Key Specifications & Parameters Parameter Specification / Description Solution Type Engineered isolation package based on Fisher control valve platforms (easy-e™, GX, etc.) Primary Function Ultra-tight shut-off (Isolation) for critical on/off applications Leakage Class ANSI Class VI (bubble-tight) with standard PTFE soft seats Valve Sizes ½ inch to 8 inches (DN 15 to DN 200) Pressure Ratings ANSI Class 150 to 2500, dependent on base valve selection Temperature Range Standard: -20° to 400°F (-29° to 204°C) with PTFE High-temp: Up to 800°F (427°C) with specialized trim Actuator Type Spring-return piston actuator (single/double acting) with high thrust output Digital Controller FIELDVUE DVC Series (DVC6200, DVC6000) with: • HART®/Foundation Fieldbus communication • Partial Stroke Testing (PST) • Continuous performance monitoring • Automated diagnostics Diagnostic Capabilities • Valve signature analysis • Friction monitoring • Spring rate analysis • Seat load verification • Travel accumulation

Key Specifications & Parameters Parameter Specification / Description Model / Type A configured solution based on standard Fisher control valves (e.g., easy-e™, GX, | Primary Function | Ultra-Tight Shut-Off (Isolation) for on/off or start/stop service. Note: It is not designed for throttling or continuous control. | | Sizes | Typically 1/2 inch to 6 inches (DN 15 to DN 150), depending on the base valve selected. | | End Connections | Flanged (ANSI 150, 300), NPT, etc., as per the base valve. | | Pressure Ratings | Dependent on the base valve body rating (e.g., ANSI Class 150, 300, 600). | | Temperature Range | Dependent on the base valve and seat material. Standard PTFE seats are typically suitable for -20° to 400°F (-29° to 204°C). | | Body Materials | Carbon Steel (WCB), Stainless Steel (304, 316), etc., as per the base valve. | | Trim & Seating | Soft Seat: PTFE (Teflon) is standard for achieving ANSI Class VI (bubble-tight) shut-off. Metal Seats: Available for higher temperature services where PTFE is not suitable, though with a higher leakage rate (ANSI Class IV). | | Leakage Class | ANSI Class VI (Standard with PTFE soft seat) | | Actuator | Spring-Return (Fail-Safe) Piston Actuator is standard. This provides the high thrust required for tight shut-off and ensures the valve moves to a safe position (open or closed) upon loss of air supply. | | Digital Controller | FIELDVUE™ DVC Series (e.g., DVC6000, DVC6200) is typically mounted. This provides: - Valve Positioning (for open/close commands). - Diagnostics (monitors valve health and performance). - Partial Stroke Testing (PST): Allows the user to test the valve's response and health without a full process shutdown. | | Accessories | Solenoid valves, limit switches, supply pressure regulators, and other components to complete the automated on/off package. |

Key Specifications & Parameters Parameter Specification Model Series easy-e™ (Comprises a valve body and a 1055/1065 size diaphragm actuator) Valve Type Balanced, Cage-Guided Globe Valve Actuator Type Spring-and-Diaphragm, Field-Reversible (for Air-to-Open or Air-to-Close action) Sizes 1/2 inch to 3 inches (DN 15 to DN 80) End Connections Flanged: ANSI Class 150 & 300 RF (Standard) Screwed (NPT): Available Pressure Ratings ANSI Class: 150 & 300 Max. Shut-off Pressure (ΔP): Dependent on actuator size and spring range. Consult performance tables. Temperature Range Standard: -20° to 400°F (-29° to 204°C) Extended: -50° to 450°F (-46° to 232°C) with specialized packing. Body Materials Standard: Carbon Steel (A216 WCB) Common Options: Stainless Steel (CF8 / 304, CF8M / 316) Trim Materials Standard Trim (Cage, Plug, Stem): 316 Stainless Steel Seat Ring: 316 Stainless Steel Soft Seat: PTFE (Teflon) for bubble-tight shut-off (ANSI Class VI). Flow Characteristics Equal Percentage (Standard, via characterized cage) Linear (Optional) Note: Characteristic is changed by re-orienting the cage, not by replacing it. Flow Capacity (Cv) Ranges from approximately 1.8 (for 1/2") to over 120 (for 3"), depending on the trim level. Rangeability 50:1 Leakage Class ANSI Class VI (Bubble-tight) with standard PTFE soft seat. Actuator Size: 1055 (for smaller valves) and 1065 (for larger valves) Spring Ranges: Standard ranges (e.g., 3-15 psig, 6-30 psig, 9-45 psig). Accessories Positioners: DVC6000 (Digital), 3582i (Pneumatic) Limit Switches, Solenoid Valves, Air Sets, Fail-Safe Kits (for loss of air supply).

