Technical Specifications Parameter / Spec Value / Description Brand / Series Vickers by Eaton — DG4V-5M, 22 Series Model Code DG4V-5M-2AJ-M-KUP5-H7-22-EN194 Valve Type Directional control valve, solenoid-operated Actuation Type Solenoid operated Coil / Electrical Connection Integrated Deutsch connector (“KUP5”) Coil Rating / Voltage 24 V DC Flow Capacity up to 32 US gpm (≈ 120 L/min) Maximum Operating Pressure (Ports P, A, B) 315 bar (≈ 4500 psi) Tank Port Pressure Rating (Port T) 210 bar (≈ 3000 psi) Seal Material (standard) Viton Fluid Compatibility Petroleum-based hydraulic oils Fluid Cleanliness Requirement 19/17/14 micron code Spool Type Spool 22 (2AJ) Spool Spring / Center Arrangement Spring-offset, end-to-end (spring returns spool toward one end when de-energized) Stage Single-stage directional valve Mounting / Interface Subplate / manifold mount, ISO 4401-05 (NG10 / D05) standard Manual Override Plain manual override (standard) Performance Level High-performance industrial directional valve Operating Ambient Temperature Range –20 °C to +70 °C (–4 °F to +158 °F) Power Consumption (coil) 38 W (when energized) Electrical Response / Energising Time ~ 120–45 ms (typical)

Technical Specifications Brand / Series: Vickers by Eaton — DG4V‑5, 20 Series Model Code: DG4V‑5-8CJ-VM-U-H6-20 Valve Type: Solenoid-operated directional control valve (4-way / 3-way depending on spool) Mounting / Interface: Subplate / manifold mount — ISO 4401‑05 (D05 / NG10) Actuation: Solenoid operated (wet-armature) Electrical Connection: ISO 4400 (DIN 43650) connector Coil Rating / Type: 24 V DC Maximum Flow Rate: Up to 32 US gpm (≈ 120 L/min) Maximum Operating Pressure (P, A, B ports): 315 bar (≈ 4500 psi) Tank (T) Port Pressure Rating: 160 bar (≈ 2320 psi) Seal Material (standard): Viton Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: 19/17/14 micron code Spool Type / Center Condition: Spool “8CJ”, spring-centered spool with four-land design Stage: Single-stage directional valve Manual Override: Plain (manual override at solenoid ends) Valve Mount Type: Subplate / manifold mounted (ISO / NFPA standard) Ambient / Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F)

Technical Specifications Brand / Series: Vickers by Eaton — DG4V‑5, 20 Series Model Code: DG4V‑5-0CJ-VM-U-H6-20 Valve Type: Solenoid-operated directional control valve (4-way / 3-way depending on port/spool configuration) Mounting / Interface: Subplate / manifold mount — ISO 4401‑05 (D05 / NG10) Actuation: Solenoid operated Electrical Connection: ISO 4400 (DIN 43650) connector Coil Rating / Type: 24 V DC Maximum Flow Rate: Up to 32 US gpm (≈ 120 L/min) Maximum Operating Pressure (P, A, B ports): 315 bar (≈ 4500 psi) Tank (T) Port Pressure Rating: 160 bar (≈ 2320 psi) Seal Material (standard): Viton Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: 19/17/14 micron code Spool Type / Center Condition: Spool “0CJ”, spring-centered Stage: Single-stage directional valve Manual Override: Plain (manual override at solenoid ends) Valve Mount Type: Subplate / manifold mounted (ISO / NFPA standard) Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F)

Technical Specifications Brand / Series: Vickers by Eaton — DG4V‑5 series Model Code: DG4V‑5-22AJ-MUH620 Valve Type: Solenoid-operated directional control valve (4-way / 3-way depending on spool/port configuration) Mounting / Interface: Subplate / manifold mount — ISO 4401‑05 (D05 / NG10) Actuation: Solenoid operated Electrical Connection: ISO 4400 (DIN 43650) connector Coil Voltage: 24 V DC Maximum Flow Rate: Up to 32 US gpm (≈ 120 L/min) Maximum Operating Pressure (P, A, B ports): 315 bar (≈ 4500 psi) Tank Port Pressure (T port): 160–210 bar (≈ 2320–3050 psi) Seal Material (standard): Viton Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: 19/17/14 micron code Spool Type / Center Condition: Spool “22AJ”, spring-offset or spring-centered (depending on configuration) Stage: Single-stage directional valve Manual Override: Plain (manual override at solenoid ends) Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F) Valve Body Material: Cast gray iron

