Key Specifications

Power Rating: 0.1 kW (0.13 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 0.6A

Overload Capacity: 150% for 3 seconds

Control Method: Sensorless vector control

Switching Frequency: Up to 16kHz (adjustable)

Main Features

1. Compact & Efficient Design

Industry's smallest footprint in its class (70×170×145mm)

Lightweight (0.6kg) IP20 enclosure

Optional IP66/NEMA 4X kit available

Built-in EMC filter (Class A)

2. Advanced Motor Control

Sensorless vector control technology

Automatic motor adaptation (AMA)

Flying start capability

Torque boost function

3. Application Flexibility

3 pre-programmed application macros

Customizable application programs

Built-in PID controller

Standard Interfaces

Control Terminals:

2 analog inputs (0-10V/4-20mA)

4 digital inputs

1 relay output

Communication:

RS485 (Modbus RTU standard)

Optional fieldbus adapters available

Physical Characteristics

Dimensions: 70×170×145mm (W×H×D)

Weight: 0.6kg

Cooling: Natural convection

Ambient Temperature: -10°C to +50°C

Key Specifications

Power Rating: 0.1 kW (0.13 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 0.6 A

Overload Capacity: 150% for 3 seconds

Control Method: Scalar (V/f) control

Switching Frequency: 2-16 kHz (adjustable)

Main Features

1. Compact Design

Ultra-small footprint (70 × 170 × 145 mm)

Lightweight construction (0.6 kg)

IP20 enclosure (open chassis)

Optional IP66 protection kit available

2. Basic Control Functions

V/f control with torque boost

3 preset speed settings

DC injection braking

Automatic restart after fault

3. Standard Interfaces

2 analog inputs (0-10V/4-20mA)

3 digital inputs

1 relay output

RS485 (Modbus RTU) communication

Application Highlights

Small fans and blowers

Laboratory equipment

Conveyor systems

Basic pump control

Light material handling

Certifications & Compliance

CE Marked

UL Recognized

RoHS Compliant

EN 61800-3 EMC Standards

Key Specifications:

Power Rating: 0.25 kW (0.33 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 1.0 A

Overload Capacity: 150% for 3 seconds

Control Technology: Flux-optimized DTC (Direct Torque Control)

Switching Frequency: Up to 16 kHz (adjustable)

Main Features:

1. Advanced Motor Control:

Sensorless vector control with 0.5% speed accuracy

Automatic motor adaptation (AMA)

Torque control mode (±3% accuracy)

Flying start and DC braking

2. Application-Specific Functions:

5 pre-programmed application macros

Customizable application programs

Built-in PID controller with sleep/wake function

Pump and fan control curves

3. Enhanced Connectivity:

Standard RS485 (Modbus RTU)

Optional fieldbus adapters:

PROFIBUS DP-V1

DeviceNet

CANopen

USB service port for quick parameter transfer

Physical Characteristics:

Enclosure Rating: IP20 (open type)

Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.65 kg

Cooling Method: Natural convection

Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

Key Specifications:

Power Rating: 0.37 kW (0.5 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 1.6 A

Overload Capacity: 150% for 3 seconds

Control Method: Open-loop vector control

Switching Frequency: 2-16 kHz (adjustable)

Main Features:

Compact Design:

Ultra-compact IP20 enclosure

Built-in EMC filter (Class A)

Optional IP66/NEMA 4X protection kit available

Advanced Motor Control:

Sensorless vector control technology

Automatic motor adaptation (AMA)

Flying start function

Torque boost capability

Application Flexibility:

3 pre-programmed application macros

Customizable application programs

Built-in PID controller

Standard Interfaces:

Control Terminals:

2 analog inputs (0-10V/4-20mA)

4 digital inputs

1 relay output

1 analog output (0/4-20mA)

Communication Options:

Built-in Modbus RTU (RS485)

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics:

Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.7 kg

Cooling: Natural convection

Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

Key Specifications:

Power Rating: 0.75 kW (1 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 2.4 A

Overload Capacity: 150% for 3 seconds

Control Method: Open-loop vector control

Switching Frequency: Up to 16 kHz

Main Features:

Compact Design:

Space-saving IP20 enclosure

Built-in EMC filter (Class A)

Optional IP66/NEMA 4X kit available

Advanced Control:

Sensorless vector control

Automatic motor adaptation (AMA)

Flying start function

Torque boost

Application Macros:

Factory preset configurations

Customizable application programs

Built-in PID controller

Standard Interfaces:

Control Terminals:

2 analog inputs (0-10V/4-20mA)

4 digital inputs

1 relay output

1 analog output

Communication Options:

Built-in Modbus RTU (RS485)

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics:

Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.8 kg

Cooling: Convection cooling

Ambient Temperature: -10°C to +50°C (14°F to 122°F)

Key Specifications
Power Rating: 5.5 kW (7.5 HP)

Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz

Output Current: 12 A

Overload Capacity: 110% for 60s, 150% for 3s

Control Method: Scalar (V/f) & Sensorless Vector Control (optional)

Switching Frequency: 1–16 kHz (adjustable)

Efficiency: >97%

Main Features
✔ Energy-Saving Operation

Automatic Energy Optimizer reduces motor losses

Sleep/Wake function for pump & fan applications

✔ Built-in Application Macros

Pre-configured settings for pumps, fans, and constant torque applications

PID controller for pressure/flow control

✔ Protection & Safety

Motor thermal protection (PTC input)

Short-circuit, overvoltage, and ground fault protection

IP21 enclosure (basic dust protection)

✔ Connectivity & Control

Standard RS485 (Modbus RTU)

2 analog inputs (0–10V/4–20mA), 3 digital inputs, 1 relay output

Optional fieldbus adapters (Profibus, BACnet, etc.)

