Technical Parameters Parameter Specification Product Series Eaton XNE (Moeller Series) Product Type Digital Input Module Number of Channels 8 Channel Type Digital Input (DI) Input Type Sinking (compatible with PNP sensors) Rated Input Voltage 24 V DC Operating Voltage Range Typically 19.2 - 30 V DC Input Current per Channel Typically 3-5 mA @ 24V DC "1" Signal Level ≥ 15 V DC (Logic High) "0" Signal Level ≤ 5 V DC (Logic Low) Connection Type Removable screw terminal block Isolation Between field side and system side Status Indication LED per channel (green) Mounting DIN Rail (35 mm, EN 60715) Compatibility Eaton XNE PLC Systems (e.g., with XNExx CPU or BUS Coupler) Standards Compliance IEC 61131-2, UL 508, CE, cULus

Technical Parameters Parameter Specification Product Series Eaton XNE (Moeller Series) Product Type Digital Output Module Number of Channels 8 Channel Type Digital Output (DO) Output Type Sourcing (P-Switching) Rated Load Voltage 24 V DC Rated Output Current per Channel 0.5 A Total Max. Current per Module Typically ~4 A (for all 8 channels combined, subject to derating) Power Supply Voltage 24 V DC (via system backplane) Switching Element Transistor (MOSFET) Load Type Resistive, Inductive, Lamp Load Connection Type Removable screw terminal block Isolation Between field side and system side Status Indication LED per channel (green) Mounting DIN Rail (35 mm, EN 60715) Compatibility Eaton XNE PLC Systems (e.g., with XNExx CPU or BUS Coupler) Standards Compliance IEC 61131-2, UL 508, CE, cULus

Technical Parameters Parameter Specification Product Series Eaton EASY719 Product Type Electronic Soft Starter with Integrated Bypass Contactor Rated Operational Voltage (Ue) 208 - 690 V AC, 50/60 Hz Motor Power Range At 400V: 5.5 kW / 7.5 HP (Please verify for other voltages, e.g., 4 kW @ 230V, 7.5 kW @ 480V, 11 kW @ 690V) Rated Operational Current (Ie) 12 A to 18 A (Depending on cooling condition and application) Setting Range Current 1 - 18 A (Adjustable) Starting Current (Limit) 150% - 500% of set current (Adjustable) Starting Time 1 - 30 seconds (Adjustable) Stopping Time 1 - 30 seconds (Adjustable for "Soft Stop") Control Connections 3 x Main Power (L1, L2, L3) 3 x Motor Output (T1, T2, T3) Screw terminal block for control wiring (Start, Stop, Relay outputs, etc.) Bypass Contactor Integrated Protection Features Overload, Phase Loss / Unbalance, Anti-jamming / Stall, Over-temperature Status Indication LED Indicators (Power, Run, Bypass, Fault) Mounting DIN Rail Mounting (EN 60715) Standards Compliance IEC/EN 60947-4-2, UL 508, CE

Technical Parameters Parameter Specification Product Series Eaton MFD Product Type Miniature Circuit Breaker (MCB) Number of Poles Single Pole (1P) Rated Current (In) 80 A Rated Voltage (Ue) 230/400 V AC Tripping Characteristic Type B (Instantaneous trip: 3 to 5 x In) Breaking Capacity (Icn) 10 kA (10,000 A) at 400V AC (Please verify specific catalog, as it may be 6kA or 10kA depending on the market) Standards Compliance IEC/EN 60898-1, IEC/EN 60947-2 Electrical Life ≥ 10,000 cycles Mechanical Life ≥ 20,000 cycles Terminal Connection Suitable for copper and aluminum cables (torque specifications to be checked in manual) Mounting DIN Rail Mounting (EN 60715) Width (Modular Size) 17.5 mm (1 module)