Technical Specifications Brand / Series: Vickers by Eaton — DG4V‑5 series Model Code: DG4V‑5-22NJ-M-U-H6 Valve Type: Solenoid-operated directional control valve (4-way / 3-way depending on spool/port configuration) Mounting / Interface: Subplate / manifold mount — ISO 4401‑05 (D05 / NG10) Actuation: Solenoid operated Electrical Connection: ISO 4400 (DIN 43650) connector Coil Voltage: 24 V DC Maximum Flow Rate: Up to 32 US gpm (≈ 120 L/min) Maximum Operating Pressure (P, A, B ports): 315 bar (≈ 4500 psi) Tank Port Pressure (T port): 160–210 bar (≈ 2320–3050 psi) Seal Material (standard): Viton Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: 19/17/14 micron code Spool Type / Center Condition: Spool “22NJ”, spring-centered or spring-offset depending on configuration Stage: Single-stage directional valve Manual Override: Plain (manual override at solenoid ends) Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F) Valve Body Material: Cast gray iron

Technical Specifications Brand / Series: Eaton — DPS2 series Model Code: DPS2‑10‑P‑F‑0‑160 Valve Type: Pressure reducing / relief valve Mounting / Interface: Subplate or inline mount (standard DPS2 mounting) Flow Capacity: 10 L/min (nominal, depends on system conditions) Maximum Pressure Setting: 160 bar Valve Function: Pressure limiting / relief for hydraulic circuits Actuation Type: Pilot-operated Seal Material (standard): Nitrile (Buna‑N) or Viton depending on configuration Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: ISO 19/17/14 (recommended) Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F) Valve Body Material: Steel or cast iron (industrial hydraulic construction) Response Time: Fast-acting for pressure control Mounting Port Size: 1/2" BSP or NPT (depending on variant)

Technical Specifications Brand / Series: Eaton — DPS2 series Model Code: DPS2‑10‑B‑F‑0‑80 Valve Type: Pressure relief / pressure reducing valve, pilot-operated Mounting / Interface: Subplate or inline mount (standard DPS2 mounting) Flow Capacity: 10 L/min (nominal, depending on system conditions) Maximum Pressure Setting: 80 bar Valve Function: Pressure limiting / relief Actuation Type: Pilot-operated Seal Material (standard): Nitrile (Buna‑N) or Viton depending on configuration Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: ISO 19/17/14 recommended Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F) Valve Body Material: Steel or cast iron Response Time: Fast-acting, precise pressure control Mounting Port Size: 1/2" BSP or NPT (depending on variant)

Technical Specifications Brand / Series: Vickers by Eaton — DG4V‑3 series Model Code: DG4V‑3‑2A Valve Type: Solenoid-operated directional control valve (4-way / 3-way depending on spool/port configuration) Mounting / Interface: Subplate / manifold mount — ISO 4401‑03 (D03 / NG06) Actuation: Solenoid operated Electrical Connection: ISO 4400 (DIN 43650) connector Coil Voltage: 24 V DC Maximum Flow Rate: Up to 21 US gpm (≈ 80 L/min) Maximum Operating Pressure (P, A, B ports): 350 bar (≈ 5000 psi) Tank Port Pressure (T port): 210 bar (≈ 3000 psi) Seal Material (standard): Viton Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: ISO 19/17/14 recommended Spool Type / Center Condition: Spool “2A”, spring-centered or spring-offset depending on configuration Stage: Single-stage directional valve Manual Override: Plain (manual override at solenoid ends) Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F) Valve Body Material: Cast gray iron

Technical Specifications Brand / Series: Eaton — DSV2 series Model Code: DSV2‑8‑B‑0 Valve Type: Direct-acting solenoid-operated directional control valve Mounting / Interface: Subplate / manifold mount (standard DSV2 mounting) Actuation: Solenoid operated Electrical Connection: ISO 4400 (DIN 43650) connector Coil Voltage: 12 V DC or 24 V DC (depending on variant) Maximum Flow Rate: 8 US gpm (≈ 30 L/min) Maximum Operating Pressure (P, A, B ports): 210 bar (≈ 3000 psi) Tank Port Pressure (T port): 50 bar (≈ 725 psi) Seal Material (standard): Nitrile (Buna‑N) Fluid Compatibility: Petroleum-based hydraulic oils Fluid Cleanliness Requirement: ISO 19/17/14 recommended Spool Type / Center Condition: Spool “B”, spring-centered Stage: Single-stage valve Manual Override: Optional (depends on configuration) Operating Temperature Range: –20 °C to +70 °C (–4 °F to +158 °F) Valve Body Material: Aluminum alloy or steel (depending on model)

Key Parameters Item Parameter / Description Maximum pressure (ports P, A, B) 350 bar (≈ 5075 psi) Maximum tank (T port) pressure 210 bar (≈ 3045 psi) Maximum flow rate Up to 80 L/min (≈ 21 US gpm) Minimum pressure drop ≈ 2.5 bar at 30 L/min Spool type (for “2C”) Closed‑center spool, spring‑centered arrangement Valve function / flow direction 4‑way directional control (P ↔ A/B ↔ T) Actuation / Electrical connection Solenoid‑operated; DIN 43650 (ISO 4400) coil/connector Electrical spec (common variant) 110 V AC (50 Hz) / 120 V AC (60 Hz) coil — for 60‑design version Operating temperature range –20 °C to +70 °C (–4 °F to +158 °F) Valve size / series DG4V‑3 series, ISO 4401‑03 / D03 / CETOP 3
