Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer

Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer Typical Applications Residential Gas Meter Sets Commercial Building Gas Service Industrial Appliance Gas Supply LP Gas Vapor Service Gas-Powered Equipment Regulation Secondary Pressure Reduction in Distribution Systems

Technical Specifications Category Specification Type Pneumatic Displacer Level Controller Input Liquid level (buoyancy force) Output 3-15 psig (0.2-1.0 bar) Air Supply 20-35 psig (1.4-2.4 bar) clean, dry air Accuracy ±1% of span Span Ranges Various displacer lengths available Temperature Range Standard: -40°F to 450°F (-40°C to 232°C) High-temp: Up to 850°F (454°C) with special options Process Connections 2" NPT standard; 3" NPT and flanged options available Chamber Materials Carbon Steel, Stainless Steel Displacer Materials Stainless Steel, Hastelloy, other alloys Torque Tube Materials Various alloys for different service conditions

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Pressure Rating ANSI Class 150, 300 Size Range 2" through 8" (50 mm through 200 mm) Connections Flanged (RF or RTJ) Maximum Inlet Pressure Up to 400 psig (28 bar) depending on configuration Outlet Pressure Range Highly configurable via pilot selection Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Ductile Iron (Standard), Carbon Steel Trim Materials Stainless Steel

Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Body Size 1-1/2" to 3" NPT Maximum Inlet Pressure 400 psig (28 bar) Outlet Pressure Range Adjustable via spring change (typical ranges: 5-50 psig, 20-100 psig) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Ductile Iron (standard), Cast Steel Trim Materials Stainless Steel Actuator Type Spring-Diaphragm Pilot Connection 1/4" NPT

Key Parameters Category Parameter Description / Typical Values Valve Body & Size Valve Body Style Single-port, top-guided, balanced or unbalanced trim. Cage-style design. Size Range Typically from 1/2 inch (DN15) to 8 inches (DN200) and larger. End Connections Flanged (ANSI Class 150, 300, 600, 900; PN ratings), Screwed (NPT), Butt-weld. Face-to-Face Dimensions Complies with ISA S75.08, IEC 60534-3-1, and other international standards. Pressure & Temperature Pressure Rating Dependent on body material and class. Common ratings: ANSI Class 150, 300, 600, 900. Max. Operating Pressure Varies with size and class. e.g., Up to several thousand psi (e.g., 1480 psi / 102 bar for a 2" Class 600 valve). Temperature Range Standard: -20°F to +450°F (-29°C to +232°C). Extended ranges available with special seals and materials (e.g., -320°F to +1000°F / -196°C to +538°C). Flow Characteristics Flow Characteristics Equal Percentage, Linear, Quick Opening. Defined by the characterized cage. Flow Coefficient (Cv) A wide range of Cv values available, selected by choosing the appropriate trim size and type. Rangeability Typically high, e.g., 50:1 for equal percentage trim. Leakage Class Leakage Class ANSI/FCI 70-2: • Class II (Standard Double-seated) • Class IV (Standard Single-seated) • Class V (Soft Seat) • Class VI (Soft Seat, Bubble-tight) Materials Body & Bonnet Materials Carbon Steel (Standard), Stainless Steel (304SS, 316SS), Alloy 20, Duplex Stainless Steel, and other alloys. Trim Materials Standard: 17-4PH Stainless Steel. Options: 316SS, Stellite, Hastelloy, etc., for erosion, corrosion, or cavitation service. Seat Rings Stainless Steel, Stellite, or soft-seated (e.g., PTFE, RPTFE). Actuator & Accessories Actuator Type Fisher 657 or 667 Diaphragm Actuator is commonly paired. Spring ranges and diaphragm sizes are selectable to achieve required thrust. Action Air-to-Close (ATC) or Air-to-Open (ATO). Accessories Positioners (e.g., Fisher DVC6200, DVC2000), Transducers, Limit Switches, Solenoid Valves, Air Sets, etc.

