Technical Parameters Parameter Specification Model Fisher C1 Type Self-Operated Temperature Regulator Operating Principle Liquid-Filled Thermal System (Remote Bulb and Capillary Tube) Body Materials Cast Iron (Standard), Bronze, Ductile Iron, Carbon Steel End Connections Screwed (NPT), Flanged Size Range 1/2" to 2" (DN 15 to DN 50) Temperature Setting Range Various ranges available, e.g., 50°F to 250°F (10°C to 121°C), depending on bulb fill and spring. Pressure Rating Up to 250 psig (17 bar), depending on body material. Bulb Material Brass or Stainless Steel Capillary Tube Length Standard lengths available, e.g., 6 ft (1.8 m) or 10 ft (3 m).

Technical Parameters Parameter Specification / Options Series Fisher Baumann 24000 Type Cage-Guided Globe Control Valve (Balanced Trim) Flow Characteristic Linear, Equal Percentage Body Styles Globe, Angle End Connections Screwed (NPT), Flanged (ANSI Class 150 to 600) Body Materials Carbon Steel (WCB), Stainless Steel (CF8/CF8M) Trim Materials Stainless Steel, Hardened Stainless Steel Pressure Rating ANSI Class 150 to 600 Temperature Range -20°F to 800°F (-29°C to 427°C) with special designs and materials. Size Range 1/2" to 2" (DN 15 to DN 50) Noise Reduction Capable of significant noise attenuation (15+ dBA) with appropriate trim. Leakage Class ANSI Class IV (Standard), ANSI Class V & VI available.

Technical Parameters Parameter Specification Model Fisher A11 (with suffix for action: e.g., A11D, A11R) Type Spring-Return Diaphragm Actuator Action Direct (A11D) or Reverse (A11R) Standard Signal Range 3 to 15 psig (0.2 to 1.0 bar) Supply Pressure Range Up to 45 psig (3.1 bar) for the 3-15 psig range. Spring Ranges Multiple springs available for different thrust outputs and fail-safe actions. Effective Area Varies by size. Example (Size 20): 32 in² (206 cm²) Stem Thrust Varies by size and air pressure. Example (Size 20 at 15 psig): ~480 lb (2135 N) Stroke Lengths Available in various standard strokes, e.g., 0.5 to 1.5 inches (12.7 to 38.1 mm). Temperature Limits -20°F to 150°F (-29°C to 66°C) with standard Buna-N diaphragm. Diaphragm Material Buna-N with nylon cloth (standard)

Technical Parameters Parameter Specification Model Fisher 3620J Type Double-Acting, Piston Actuator (Scotch Yoke) Action Double-Acting (Air-to-Open / Air-to-Close) Standard Travel 90° quarter-turn. Body Material Cast Aluminum Piston Material Steel Operating Pressure Range 50 to 150 psig (3.4 to 10.3 bar) is standard. Torque Output Varies by size and supply pressure. Example (at 120 psig): - Size 30: ~ 2,200 lb-in (249 Nm) - Size 70: ~ 12,500 lb-in (1,412 Nm) - Size 100: ~ 25,000 lb-in (2,824 Nm) Sizes (Frame Size) 30, 40, 50, 60, 70, 80, 100, 120

Technical Parameters Parameter Specification Model Fisher 3024C Type Pilot-Operated Pressure Reducing Regulator Body Materials Ductile Iron (Standard), Cast Iron, Carbon Steel End Connections Flanged (ANSI Class 150, 300, 600); Butt-Weld Size Range (Main Valve) 2" to 8" (DN 50 to DN 200) Maximum Inlet Pressure (P1) Up to 1440 psig (99 bar) for ANSI 600 models. Outlet Pressure Range (P2) Wide range available via interchangeable pilot springs. Temperature Range -20°F to 150°F (-29°C to 66°C) with standard elastomers. Flow Capacity (Cv) Very high. Example (2" 3024C): Cv ~ 45 Accuracy (Droop) Excellent, typically less than 5% of the setpoint due to pilot-operated design. Pilot Options Available in various setpoint ranges.

