Technical Parameters Category Specification Product Model 93PR Product Family Eaton 93P Series UPS Topology Double Conversion Online (Three-Phase) Power Range 500-1600 kVA (scalable) Input Characteristics - Voltage 380/400/415V AC, 3PH + N - Frequency 50/60 Hz (auto-sensing) - Input Power Factor >0.99 - THDi <3% at full load Output Characteristics - Voltage 380/400/415V AC, 3PH + N - Frequency 50/60 Hz (±0.1% static) - Waveform Pure Sine Wave - Efficiency Up to 97% (in online mode) - Overload Capability 125% for 10 minutes, 150% for 1 minute Battery System - Battery Voltage 480V DC (standard) - Battery Technology VRLA or Lithium-ion options - Runtime Configurable based on battery cabinets - Recharge Time <4 hours to 90% capacity Physical Specifications - Configuration Modular, N+X redundant - Form Factor Power module + system cabinet - Dimensions Varies by configuration Environmental - Operating Temperature 0°C to 40°C - Operating Humidity 0-95% non-condensing - Audible Noise <75 dBA at 1 meter Communications - Interfaces Ethernet, SNMP, USB, RS-232 - Management Eaton Intelligent Power Manager

Technical Parameters Category Specification Product Model EATS16A Product Family Eaton Automatic Transfer Switches Rated Current 16A Number of Poles 2 poles Rated Operational Voltage 230V AC Rated Frequency 50/60 Hz Short-Circuit Capacity 6kA Utilization Category AC-33A Mechanical Life 10,000 operations Electrical Life 1,000 operations at rated current Control Voltage 230V AC Operating Temperature -25°C to +60°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (for indoor installation) Standards Compliance IEC 60947-6-1, CE

Technical Parameters Category Specification Product Model EATS16CN Product Family Eaton Automatic Transfer Switches Rated Current 16A Number of Poles 2 poles Rated Operational Voltage 230V AC Rated Frequency 50/60 Hz Short-Circuit Capacity 6kA Utilization Category AC-33A Mechanical Life 10,000 operations Electrical Life 1,000 operations at rated current Control Voltage 230V AC Operating Temperature -25°C to +60°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 Standards Compliance IEC 60947-6-1, CE, CCC

Technical Parameters Category Specification Product Model NZMH2-A63 Product Family Eaton NZM H-series Miniature Circuit Breakers Number of Poles 2 poles Rated Current 63A Rated Voltage 230/400V AC Rated Frequency 50/60 Hz Breaking Capacity 10kA (at 400V AC) Tripping Characteristic C-characteristic (medium trip) Standards Compliance IEC 60898-1, CE Electrical Life 10,000 operations Mechanical Life 20,000 operations Operating Temperature -25°C to +55°C Storage Temperature -40°C to +85°C Protection Degree IP20 (when installed in enclosure) Electrical Characteristics Rated Insulation Voltage: 500V Impulse Withstand Voltage: 6kV Power Loss: <3W per pole Terminal Capacity: 35 mm² max cable size Tripping Characteristics Instantaneous Trip: 5-10 × In (C-characteristic) Thermal Trip: 1.13 × In, t > 1 hour (no trip) Magnetic Trip: 1.45 × In, t < 1 hour (trip) Mechanical Specifications Mounting: DIN rail (35mm) Connection: Screw terminals Torque Requirement: 2.5-3.0 Nm Weight: Approximately 0.4 kg Dimensions: 90 × 35 × 78 mm (H×W×D)

Technical Parameters Category Specification Product Model MATSG-200/3P Product Family Eaton MATSG Automatic Transfer Switch Series Rated Current 200A Number of Poles 3 poles Rated Operational Voltage 400V AC Rated Insulation Voltage 690V AC Rated Frequency 50/60 Hz Short-Time Withstand Current 15kA (1 second) Utilization Category AC-33A Mechanical Life 8,000 operations Electrical Life 800 operations at rated current Control Voltage 24V DC / 230V AC (depending on configuration) Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Relative Humidity 95% (non-condensing) Protection Degree IP20 (for enclosure mounting) Standards Compliance IEC 60947-6-1, CE