Key Specifications & Parameters Parameter Specification Notes Model Series YD (Diaphragm Pilot), YS (Piston Pilot) Type Pilot-Operated, Pressure Reducing Regulator Primary Function Pressure Reducing Sizes 1/2 inch to 8 inches (DN 15 to DN 200) Larger sizes available for specific requirements. End Connections Flanged: ANSI Class 125, 150, 250, 300 (depending on body material) NPT: Available in smaller sizes. Pressure Ratings Body Ratings: ANSI Class 125, 150, 250, 300 Max. Inlet Pressure (P1): Up to 400 psig (27.6 bar) for certain sizes/materials. Outlet Pressure (P2) Ranges: Various pilot springs available, typically covering ranges from 5 to 300 psig (0.3 to 20.7 bar). The wide range is achieved by changing the pilot spring. Temperature Range YD (Diaphragm Pilot): Up to 406°F (208°C) YS (Piston Pilot): Up to 800°F (427°C) The YS is the clear choice for high-temperature superheated steam. Body Materials Standard: Ductile Iron (for steam service) Common Options: Cast Iron, Carbon Steel (WCB), Bronze. Material selection is critical for the application fluid. Trim Materials Stainless Steel, Stainless Steel with Stellite hard-facing (for erosive service). Flow Capacity (Cv) Very High. Significantly higher than same-size direct-operated regulators. Specific Cv depends on size and trim. (e.g., a 2" YD/YS can have a Cv over 100). This is a key advantage of the pilot-operated design. Pilot Options Various internal and external pilots available for specific control needs, including absolute pressure pilots (for vacuum breaker or back-pressure service) and temperature pilots. This versatility allows the YD/YS to be used for more than just pressure reduction. Accessories Internal Check Valve: Prevents reverse flow. Separate Strainer: Recommended to protect the pilot from debris.

Key Specifications & Parameters Parameter Specification Model Series DVC2000 (e.g., DVC2000, DVC2000f - fieldbus) Type Digital Valve Controller / Positioner Input Signal Standard: 4-20 mA DC, with HART® 5/6/7 protocol Digital Option: Foundation Fieldbus H1 (31.25 kbit/s) Output Signal Pneumatic Output: to control the valve actuator Supply Air Pressure Minimum: 0.14 bar (2 psig) above actuator pressure requirement Maximum: 7.0 bar (100 psig) for standard models; 10.3 bar (150 psig) for high-pressure (HP) models Air Consumption Steady State: Less than 0.028 Nm³/h (0.02 SCFM) Stroking: Additional consumption based on actuator size and travel speed Flow Capacity (Cv) Gauge Pressure (GP) versions: 0.086 High Flow (HF) versions: 0.32 Note: This is the Cv of the positioner's pneumatic relay. Stem Travel Range Linear Actuators: 3 to 150 mm (0.12 to 6.0 in) Rotary Actuators: 25° to 100° of rotation Accuracy Linearity: ±0.5% of span Hysteresis: 0.3% of span Sensitivity 0.1% of span Ambient Temperature Range Standard Electronics: -40° to 85°C (-40° to 185°F) Extended Temperature: -40° to 95°C (-40° to 203°F) option available Enclosure Rating NEMA 4X (IP66) - Weatherproof, dust-tight, and hose-proof Materials Enclosure: Aluminum with polyester coating Cover: Polycarbonate Communications HART: Via 4-20 mA loop Foundation Fieldbus: Via H1 terminal block Local: Infrared communication using Fisher FIELDVUE DVC2000 Setup Software or AMS Device Manager Diagnostic Capabilities Monitors and reports: - Valve Travel - Travel Accumulation - Actuator Pressure - Supply Pressure - Alarm Conditions (e.g., high friction, low supply, signal failure)

