Key Features & Benefits
1. High-Speed Industrial Communication
Dual-Port PROFINET & Ethernet (10/100 Mbps, auto-negotiation)

PROFINET RT (Real-Time) and IRT (Isochronous Real-Time) support for deterministic control

Integrated switch functionality for daisy-chaining devices

2. Robust Industrial Design
Wide operating temperature range (-20°C to +60°C)

High EMC immunity (EN 61000-6-2) for harsh environments

DIN-rail mounting for easy installation

3. Seamless Integration with ABB AC 500 PLCs
Plug-and-play installation with AC500 controllers

Configuration via Automation Builder (ABB’s engineering tool)

LED diagnostics for quick troubleshooting

4. Cybersecurity & Network Management
VLAN & QoS support for traffic prioritization

Password protection & access control for secure operation

SNMP monitoring for network diagnostics

Technical Specifications
Parameter Specification
Ethernet Standard IEEE 802.3 (10/100 Mbps)
Protocols PROFINET RT/IRT, Modbus TCP, DHCP
Ports 2x RJ45 (auto-MDI/MDIX)
Power Consumption 1.8W typical
Certifications CE, UL, IEC 61131, PROFINET Conformance Class B

Key Features
Dual-Port Ethernet Connectivity

2x 10/100/1000 Mbps RJ45 ports with auto-negotiation

Integrated switch functionality for daisy-chaining

PROFINET RT/IRT, EtherNet/IP, and Modbus TCP support

Industrial Reliability

-40°C to +70°C operating temperature range

High EMC immunity (EN 61000-6-2, IEC 61850-3)

DIN-rail mountable with vibration-resistant design

Advanced Networking Capabilities

IEEE 1588 Precision Time Protocol (PTP) support

VLAN and QoS for traffic prioritization

Integrated firewall and security features

Seamless Integration

Plug-and-play with AC500 PLC systems

Configuration via ABB Automation Builder

Comprehensive LED diagnostics

Technical Specifications
Parameter Specification
Ethernet Standard IEEE 802.3 (1000BASE-T)
Protocols PROFINET, EtherNet/IP, Modbus TCP
Ports 2x RJ45 (shielded)
Latency <1 μs (switch mode)
Power Consumption 3.5W typical
Certifications UL, CE, IEC 61850-3, IEEE 1613

Key Features & Benefits
Robust Industrial Connectivity

10/100 Mbps Ethernet with auto-negotiation

RJ45 connector with industrial-grade shielding

IEEE 802.3 compliant for standard compatibility

Industrial-Grade Reliability

Operating temperature: -25°C to +60°C

High resistance to vibration and electrical noise

DIN-rail mountable design for easy installation

Comprehensive Protocol Support

Modbus TCP protocol for industrial communication

Transparent ready for system integration

DHCP support for automatic IP configuration

Enhanced System Integration

Plug-and-play installation with AC500 PLCs

Configuration via ABB Automation Builder software

LED status indicators for quick diagnostics

Technical Specifications
Parameter Specification
Ethernet Standard IEEE 802.3 (10BASE-T/100BASE-TX)
Protocol Support Modbus TCP, DHCP
Connector 1x RJ45 (shielded)
Power Consumption 1.5W typical
Certifications CE, UL, IEC 61131

Key Features & Benefits
Advanced Ethernet Connectivity

10/100/1000 Mbps Gigabit Ethernet port

Auto-negotiation and auto-MDI/MDIX capability

PROFINET, EtherNet/IP, and Modbus TCP protocol support

Industrial-Grade Durability

Extended temperature range (-40°C to +70°C)

High EMC immunity (EN 61000-6-2, IEC 61850-3)

Vibration-resistant DIN-rail mounting design

Enhanced Network Performance

IEEE 1588 Precision Time Protocol (PTP) support

VLAN and QoS for traffic prioritization

Integrated firewall for network security

Seamless System Integration

Plug-and-play with AC500 PLC systems

Configuration via ABB Automation Builder

Comprehensive LED diagnostics indicators

Technical Specifications
Parameter Specification
Ethernet Standard IEEE 802.3 (1000BASE-T)
Protocols PROFINET, EtherNet/IP, Modbus TCP
Connector 1x RJ45 (shielded)
Latency <1 μs
Power Consumption 2.5W typical
Certifications UL, CE, IEC 61850-3, IEEE 1613

Key Features & Benefits
PROFIBUS DP Connectivity

Supports PROFIBUS DP-V0 and DP-V1 protocols

Transmission rates up to 12 Mbps

9.6 kbps to 12 Mbps auto-baud rate detection

Industrial-Grade Reliability

Operating temperature: -25°C to +60°C

High immunity to electromagnetic interference

DIN-rail mountable design

Flexible Configuration

Configurable as DP Master or Slave

Supports up to 244 bytes of input/output data

GSD file available for easy integration

Diagnostic Capabilities

Comprehensive LED status indicators

Detailed diagnostic information available in controller

Bus error detection and reporting

Technical Specifications
Parameter Specification
Bus Protocol PROFIBUS DP (EN 50170)
Transmission Rate 9.6 kbps - 12 Mbps
Interface RS-485 (9-pin D-sub connector)
Maximum Stations 125 (with repeater)
Power Consumption 1.8W typical
Certifications CE, UL, PROFIBUS International

