Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34060NB-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 1.1 kW Horsepower (HP) 1.5 HP Output Current 3.0 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke (as indicated by "C" in model suffix) Control Method Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) standard Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34150NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 4.0 kW Horsepower (HP) 5 HP Output Current 7.5 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34110NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 1.5 kW Horsepower (HP) 2 HP Output Current 3.7 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34090NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 1.1 kW Horsepower (HP) 1.5 HP Output Current 2.8 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Line DF1 (DuraDrive F1) Product Model DF1-34075NN-C20CX1 Product Type AC Variable Frequency Drive (VFD) Rated Output Power 0.75 kW Horsepower (HP) 1 HP Output Current 2.1 A Input Voltage 3-Phase, 380 - 480 V AC (±10%) Input Frequency 50/60 Hz (±5%) Output Voltage 0 - Input Voltage Output Frequency 0 - 599 Hz Key Feature Integrated DC Choke Control Methods Sensorless Vector Control, V/F Control Enclosure Rating IP20 / NEMA Type 1 (Open Type) Keypad Removable with potentiometer Communication Protocols Modbus RTU (RS-485) Mounting Panel Mount Approvals / Certifications CE, cULus, RoHS

Technical Parameters Category Specification Product Series DuraDrive F1 Rated Power 0.55 kW (0.75 HP) Output Current 1.8 A Input Voltage 3-phase 380-480 V AC ±10% Input Frequency 50/60 Hz ±5% Output Frequency 0-599 Hz Control Methods V/F control, Sensorless vector control DC Choke Integrated Communication Modbus RTU (RS-485) Enclosure Rating IP20 Keypad Removable with potentiometer Mounting DIN rail mount

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series XC Series Programmable Controllers Product Model XC-CPU101-C256K Product Type PLC Central Processing Unit (CPU) Program Memory 256 KB Data Memory Integrated (typically a portion of the 256 KB is allocated) Integrated Communication Ports • 1 x Ethernet (XC-BUS) • 1 x RS-232 (for programming or other devices) • 1 x RS-485 (for Modbus master/slave, etc.) Integrated Real-Time Clock (RTC) Yes I/O Expansion Capability Yes, via XC series extension modules on the right side Max. Number of Connected I/O Modules Up to 8 (including special function modules) Programming Software Eaton XSoft-CODESYS (based on CODESYS V3) Programming Languages Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC) Supported Communication Protocols Modbus TCP (via Ethernet), Modbus RTU (via RS-232/485), XC-BUS (for I/O expansion) Power Supply 24 V DC (via the base unit or a separate power supply module) Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model C445BD-SDNM Product Type Electromechanical Contactor Number of Main Poles 4 Rated Operational Current (Iₑ) at AC-3 55 A (at 690V AC) Rated Thermal Current (Ith) 80 A Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Control Coil Voltage DC (Specific voltage is denoted by the suffix, e.g., C445BD-S24 for 24V DC. "SDNM" often indicates a standard version, and the exact voltage must be specified when ordering). Motor Rating (AC-3) at 400V ~ 55 kW Motor Rating (AC-3) at 690V ~ 75 kW Electrical Life > 1 Million operations (under specific load conditions) Mechanical Life > 10 Million operations Auxiliary Contacts Not included as standard; add-on blocks available (e.g., CA4... series) Mounting Snap-on mounting to standard DIN Rail (35mm) or screw mounting Approvals / Certifications CE, cULus, CCC, IEC/EN 60947-4-1

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model DILM32-XTEE11 Catalog Reference RAC240 Product Type Contactor Relay (4-pole, changeover contacts) Number of Contacts 4 Contact Type 4 Changeover (CO) / Form C (Each contact: 1 NO + 1 NC) Rated Operational Current (Iₑ) 10 A (at 250V AC) Rated Thermal Current (Ith) 16 A Rated Insulation Voltage (Ui) 500 V AC Control Coil Voltage 24 V DC Special Feature Latching (Impulse) Version (Mechanically held) Electrical Life > 1 x 10⁶ operations Mechanical Life > 10 x 10⁶ operations Mounting 35 mm DIN Rail Terminal Type Cage Clamp (Spring-loaded) Approvals / Certifications CE, cULus, CCC, IEC/EN 60947-5-1

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series ED6 Product Model ED6-10/1N/D/003 Product Type Type 2 / Class II Surge Protective Device (SPD) Rated Voltage 230/400 V AC Nominal System Voltage 230 V AC (Single-Phase + N) Protection Mode 1-Pole + N (L-N, N-PE) Max. Discharge Current (Imax - 8/20 µs) 10 kA per pole Nominal Discharge Current (In - 8/20 µs) 5 kA Voltage Protection Level (Up) ≤ 1.5 kV Response Time < 25 ns Backup Fuse Recommendation 16 A gG/gL (or according to local regulations) Status Indication Visual (Green: OK; Red: End-of-Life) & Remote Signalling Contact Remote Contact 1 Changeover Contact (SPDT) Mounting 35 mm DIN Rail (EN 60715) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11
