Parameter Specification Product Series Eaton HM (General Purpose Relay) Model Number HM4R12 Description Plug-in General Purpose Relay, 4PDT, 12A, 24V DC Coil Contact Configuration 4PDT (4 Form C / 4 Changeover) Rated Load Current 12 A @ 250V AC Coil Voltage 24V DC Electrical Life Typically 1 x 10^6 operations (at rated load) Mechanical Life Typically 10 x 10^6 operations Mounting Plug-in base (e.g., PA16-11B or similar) Terminals Plug-in (screw terminals on the base) Standards & Certifications IEC 61810-1, UL 508, CSA C22.2 No. 14

Parameter Specification Product Type Digital Panel Voltmeter Model Number DMV-630N/3 Description Digital Voltmeter, 3-Phase, 0-630V AC Measured System 3-Phase (with Neutral) Rated Voltage (Un) 400V / 480V AC Measuring Range 0 - 630V AC Power Supply Auxiliary supply (e.g., 80-270V AC/DC or 24V AC/DC) Display Digital Display (LED or LCD) Accuracy Typically ±0.5% to ±1% of reading Mounting Panel Mount (requires panel cutout) Connection Screw Terminals Standards & Certifications IEC 61010-1, UL 61010-1, CE

Parameter Specification Product Type Digital Panel Voltmeter Model Number DMV-1000N/3 Description Digital Voltmeter, 3-Phase, 0-1000V AC Measured System 3-Phase (with or without Neutral) Rated Voltage (Un) 690V AC Measuring Range 0 - 1000V AC Power Supply Typically 80-270V AC/DC or 24V AC/DC (Auxiliary supply) Display LED or LCD Digital Display Accuracy Typically ±0.5% of reading Mounting Panel Mount (Cut-out required) Connection Screw Terminals Standards & Certifications IEC 61010-1, UL 61010-1, CE

Parameter Specification Product Series Eaton ZM (Timer & Monitoring Relays) Model Number ZM-32-8-PKZ24 Description Multi-Function Timer Relay, 8-Pin, 24V AC/DC Supply Voltage (Us) 24V AC/DC Number of Outputs 1 Changeover (SPDT) Output Contact Rating Typically 8A @ 250V AC Timing Functions Multiple (e.g., On-delay, Off-delay, Interval, One-shot, Flasher) Time Range Adjustable, typically from 0.05s up to 300h (depends on selected function) Setting Method Via DIP-switches and a potentiometer or rotary switch Mounting DIN Rail (35mm) on an 8-pin socket Terminals Screw Clamp Status Indication LED for power and output status Standards & Certifications IEC/EN 61812-1, UL 508, CSA

Parameter Specification Product Series Eaton L630E Model Number 69D4630G03 (Full Assembly) / L630E (Relay Core) Description Thermal Overload Relay, 22-32A Motor Current Setting Range (FLA) 22 - 32 A Poles 3 (for 3-phase motor protection) Tripping Class 10 (Standard) Ambient Compensated Yes Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton N4 (UPS Series) Model Number N4-4-800 Description Line-Interactive UPS, 800VA/480W, 230V, 4 Outlets Topology Line-Interactive with AVR Rated Capacity 800 VA / 480 W Input Voltage 230 V AC, 50/60 Hz Output Voltage 230 V AC, 50/60 Hz (Sinusoidal) Typical Backup Time Varies by load (e.g., ~5-15 minutes at half load) Battery Sealed, maintenance-free lead-acid battery (user-replaceable) Form Factor Tower / Desktop Outlets 4 x NEMA / Local Standard battery-backed + surge-protected outlets Communication USB (for management and graceful shutdown of connected computers) Display LED status indicators Warranty Typically 2 years

Parameter Specification Product Series Eaton LD / LB (Limit Switch) Model Number LD 35K 6633C81G03 Description Heavy-Duty Limit Switch, Lever Arm Actuator Actuator Type Lever Arm with Roller Contact Configuration Specific to the "6633C81G03" code (e.g., 1NO + 1NC) Rated Operational Current Typically 10A @ 600V AC Rated Insulation Voltage 500V - 600V Electrical Life Millions of cycles (at rated load) Mechanical Life Tens of millions of cycles Housing Material Metal (e.g., Zinc Die Cast) Protection Degree IP65 (Dust-tight and protected against water jets) Terminals Screw Terminals Standards & Certifications IEC 60947-5-1, UL 508, CSA

Parameter Specification Product Series Eaton HMDL (Accessory) Model Number HMDL-DCW Description DC Power Supply Module for HMDL Contactors, White Input Voltage Typically 120V AC or 277V AC Output Voltage 24V DC Output Power / Current Sufficient to power multiple HMDL contactor coils (e.g., 50 VA)。 Enclosure Color White Mounting DIN Rail (35mm) Compatibility Designed for use with Eaton HMDL Series Lighting Contactors Primary Use Provides low-voltage DC control power for lighting automation systems.

Parameter Specification Product Series Eaton HMDL (Accessory) Model Number HMDL-DC Description DC Power Supply Module for HMDL Contactors Input Voltage Typically 120V AC or 277V AC Output Voltage 24V DC Output Power / Current Sufficient to power multiple HMDL contactor coils (e.g., 50 VA). 。 Mounting DIN Rail (35mm) Compatibility Designed for use with Eaton HMDL Series Lighting Contactors Primary Use Provides low-voltage DC control power for lighting automation systems.

Parameter Specification Product Series Eaton N4 (UPS Series) Model Number N4-1000 Description Line-Interactive UPS, 1000VA/900W, 120V Topology Line-Interactive with AVR Rated Capacity 1000 VA / 900 W Input 120 V AC, 50/60 Hz Output 120 V AC, 50/60 Hz (Sinusoidal) Typical Backup Time Varies by load (e.g., ~10-20 minutes at half load) Battery Sealed, maintenance-free lead-acid battery (user-replaceable) Form Factor Tower / Desktop Outlets Multiple NEMA 5-15R battery-backed + surge-only outlets Communication USB, Serial (for management and graceful shutdown of connected computers) Display LCD or LED status display Warranty Typically 2 or 3 years