Key Specifications & Parameters Parameter Specification Model SS-263 (with various trim options and actuator types) Valve Type Top-Entry, Segmented V-Notch Ball, Rotating Shaft Flow Characteristic Approximated Equal Percentage (inherent, due to the V-notch profile) Sizes 1 inch to 16 inches (DN 25 to DN 400) End Connections Flanged: ANSI Class 150, 300, 600, 900, 1500 (RF, RTJ) Butt Weld: Available Pressure Ratings ANSI Class: 150, 300, 600, 900, 1500 Max. Pressure: Dependent on size and class. Can handle very high pressures, e.g., up to 3700 psig (255 bar) for ANSI 1500 class. Temperature Range Standard: -50° to 800°F (-46° to 427°C) Extended: Options available for cryogenic services down to -320°F (-196°C) and high-temperature services up to 1200°F (649°C) with special components. Body Materials Standard: 316 Stainless Steel (CF8M) Common Options: Carbon Steel (WCB/WCC), Alloy 20 (CN7M), Hastelloy C, Duplex Stainless Steel, Monel, Inconel. Trim Materials Ball & Shaft: 316 Stainless Steel (standard) with hard-facing options (e.g., Stellite) for erosive service. Seat: Multiple Options: - Soft Seat: Reinforced PTFE (RPTFE), PEEK for tight shut-off and lower temperatures. - Metal Seat: 17-4PH SS, Stellite, for high temperatures and erosive services. Flow Capacity (Cv) Extremely high Cv values. Specific values depend on size and trim. (e.g., an 8" SS-263 can have a Cv over 2000). Rangeability Very High, typically 100:1 or greater. Leakage Class Soft Seat (PTFE, PEEK): ANSI Class IV (bubble-tight) Metal Seat: ANSI Class V Fire-Tested: Designs available to meet API 607/API 6FA fire test standards. Actuator Options Pneumatic: Piston actuators (e.g., 1061P) are standard for the high thrust requirements of the SS-263. Electro-Hydraulic: Design EH for precise digital control. Hydraulic: Also available. Accessories Positioners, limit switches, solenoid valves, supply pressure regulators, etc.

Key Specifications & Parameters Parameter Specification Model Series GX (Comprises a valve body and a 657/667 diaphragm actuator) Valve Type Globe Valve, Characterized Cage-Guided Actuator Type Spring-and-Diaphragm, Field-Reversible (for Air-to-Open or Air-to-Close action) Sizes Valve Body (Port Size): 1/2 inch to 3 inches (DN 15 to DN 80) Actuator Size: 3 sizes (e.g., 30, 45, 70) to match valve size and pressure requirements. End Connections Screwed (NPT): Standard Flanged: ANSI Class 150 & 300 RF Socket Weld: Available Pressure Ratings ANSI Class: 150, 300, 600 (depending on body size and material) Max. Shut-off Pressure (P₁ - P₂): Dependent on actuator size and spring range. Consult performance tables. Temperature Range Standard: -20° to 400°F (-29° to 204°C) Extended: -50° to 450°F (-46° to 232°C) with specialized packing. Body Materials Standard: Carbon Steel (A216 WCB) Options: Stainless Steel (CF8M / 316), Alloy 20 (CN7M), Bronze. Trim Materials Standard Trim (Cage, Plug, Stem): 316 Stainless Steel Seat Ring: 316 Stainless Steel Soft Seat: PTFE (Teflon) for bubble-tight shut-off (ANSI Class VI). Flow Characteristics Equal Percentage (Standard, via characterized cage) Linear (Optional) Flow Capacity (Cv) Ranges from approximately 1.5 (for 1/2") to over 200 (for 3"), depending on trim level. Rangeability 50:1 Leakage Class ANSI Class VI (Bubble-tight) with standard PTFE soft seat. Actuator Spring Ranges Multiple standard ranges (e.g., 3-15 psig, 6-30 psig, etc.) to provide the required thrust for the application. Accessories Positioners: DVC6200 (Digital), 3582i (Pneumatic) Limit Switches, Solenoid Valves, Air Sets, Fail-Safe Kits (for loss of air supply).

Key Specifications & Parameters Parameter Specification Model SS-252B (with various trim options and actuator types) Valve Type Segmented V-Notch Ball, Rotating Shaft Flow Characteristic Approximated Equal Percentage (inherent, due to the V-notch profile) Sizes 1/2 inch to 8 inches (DN 15 to DN 200) End Connections Flanged: ANSI Class 150, 300, 600 (RF, RTJ) Other: Butt Weld, Socket Weld (available in smaller sizes) Pressure Ratings ANSI Class: 150, 300, 600 Max. Pressure: Dependent on size and class, up to ANSI 600 rating (e.g., 1440 psig @ 100°F / 38°C for Class 600). Temperature Range Standard: -50° to 800°F (-46° to 427°C) Extended: Options available for cryogenic services down to -320°F (-196°C) and high-temperature services up to 1200°F (649°C) with special components. Body Materials Standard: 316 Stainless Steel (CF8M) Options: Carbon Steel (WCB), Alloy 20 (CN7M), Hastelloy C, Duplex Stainless Steel, and others. Trim Materials Ball & Shaft: 316 Stainless Steel (standard) Seat: Reinforced PTFE (Teflon), RPTFE, PEEK, Metal Seats (e.g., 17-4PH SS, Stellite) for high-temperature or abrasive services. Flow Capacity (Cv) Very high Cv values compared to same-size globe valves. Specific values depend on size and trim; consult sizing data. (e.g., a 3" SS-252B can have a Cv over 200). Rangeability High, typically 50:1 or greater. Leakage Class Soft Seat (PTFE): ANSI Class IV (bubble-tight) Metal Seat: ANSI Class V or Class VI (Fire-tested designs available) Actuator Options Pneumatic: Double-acting or spring-return piston actuators (e.g., with 1061P or 1066P actuator). Electro-Hydraulic: The Design EH option provides high thrust for precise digital control. Accessories Positioners, limit switches, solenoid valves, supply pressure regulators, etc.

