optional dual-channel for fault-tolerant systems
✔ Hot-Swappable – Allows replacement without system shutdown
✔ Diagnostics & Monitoring – Built-in LED indicators for status & errors
✔ Wide Compatibility – Works with ABB AC 800M, S800 I/O, and third-party PROFIBUS devices

Technical Specifications
Parameter Specification
Model Number CI854BK01 (3BSE069449R1)
Communication Standard PROFIBUS DP-V1 (IEC 61158)
Data Rate 9.6 kbps – 12 Mbps (auto-sensing)
Connector 9-pin D-sub (RS-485)
Isolation 500V (galvanic isolation)
Power Supply 24V DC (via backplane)
Operating Temp. -25°C to +60°C
Certifications CE, UL, ATEX (optional)
Typical Applications
Process Automation (chemical, oil & gas, power plants)

Manufacturing & Factory Automation (PLC-to-drive communication)

Water/Wastewater Treatment

Mining & Metals Processing

Key Features
✔ PROFIBUS DP-V1 Master Functionality - Compliant with IEC 61158/61784 standards
✔ High-Speed Communication - Supports baud rates from 9.6 kbps to 12 Mbps (auto-negotiating)
✔ Robust Industrial Design - Operates in harsh environments (-25°C to +60°C)
✔ Comprehensive Diagnostics - LED indicators for power, status, and network activity
✔ Hot-Swappable - Allows replacement without system shutdown (when used in redundant configuration)
✔ Flexible Configuration - Supports up to 244 bytes of input/output data

Technical Specifications
Parameter Specification
Article Number 3BSE030221R1
Interface Type PROFIBUS DP-V1 (RS-485)
Connector 9-pin D-sub male
Power Supply 24V DC via backplane
Isolation 500V galvanic isolation
Data Transfer Cyclic and acyclic
Certifications CE, UL, ATEX (optional)
Typical Applications
Process control systems in oil & gas facilities

Power generation and distribution systems

Chemical and pharmaceutical plants

Water and wastewater treatment plants

Manufacturing automation systems
