Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Cracking Pressure 0.35 bar 5 psi (Free Flow) Pilot Ratio 3.5:1 Typical Maximum Flow 75 L/min 19.8 US gpm Port Size Cavity ISO 7789 Standard Cartridge Thread Size 11/16-16 UN Standard Installation Torque 95-110 Nm 70-81 lb-ft

Technical Parameters Parameter Value Notes Rated Current 20A Iₙ Rated Voltage 400V AC 50/60Hz Breaking Capacity 36kA Icu at 400V AC Rated Insulation Voltage 690V AC Ui Rated Impulse Voltage 8kV Uimp Number of Poles 3 Standard Tripping Characteristic Electronic S4 Curve Electrical Characteristics Parameter Specification Rated Frequency 50/60 Hz Utilization Category A Electrical Life 5,000 cycles Mechanical Life 20,000 cycles Termination Cable Lug or Bus Bar

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered, tandem center Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At rated pressure Response Time < 30 ms Solenoid actuation Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Coil Resistance 22 Ω ±10% Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Recommended Viscosity 10-100 mm²/s

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 15 L/min 4 US gpm (typical) Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 80 mL/min At rated pressure Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Response Time < 35 ms Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 6 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Fluid Viscosity Range 10-100 mm²/s

Technical Parameters Parameter Value Notes Maximum Operating Pressure 250 bar 3,625 psi Rated Flow Capacity 38 L/min 10 US gpm per section Port Size 3/4" NPTF Standard mobile connections Spool Configuration 3-position, 4-way Spring-centered Actuation Type Mechanical lever Manual control Pressure Rating - Work Ports 250 bar 3,625 psi - Inlet Port 210 bar 3,045 psi Internal Leakage < 30 mL/min At rated pressure Functional Characteristics Dual Spool Design: Independent control of two hydraulic functions Spring-Centered: Automatic return to neutral Parallel Circuit: Allows simultaneous operation Load Holding: Check valve functionality in neutral Manual Lever Control: Mechanical actuation Detent Mechanism: Position holding capability Spool Configuration Details Spool Code Function A Side A2W 3-position, spring-centered with detent B Side B2W 3-position, spring-centered with detent Mechanical Specifications Parameter Specification Actuation Force 30-50 N per lever Lever Travel 35-45° total Detent Force 15-25 N Spool Type Sliding spool Mounting Stackable design Weight Approx. 5.5 kg (12.1 lb)

Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At rated pressure Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Response Time < 30 ms Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C

Technical Parameters Parameter Value Notes Displacement 141 cm³/rev 8.61 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Control Response Time < 40 ms 10-90% stroke Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (clockwise) Weight Approx. 48 kg (106 lb) Length ~325 mm (12.8 in) Width ~235 mm (9.3 in) Performance Data Parameter Value Theoretical Flow at 1800 rpm 253.8 L/min (67.0 US gpm) Actual Flow at 1800 rpm ≈ 246 L/min (65.0 US gpm) Input Power at 250 bar 106 kW (142 hp) Input Power at 280 bar 118 kW (158 hp) Noise Level < 80 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Electronic Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 1.8A maximum Hysteresis < 1.5% Linearity < 2% Repeatability < 0.5% Protection Rating IP65

Technical Parameters Parameter Value Notes Displacement 180 cm³/rev 10.98 in³/rev Maximum Operating Pressure 420 bar 6,090 psi (continuous) Rated Pressure 350 bar 5,075 psi Peak Pressure 450 bar 6,525 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2200 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Mechanical Efficiency ≥ 95% At rated conditions DF Control System Characteristics Electro-Hydraulic Proportional Control: Precise electronic displacement control Pressure Compensation: Automatic pressure regulation Flow Control: Proportional flow matching to system demand Load Sensing Compatibility: System pressure demand sensing Power Control: Horsepower limitation capability Multiple Control Modes: Programmable operating modes Physical Specifications Parameter Specification Electrical Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 2.0A maximum Response Time < 35 ms Hysteresis < 1.5% Linearity < 2% Protection Rating IP66 Shaft Type SAE Standard (19 mm) Mounting SAE 2-bolt type "D" Port Size SAE 1-1/2" (No. 16) Rotation Right-hand (clockwise) Weight Approx. 65 kg (143 lb) Length ~350 mm (13.8 in) Width ~280 mm (11.0 in)

Technical Parameters Parameter Value Notes Displacement 90 cm³/rev 5.49 in³/rev Maximum Operating Pressure 420 bar 6,090 psi (continuous) Rated Pressure 350 bar 5,075 psi Peak Pressure 450 bar 6,525 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 600 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions DF Control Characteristics Electro-Hydraulic Proportional: Precise electronic control of pump displacement Pressure Compensation: Automatic pressure control capability Flow Control: Proportional flow regulation Load Sensing: Optional system optimization Multiple Control Modes: Pressure, flow, power control Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Electrical Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 1.5A maximum Response Time < 30 ms Hysteresis < 1.5% Protection Rating IP65 Rotation Right-hand (clockwise) Weight Approx. 38 kg (83.8 lb) Length ~285 mm (11.2 in) Width ~220 mm (8.7 in)

Technical Parameters Parameter Value Notes Displacement 74 cm³/rev 4.52 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 700 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Mechanical Efficiency ≥ 94% At rated conditions