Key Specifications & Parameters Parameter Specification Model Series 262K (e.g., 262KSP, 262KSR, 262KES, etc.) Type Piston-Actuated, Balanced Valve Primary Function Pressure Reducing (can be configured for Back-Pressure Regulation) Sizes 1/2 in. to 3 in. (DN 15 to DN 80) End Connections NPT (standard), ANSI Flanged (RF, RJ), SW (Socket Weld) Pressure Ratings Body Ratings: ANSI Class 125, 150, 200, 300 (depending on body material and size) Max. Inlet Pressure (P1): Up to 400 psig (27.6 bar) for certain sizes Outlet Pressure (P2) Ranges: Various spring ranges available, typically from 3 to 200 psig (0.2 to 13.8 bar). Consult sizing software for specific capabilities. Temperature Range Standard Packing: -20° to 400°F (-29° to 204°C) High-Temp Packing: Up to 800°F (427°C) with appropriate materials. Note: Temperature limits are also dependent on seat material. Body Materials Standard: Ductile Iron Options: Cast Iron, Carbon Steel (WCB), Stainless Steel (CF8M/316), Bronze. Trim Materials Standard Trim: 11-13% Chrome Stainless Steel stem, 410SS piston, 316SS seat ring. Soft Seat: Buna-N, EPDM, FKM (Viton), PTFE (Teflon) O-rings for tight shut-off. Flow Characteristics Equal Percentage (inherent) Leakage Class Soft Seat: ANSI Class IV (bubble-tight shut-off) Metal Seat: ANSI Class II Actuator Type Spring & Diaphragm Actuator with a Piston Operator. The piston provides high thrust and fast response. Accessories Pilot-operated Actuators (262PES): For higher outlet pressures or where a larger diaphragm is needed for sensitivity. Internal Check Valves (262CV): Prevents reverse flow. Separate Strainers

Key Specifications & Parameters Parameter Specification Model 6060 Level Transmitter Measurement Principle Hydrostatic Pressure Output Signal 2-wire, 4-20 mA DC, HART® protocol (optional) Power Supply 12 to 42 V DC (standard loop power) Accuracy Typically ±0.25% of calibrated span (includes linearity, hysteresis, and repeatability) Zero & Span Adjustments Field adjustable via potentiometers or magnetic pushbuttons (depending on version) Wetted Materials Diaphragm: 316L Stainless Steel, Hastelloy C-276 O-Rings: FKM (Viton®), EPDM, FFKM (Kalrez®) Process Connection 2-inch NPT (standard); ANSI 150 lb and DIN flanges available Electrical Connection 1/2-inch NPT conduit entry Fill Fluid Silicone Oil (standard) or Halocarbon Oil (for oxygen service) Mounting Flush or extended diaphragm configurations. Can be mounted directly to the tank or via a remote seal (for high temperature applications). Performance - Turn Down Ratio 10:1 - Response Time <10 ms (typical) - Stability <±0.1% of URL per year Environmental - Ambient Temp. Range -40° to 185°F (-40° to 85°C) - Process Temp. Range With Silicone Fill: -40° to 248°F (-40° to 120°C) With Halocarbon Fill: -40° to 248°F (-40° to 120°C) Remote Seal Options: Allow for much higher process temperatures. - Storage Temp. Range -40° to 185°F (-40° to 85°C) - Humidity 0 to 100% RH Mechanical - Weight Approximately 4.5 lbs (2.0 kg) - Enclosure Rating NEMA 4X (IP66) - Material 316 Stainless Steel Approvals CE, RoHS, RCM (varies by specific model and configuration)
