Parameter Specification Product Model 15100AQD07 Product Series Eaton Heavy-Duty Limit Switch Actuator Type Rotating Lever Arm (inferred from QD07) Contact Configuration 1 NO (Normally Open) (inferred from QD07) Rated Operational Current 10 A at 600 V AC Electrical Life >1 million operations (at rated load) Mechanical Life >10 million operations Enclosure Rating NEMA 4, 4X, 6P, 13; IP67 Housing Material Zinc die cast Terminal Type Screw terminals Operating Temperature -20°C to 120°C Standards Compliance UL, cULus, CE

Parameter Specification Product Model LS-02-ZB Product Type Inductive Proximity Sensor Sensing Distance 2 mm (nominal) Detection Object Ferrous metals (e.g., steel) Output Type DC 3-wire (typically PNP or NPN) Supply Voltage 10–30 V DC Current Rating ≤200 mA Switching Frequency 500 Hz Housing Material Nickel-plated brass Connection Type Pre-wired cable (2 m standard) Protection Rating IP67 Operating Temperature -25°C to 70°C

Parameter Specification Product Model PKM0-10 Product Line Eaton PKM0 Series UPS Topology Online double-conversion (VFI) Rated Power Capacity 10 kVA / 9 kW (at 230 V AC) Input Voltage Range 160–276 V AC (auto-sensing) Input Frequency Range 50/60 Hz (auto-sensing) Output Voltage 230 V AC (±1% steady state) Output Frequency 50/60 Hz (±0.5% in battery mode) Battery Runtime Configurable (typical 5–30 minutes with external battery packs) Efficiency >94% at full load Communication Interfaces Ethernet, RS-232, USB, dry contacts Form Factor Tower or rack-mountable (2U with kit) Operating Temperature 0–40°C Standards Compliance IEC 62040-3, CE, UL, RoHS

Parameter Specification Product Model M22-I2 Product Line Eaton M22 Series Product Type Indicator Light (Visual Signaling) Lens Color Red (inferred from I2) Mounting Hole Diameter 22 mm Voltage Options e.g., 24 V DC, 120 V AC (requires separate lamp holder/LED module) Protection Rating IP67 (dust-tight and waterproof) Lens Material Polycarbonate (typical) Housing Material Thermoplastic (e.g., PA66) Terminal Type Screw terminals or spring-cage Operating Temperature -25°C to +55°C

Parameter Specification Product Model M22-I4 Product Line Eaton M22 Series Product Type Indicator Light (Visual Signaling) Lens Color Green (inferred from I4) Mounting Hole Diameter 22 mm Voltage Options e.g., 24 V DC, 120 V AC (requires separate lamp holder/LED module) Protection Rating IP67 (dust-tight and waterproof) Lens Material Polycarbonate (typical) Housing Material Thermoplastic (e.g., PA66) Terminal Type Screw terminals or spring-cage Operating Temperature -25°C to +55°C

Parameter Specification Product Model DG4V-3-S-9 Product Line Eaton DG4V Series Directional Valves Valve Type 3-way, 2-position (3/2) Actuation Solenoid-operated (12 V DC coil) Rated Flow Up to 19 L/min (5 GPM) Maximum Operating Pressure 315 bar (4,500 psi) Port Size 10-32 UNF (standard) Response Time <30 ms (typical) Fluid Compatibility Mineral-based hydraulic oils (ISO VG 15–68) Operating Temperature -40°C to +100°C Electrical Connection DIN 43650 Form A (standard)

Parameter Specification Product Model RV1-8-S-0-36 Product Line Eaton RV Series Pressure Relief Valves Valve Type Pilot-operated, direct-acting Pressure Adjustment Range Example: 50–350 bar (exact range depends on variant) Rated Flow Capacity Up to 75 L/min (typical for RV1 series) Maximum Setting Pressure 350 bar (5,000 psi) Port Size SAE 1/2" (or as specified) Fluid Compatibility Mineral-based hydraulic oils (ISO VG 15–68) Operating Temperature -40°C to +100°C Leakage Meets ISO 10770-1 standards

Parameter Specification Product Model LS-XRL Product Line Eaton Limit Switches Contact Configuration 1 NO + 1 NC (typical) Rated Operational Current 10 A at 600 V AC Electrical Life >1 million operations (at rated load) Mechanical Life >10 million operations Enclosure Rating NEMA 4, 4X, 6P, 13; IP67 Housing Material Zinc die cast Actuator Type Extended rotary lever (inferred from "XRL") Terminal Type Screw terminals Operating Temperature -20°C to 120°C Standards Compliance UL, cULus, CE

Parameter Specification Product Model PHV2BVN Product Line Eaton PHV Series Directional Control Valves Valve Type 2-position, 2-way (2/2) Actuation Manual lever Rated Flow Up to 19 L/min (5 GPM) Maximum Operating Pressure 250 bar (3,625 psi) Port Size 1/4" NPTF (standard) Neutral Position Closed center (typical) Fluid Compatibility Mineral-based hydraulic oils (ISO VG 32-68) Operating Temperature -40°C to +100°C Leakage Minimal internal leakage (meets ISO standards)

Parameter Specification Product Model SHLR-0008 Product Line Eaton NZM Series Accessories Compatible Breakers NZM1, NZM2, NZM3 MCCBs Rated Control Voltage 24–240 V AC/DC (specific range depends on variant) Power Consumption ≤15 VA/W (typical) Mounting Integrated directly onto NZM breaker Operating Temperature -25°C to +70°C Electrical Life ≥10,000 operations Standards Compliance IEC 60947-2, UL 489