Technical Parameters Category Specification Product Model EASY821-DC-TC Product Line EASY800 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 24 V DC (Range: 19.2 - 28.8 V DC) Power Consumption Typically 12 W (including loads) Core Processor 8-bit microcontroller User Program Memory 1,000 function blocks (non-volatile) Data Memory 128 flags (non-volatile) Real-Time Clock (RTC) Integrated (buffered for approx. 80 hours at 25°C) Digital Inputs 8 x Digital Inputs • 24 V DC (sinking/sourcing) • 2 inputs are multi-functional and can be used as analog inputs (0-10 V) or high-speed counters (5 kHz) Digital Outputs 6 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs 2 x Analog Inputs (shared with 2 multi-functional digital inputs) • Voltage Range: 0 - 10 V DC • Resolution: 8 bit High-Speed Counters 2 x High-Speed Counters (shared with 2 multi-functional digital inputs) • Frequency: up to 5 kHz Display & Operation Integrated Text Display (TC) • 2-line, 16-character backlit LCD • 4 navigation keys for programming and operation Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY800 devices (via RJ12) • PC Connection: For programming with EASY-SOFT software Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 126 x 90 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY412-DC-R Product Line EASY400 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 24 V DC Power Consumption Typically 8 W (including loads) Core Processor 8-bit microcontroller User Program Memory 500 function blocks (non-volatile) Data Memory 64 flags (non-volatile) Real-Time Clock (RTC) Not available on this model Digital Inputs 6 x Digital Inputs • 24 V DC (sinking/sourcing) Digital Outputs 4 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) • Note: The total current for all outputs combined must not exceed 16 A. Analog Inputs Not available on this model. High-Speed Counters Not available on this model. Display & Operation No built-in display. Status indicated by LEDs. Programming and monitoring require a PC. Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/600/800 devices (via RJ12 connectors) • PC Connection: For programming with EASY-SOFT software Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 90 x 71.5 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY819-DC-RC Product Line EASY800 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 24 V DC (19.2 - 28.8 V DC) Power Consumption Typically 15 W (including loads) Core Processor 32-bit microcontroller User Program Memory 2,000 function blocks (non-volatile) Data Memory 512 flags (non-volatile) Real-Time Clock (RTC) Integrated (buffered for approx. 80 hours at 25°C) Digital Inputs 8 x Digital Inputs • 24 V DC (sinking/sourcing) • 4 of them can be used as analog inputs (0-10 V, 0/4-20 mA) or high-speed counters (5 kHz) Digital Outputs 6 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs 4 x Analog Inputs (shared with 4 digital inputs) • Configurable: 0 - 10 V, 0/4 - 20 mA • Resolution: 10 bit High-Speed Counters 4 x High-Speed Counters (shared with 4 digital inputs) • Frequency: up to 5 kHz Display & Operation Integrated Color Graphic Display (RC) • High-resolution TFT color screen • 8 function keys with customizable labels Programming Interface Integrated EASY-PC interface (via RJ12 connector) & USB port Communication • EASY-LINK: For networking up to 12 EASY800 devices • Ethernet (optional module): For integration into plant networks and remote access. • PC Connection: Via USB or RJ12. Programming Software Eaton EASY-SOFT (Version 7 or higher recommended for full color display support) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 126 x 90 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY410-DC-RE Product Line EASY400 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 24 V DC Power Consumption Typically 6 W (including loads) Core Processor 8-bit microcontroller User Program Memory 500 function blocks (non-volatile) Data Memory 64 flags (non-volatile) Real-Time Clock (RTC) Not available Digital Inputs 4 x Digital Inputs • 24 V DC (sinking/sourcing) Digital Outputs 2 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs Not available High-Speed Counters Not available Display & Operation No built-in display. Status is indicated by LEDs only. Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/600/800 devices (via RJ12 connectors). • PC Connection: For programming with EASY-SOFT software. Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 90 x 71.5 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY619-AC-RC Product Line EASY600 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 100-240 V AC (85-264 V AC, 50/60 Hz) Power Consumption Typically 12 W (including loads) Core Processor 32-bit microcontroller User Program Memory 1,000 function blocks (non-volatile) Data Memory 256 flags (non-volatile) Real-Time Clock (RTC) Integrated Digital Inputs 8 x Digital Inputs • 24 V DC (sinking/sourcing) • 2 of them can be used as analog inputs (0-10 V) or high-speed counters (5 kHz) Digital Outputs 6 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs 2 x Analog Inputs (shared with 2 digital inputs) • 0 - 10 V DC • Resolution: 10 bit High-Speed Counters 2 x High-Speed Counters (shared with 2 digital inputs) • Frequency: up to 5 kHz Display & Operation Integrated Color Graphic Display (RC) • TFT color screen • 8 function keys with customizable labels Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/600/800 devices (via RJ12 connectors). • PC Connection: For programming with EASY-SOFT software. Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 126 x 90 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY512-AC-RC Product Line EASY500 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 100-240 V AC (85-264 V AC, 50/60 Hz) Power Consumption Typically 10 W (including loads) Core Processor 8-bit microcontroller User Program Memory 500 function blocks (non-volatile) Data Memory 64 flags (non-volatile) Real-Time Clock (RTC) Not available on this model Digital Inputs 6 x Digital Inputs • 24 V DC (sinking/sourcing) Digital Outputs 4 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs Not available on this model. High-Speed Counters Not available on this model. Display & Operation Integrated Color Display (RC) • Basic color screen for text and status indication. • Navigation keys for operation. Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/500/600/800 devices (via RJ12 connectors). • PC Connection: For programming with EASY-SOFT software. Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 90 x 71.5 x 64 mm