Technical Parameters Parameter Specification Model Fisher 1008 Type Unbalanced, Top-Guided, Flanged Globe Valve Trim Type Unbalanced Trim (Standard) Flow Characteristic Equal Percentage or Linear (depending on plug selection) End Connections ANSI Class 150, 300, or 600 Flanged (RF or RTJ) Body Materials Carbon Steel (WCB), Stainless Steel (CF8, CF8M), Ductile Iron Trim Materials Stainless Steel (Standard) Temperature Range -20°F to 850°F (-29°C to 454°C) depending on body/trim materials and seat gasketing. Pressure Rating ANSI Class 150: 275 psig (19 bar) ANSI Class 300: 720 psig (49.6 bar) ANSI Class 600: 1440 psig (99.3 bar) Leakage Class ANSI Class IV (Standard) ANSI Class VI (Soft Seat) options available. Sizes (Pipe Size) 1" to 8" (DN 25 to DN 200)

Technical Parameters Parameter Specification Model Fisher CAV III Type High Capacity, Constant Bleed Volume Booster / Relay Pressure Ratio 1:1 (Standard) Supply Pressure Range Up to 150 psig (10.3 bar) Input & Output Signal Range Typically 3 to 15 psig (0.2 to 1.0 bar) or 3 to 27 psig (0.2 to 1.9 bar)，取决于弹簧范围。 Constant Bleed Rate Approximately 0.5 SCFM (0.85 m³/hr). Flow Capacity (Cv) Approximately 3.0 (非常高) Body Material Aluminum Connection Size 1/4" NPT (Input, Output, and Supply) Operating Temperature -40°F to 180°F (-40°C to 82°C) with standard Buna-N seals. Mounting Panel mount or directly onto a valve actuator/positioner bracket.

Technical Parameters Parameter Specification Model Fisher Yarway 25 Type Thermodynamic (Disc) Steam Trap Operation Intermittent (Cycles open and closed) Body Material Forged Carbon Steel (Standard), Stainless Steel Internals Stainless Steel Disc and Seat Connection Screwed (NPT) Maximum Working Pressure Up to 600 psig (41 bar) Maximum Working Temperature Up to 800°F (427°C) Continuous Working Pressure Range 30 to 600 psig (2 to 41 bar)

Technical Parameters Parameter Specification Model Fisher 1080 Type Balanced, Cage-Guided, Flanged Globe Valve Trim Type Balanced Trim Flow Characteristic Linear, Equal Percentage (via different cages/plugs) End Connections Flanged (ANSI Class 150, 300, 600, 900) Body Materials Carbon Steel (WCB), Stainless Steel (CF8, CF8M), Alloy Steel Trim Materials Stainless Steel (Standard), hardened materials available for severe service. Temperature Range -450°F to 1100°F (-268°C to 593°C) with special designs and materials. Pressure Rating ANSI Class 150: 275 psig (19 bar) ANSI Class 300: 720 psig (50 bar) ANSI Class 600: 1440 psig (99 bar) ANSI Class 900: 2160 psig (149 bar) Leakage Class ANSI Class IV (Standard), ANSI Class V & VI options available. Sizes (Pipe Size) 1" to 12" (DN 25 to DN 300)

Technical Parameters Parameter Specification Model Fisher Vee-Ball V150 Type Rotary V-Notch Ball Control Valve Flow Characteristic Equal Percentage (inherent from the V-notch profile) Shut-Off Class ANSI Class VI (Bubble-tight) with standard non-metallic seats. End Connections Flanged (ANSI Class 150 & 300) Body Materials Ductile Iron, Carbon Steel (WCB), Stainless Steel (CF8) Ball & Stem Material Stainless Steel (standard) Seat Material Reinforced PTFE (RPTFE), Ultra-High Molecular Weight Polyethylene (UHMW-PE) Temperature Range -40°F to 400°F (-40°C to 204°C) with standard polymeric seats. Pressure Rating ANSI Class 150: 275 psig (19 bar) ANSI Class 300: 720 psig (49.6 bar) Flow Capacity (Cv) Varies by size. Example (Class 150 Flanged, 6"): Cv ~ 1150 Sizes (Pipe Size) 1" to 12" (DN 25 to DN 300)