Key Features & Benefits
Fieldbus Power Conditioning

Provides galvanic isolation between control system and field networks

Integrated power conditioning with surge protection

Supports FOUNDATION Fieldbus (FF) and PROFIBUS PA standards

Robust Industrial Design

-40°C to +70°C operating temperature range

High immunity to EMI/RFI interference

Compact DIN-rail mounting (1/8 DIN size)

Advanced Protection Features

Short-circuit and overload protection

Polarity reversal protection

Redundant power supply options available

Diagnostic Capabilities

LED status indicators for power and network health

Remote monitoring capability via control system

Technical Specifications
Parameter Specification
Input Voltage 18-32V DC
Output Voltage FOUNDATION Fieldbus compliant
Maximum Current 500mA (field side)
Isolation Voltage 1500V DC
Certifications ATEX, IECEx, UL, CE

Key Features & Benefits
High-Efficiency Power Conversion

93% typical efficiency rating

Active power factor correction (PFC >0.95)

Wide input voltage range (85-264V AC)

Industrial-Grade Reliability

-25°C to +70°C operating temperature

150% power reserve for peak loads

50ms buffering time at full load

Advanced Protection Features

Short-circuit, overload, and overvoltage protection

Automatic recovery function

Reverse polarity protection

Flexible Installation

Compact DIN-rail design (105mm width)

Plug-in screw terminal connections

Status LED indicators

Technical Specifications
Parameter Specification
Input Voltage 85-264V AC (47-63Hz)
Output Voltage 24V DC (±0.5%)
Output Current 6.3A (150% peak for 5s)
Power Rating 150W
Efficiency 93% typical
Protection IP20 (front panel)
Certifications UL, CE, cULus, EN 60950
Typical Applications
✔ PLC control cabinets
✔ Industrial machinery power systems
✔ Process automation panels
✔ Motor control centers
✔ Robotics and assembly systems

Key Features
Enhanced Processing Performance

32-bit RISC processor @ 300 MHz

4MB program memory / 4MB data memory

0.1ms typical instruction execution time

Versatile Communication

Integrated RS232/RS485 ports

Supports PROFIBUS DP, CANopen, and Ethernet (via expansion)

SD card slot for program backup

Industrial Durability

Operating temperature: -25°C to +60°C

Vibration resistant (5g @ 10-150Hz)

Compact design (45mm width)

Programming Flexibility

Supports all IEC 61131-3 languages

Compatible with ABB Automation Builder

Online modification capability

Technical Specifications
Parameter Specification
Processor 32-bit RISC @ 300MHz
Memory 4MB Flash, 4MB RAM
Digital I/O Up to 16,000 points (expandable)
Analog I/O Up to 2,000 channels (expandable)
Communication 1x RS232, 1x RS485
Power Consumption 8W typical
Certifications CE, UL, cULus
Typical Applications
✔ Machine automation
✔ Packaging systems
✔ Material handling
✔ Building management
✔ Water treatment plants

Key Features & Benefits
Crisp Display & Touch Interface

5.7" STN LCD with LED backlight (320 x 240 pixels)

Resistive touch screen for glove-friendly operation

65K color support for clear visualization

Industrial Durability

IP65-rated front panel protection

-20°C to +60°C operating temperature range

Vibration and shock resistant design

Flexible Connectivity

Integrated RS232/RS422/RS485 ports

USB 2.0 host port for data transfer

Supports ABB, Modbus, and other major protocols

Easy Integration

Pre-installed CODESYS runtime

Compatible with ABB Automation Builder

Plug-and-play with AC500 PLC systems

Technical Specifications
Parameter Specification
Display Size 5.7" diagonal
Resolution 320 x 240 pixels
Touch Technology Resistive (single-touch)
Processor 32-bit RISC @ 400MHz
Memory 128MB Flash / 64MB RAM
Communication 1x RS232/422/485, 1x USB 2.0
Power Supply 24V DC (18-32V range)
Protection Rating IP65 (front)
Typical Applications
✔ Machine operation panels
✔ Process control monitoring
✔ Packaging equipment interfaces
✔ Building automation systems
✔ Small-scale SCADA visualization

Key Features & Benefits
High Channel Density

32-channel isolated digital inputs

Supports both 24V DC and 48V DC field signals

Individual channel diagnostics

Industrial-Grade Reliability

-40°C to +70°C operating temperature

High EMI/RFI immunity (EN 61000-6-2)

Hot-swappable design (with carrier module)

Advanced Diagnostics

Per-channel LED status indicators

Open wire detection

Group fault reporting

Flexible Configuration

Configurable filter times (0.1ms to 20ms)

Supports both sinking and sourcing inputs

Compatible with redundant systems

Technical Specifications
Parameter Specification
Input Channels 32 (electrically isolated)
Input Voltage 24V DC (19-30V) / 48V DC (38-60V)
Input Current 3mA typical (24V)
Isolation 500V channel-to-channel
Response Time Configurable 0.1-20ms
Power Consumption 2.5W typical
Certifications UL, CE, ATEX, IECEx
Typical Applications
✔ Power plant control systems
✔ Oil & gas process automation
✔ Water treatment monitoring
✔ Discrete manufacturing
✔ Safety interlock systems