Technical Parameters Category Specification Product Model DIL M185A Product Family Eaton DIL M-series Motor Protection Circuit Breakers Number of Poles 3 poles Rated Current 185A Rated Operational Voltage 690V AC Rated Insulation Voltage 1000V AC Rated Frequency 50/60 Hz Breaking Capacity 100kA (at 415V AC) Utilization Category AC-3 (for squirrel cage motors) Motor Power Rating Up to 90kW (at 400V AC) Standards Compliance IEC/EN 60947-2, IEC/EN 60947-4-1, CE, UL Electrical Life 5,000 operations Mechanical Life 10,000 operations Operating Temperature -25°C to +70°C Protection Degree IP20 (when installed in enclosure) Protection Characteristics Overload Protection: Adjustable 0.7-1.0 × In Short-Circuit Protection: Magnetic instantaneous trip Phase Failure Protection: Built-in protection Trip Class: Class 10 (standard) Electrical Characteristics Rated Service Short-Circuit Capacity (Ics): 65kA Rated Ultimate Short-Circuit Capacity (Icu): 100kA Power Loss: <25W per pole Terminal Capacity: 185 mm² max cable size Mechanical Specifications Mounting: Fixed mounting or adapter plate Connection: Screw terminals Torque Requirement: 40-50 Nm Weight: Approximately 4.5 kg Dimensions: 158 × 105 × 140 mm (H×W×D)

Technical Parameters Category Specification Product Model NZM1-XU Product Family Eaton NZM1 Accessories Device Type Undervoltage Release Rated Control Voltage 230V AC / 400V AC Operating Voltage Range 0.7-1.1 × Us (rated control voltage) Release Voltage <0.35 × Us (must trip) >0.85 × Us (must not trip) Power Consumption Approx. 20VA (during operation) Operating Time <100ms Mounting Position Can be mounted on left or right side Compatibility NZM1 series circuit breakers Electrical Life >1,000 operations Mechanical Life >10,000 operations Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Protection Degree IP20 (when installed in breaker) Standards Compliance IEC/EN 60947-2 Electrical Characteristics Rated Insulation Voltage: 690V AC Dielectric Strength: 2500V AC (1 minute) Insulation Resistance: >100MΩ (at 500V DC) Connection Method: Screw terminals Mechanical Specifications Mounting: Direct mounting on NZM1 breaker Weight: Approximately 0.3-0.5 kg (depending on breaker size) Connection: Fixed wiring connection

Technical Parameters Category Specification Product Model NZM2/3-XA 208250V AC/DC Product Family Eaton NZM Accessories Device Type Shunt Trip Release Rated Control Voltage 208-250V AC/DC Operating Voltage Range 0.7-1.1 × Us Power Consumption AC: 20VA (inrush), 8VA (hold) DC: 20W (inrush), 8W (hold) Operating Time <50ms Mounting Compatibility NZM2 and NZM3 series circuit breakers Electrical Life >1,000 operations Mechanical Life >10,000 operations Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Protection Degree IP20 (when installed in breaker) Standards Compliance IEC/EN 60947-2 Electrical Characteristics Rated Insulation Voltage: 690V AC Dielectric Strength: 2500V AC (1 minute) Insulation Resistance: >100MΩ (at 500V DC) Connection Method: Screw terminals Mechanical Specifications Mounting: Direct mounting on NZM2/NZM3 breaker Weight: Approximately 0.4 kg Connection: Fixed wiring connection

Technical Parameters Category Specification Product Model NZM2/3-XA480-525AC/DC Product Family Eaton NZM Accessories Device Type Shunt Trip Release Rated Control Voltage 480-525V AC/DC Operating Voltage Range 0.7-1.1 × Us Power Consumption AC: 25VA (inrush), 10VA (hold) DC: 25W (inrush), 10W (hold) Operating Time <50ms Mounting Compatibility NZM2 and NZM3 series circuit breakers Electrical Life >1,000 operations Mechanical Life >10,000 operations Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Protection Degree IP20 (when installed in breaker) Standards Compliance IEC/EN 60947-2, UL 489 Electrical Characteristics Rated Insulation Voltage: 690V AC Dielectric Strength: 2500V AC (1 minute) Insulation Resistance: >100MΩ (at 500V DC) Terminal Capacity: 2.5 mm² max Connection Method: Screw terminals

Technical Parameters Category Specification Product Model NZM4-XA Product Family Eaton NZM Accessories Device Type Shunt Trip Release Compatibility NZM4 series circuit breakers Mounting Position Can be mounted on left or right side of breaker Electrical Life >1,000 operations Mechanical Life >10,000 operations Operating Temperature -25°C to +70°C Storage Temperature -40°C to +85°C Protection Degree IP20 (when installed in breaker) Standards Compliance IEC/EN 60947-2