✔ User-Friendly Interface

Integrated control panel with LED display

Quick start-up wizard for easy commissioning

Physical & Environmental Specifications
Enclosure Rating: IP21 (open chassis)

Cooling Method: Convection cooling (fanless design)

Ambient Temperature: -10°C to +50°C (14°F to 122°F)

Dimensions (W×H×D): 150 × 200 × 165 mm

Weight: 2.1 kg

Key Specifications
Power Rating: 500 kW (670 HP)

Input Voltage: 3-phase 380–500V AC (±10%), 50/60 Hz

Output Current: 850 A

Overload Capacity: 110% continuous, 150% for 60s

Control Method: Sensorless Vector Control (DTC option available)

Efficiency: >98%

Switching Frequency: Adjustable (2–8 kHz)

Main Features
✔ Advanced Motor Control

Sensorless vector control for precise speed regulation

Automatic motor adaptation (AMA) for optimal performance

Flying start and torque boost functions

✔ Built-in Application Macros

Pre-programmed settings for pumps, fans, conveyors, and compressors

Customizable logic with PID controller (for pressure/flow control)

✔ Protection & Safety

Motor thermal protection (PTC/KTY support)

Short-circuit, overvoltage, and ground fault protection

Safe Torque Off (STO) for emergency stop compliance

✔ Connectivity & Communication

Standard RS485 (Modbus RTU)

Optional fieldbus modules (Profibus, Ethernet/IP, Modbus TCP)

ABB Drive Composer software for easy configuration

✔ User-Friendly Interface

Integrated keypad with LCD display

Quick setup with assisted startup wizard

Parameter backup via USB

Physical & Environmental Specifications
Enclosure Rating: IP21 (open chassis)

Cooling Method: Forced air cooling (fans included)

Ambient Temperature: 0–40°C (32–104°F) without derating

Dimensions (W×H×D): 800 × 1800 × 400 mm

Weight: Approx. 200 kg

Technical Specifications:

Main Drive Unit (ACS880-04-725A-3):

Power Rating: 725 kW (971 HP)

Input Voltage: 3-phase 380-500V AC (-15%/+10%)

Output Current: 1040 A

Overload Capacity: 110% continuous, 150% for 60s

Control Technology: DTC (Direct Torque Control)

Efficiency: >98.5%

Switching Frequency: 1-4 kHz (adjustable)

D150 Control Panel Features:

7" color touchscreen display

Multilingual interface (20+ languages)

Real-time process monitoring

Built-in trend recorder

Password protection levels

USB port for parameter transfer

Key System Features:

Advanced Control Capabilities:

Sensorless vector control (SLVC)

Encoderless speed control (±0.1% accuracy)

Torque control mode (±2% accuracy)

Adaptive programming capability

Application-Specific Functions:

Multiple application macros

Customizable logic functions

Built-in safety functions (STO, SS1, SLS)

Advanced PID controller

Protection & Monitoring:

Motor thermal protection (PTC/KTY84)

Ground fault detection

Input phase monitoring

DC link monitoring

IGBT temperature monitoring

Communication Interfaces:

Standard:

Modbus RTU (RS485)

Ethernet

Optional:

PROFIBUS DP

PROFINET

EtherNet/IP

CANopen

Physical Specifications:

Drive Dimensions: 900 × 2200 × 600 mm (W×H×D)

Control Panel Dimensions: 210 × 170 × 60 mm

Weight: 320 kg (drive only)

Cooling: Liquid cooling system

Ambient Temperature: 0-40°C (32-104°F)

Certifications & Compliance:

CE

UL

cULus

DNV GL

IEC 61800-3

ISO 13849-1 (PL e)

Technical Specifications:

Power Rating: 2.2 kW (3 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 5.2 A

Overload Capacity: 150% for 60 seconds

Control Technology: DTC (Direct Torque Control)

Encoder Interface: N671 module for incremental encoders

Key Features:

Precision Control:

Closed-loop vector control with encoder feedback

±0.01% speed accuracy (with encoder)

0.1 Hz speed control range

Encoder Module (N671):

Supports 5V/24V incremental encoders

Resolution up to 4096 ppr

Differential (RS422) and single-ended inputs

LED status indicators

Technical Specifications:

Power Rating: 37 kW (50 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 65 A

Overload Capacity: 150% for 60 seconds

Control Technology: DTC (Direct Torque Control)

Frequency Range: 0-500 Hz

Efficiency: >98%

Key Features:

Advanced Control Capabilities:

Sensorless vector control

Automatic motor adaptation

Torque control mode

Flying start function

Application-Specific Functions:

Built-in PID controller

Pump and fan control curves

Multiple preset macros

Custom application programming

Protection Systems:

Motor thermal protection

Short circuit protection

Ground fault detection

Input phase monitoring

Standard Interfaces:

Control Terminals:

2 analog inputs (0-10V/4-20mA)

3 digital inputs

2 relay outputs

1 analog output (0/4-20mA)

Communication:

RS485 (Modbus RTU standard)

Optional fieldbus adapters available

Physical Characteristics:

Enclosure: IP21 (open chassis)

Dimensions: 350 × 482 × 227 mm (W × H × D)

Weight: 18.5 kg

Cooling: Forced air cooling

Ambient Temperature: 0-40°C (32-104°F) without derating