Key Parameters Category Parameter Description / Typical Values Enclosure Enclosure Material Cast Aluminum with Epoxy Powder Coat. Ingress Protection IP66/IP67 (NEMA 4, 4X, 6 equivalent) - Dust-tight and protected against powerful water jets and temporary immersion. Hazardous Area Certifications ATEX, IECEx (Ex d IIC T6 Gb / Ex tb IIIC T80°C Db), CSA (Class I, Div 1 & 2, Groups A, B, C, D). Electrical Electrical Connections Modular terminal block for easy wiring. Conduit Entries Multiple ½" NPT conduit entries. Switch Types Standard: 2 to 4 snap-action switches (SPDT). Optional: Magnetic proximity switches (Reed switches), Hall Effect sensors. Electrical Ratings Typical Switch: 10 A, 250/480 VAC. (Specific ratings depend on the switch type selected). Mechanical Shaft Rotation Standard 90° adjustment (configurable for other angles). Operating Temperature Standard: -40°F to +165°F (-40°C to +74°C). Optional high-temperature version available. Mounting Directly mounts to the actuator using a standardized interface (e.g., Fisher V-Ball, V500/V600 actuator mounts). Indication Position Indicator Mechanical Flag Indicator: Color-coded (Red/Green) for local visual position indication. Optional Features • Potentiometer for analog position feedback. • Heater Kit for cold environments to prevent condensation. • Solenoid valves for integrated control.

Key Parameters Category Parameter Description / Typical Values Pressure Ratings Inlet Pressure (P1) Up to 4000 psig (275 bar). Outlet Pressure (P2) Range Varies with size and spring/dome load. Typically from 15 to 1500 psig (1 to 103 bar). Consult sizing tables. Max. Shutoff Pressure Up to the maximum inlet pressure rating. Size & Connections Orifice Size Common sizes: 1/2 inch, 3/4 inch, 1 inch, 1-1/2 inch, 2 inch. End Connections NPT (Standard), Flanged (ANSI Class 150, 300, 600, 900, etc.), or SW (Socket Weld). Flow & Performance Flow Coefficient (Cv) High Cv values, e.g., up to 45 Cv for a 2" orifice. Accuracy & Droop Excellent accuracy with minimal droop due to the pilot-operated design. Materials Body Materials Carbon Steel (Standard), Stainless Steel (316). Trim Materials Stainless Steel, etc. Pilot Options Control Type Spring-Loaded Pilot: Setpoint is adjusted by a spring. Dome-Loaded Pilot: Setpoint is controlled by applying an external air or gas signal to the dome, allowing for remote control. Environment Operating Temperature Standard: -20°F to +150°F (-29°C to +66°C). Extended temperature ranges available with optional elastomers.

Key Parameters Category Parameter Description / Typical Values Input Signal Electrical Input 4-20 mA DC (standard); other ranges available (e.g., 10-50 mA, 1-5 VDC). Output Signal Pneumatic Output 3-15 psig (0.2-1.0 bar); other standard ranges available (e.g., 6-30 psig). Air Supply Supply Pressure 20 psig (1.4 bar) minimum to 100 psig (6.9 bar) maximum. Performance Accuracy Typically within ±0.5% of span. Sensitivity Typically within 0.1% of span. Air Consumption Low steady-state air consumption (e.g., < 0.2 SCFM @ no load). Environmental Enclosure Rating NEMA 4X (IP66) - Weatherproof, watertight, and corrosion-resistant. Operating Temperature -40°F to +180°F (-40°C to +82°C). Hazardous Area Certifications Available with certifications for Non-Incendive (NI) and Explosion-Proof (XP) applications (e.g., Class I, Div 1 & 2, Groups A, B, C, D). Physical Enclosure Material Epoxy-coated aluminum. Mounting Directly to actuator yoke (2-bolt pattern) or panel mount. Options & Features Gauge C483-24: Without output gauge. C484-24: With output pressure gauge. Relay Options Standard High-Capacity Relay. Venting Open Vent (standard) or Closed Vent (for specific applications).
