Parameter Specification Product Series Eaton A22 Model Number A22-EC20 Description 22mm Illuminated Push Button Operator, Momentary, Flat, Yellow LED Operator Type Illuminated Push Button Button Color Black (Translucent, illuminated by LED) Lens Shape Flat LED Color Yellow (Amber) Contact Action Momentary (returns to normal position when released) Rated Voltage for LED Typically 24V DC (or as specified by the accompanying contact block/LED module). Note: The LED circuit is separate from the main contact block's power circuit. Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Button Cap and Body)

Parameter Specification Product Series Eaton A22 Model Number A22-EC11 Description 22mm Illuminated Push Button Operator, Momentary, Flat, Red LED Operator Type Illuminated Push Button Button Color Black (Translucent, illuminated by LED) Lens Shape Flat LED Color Red Contact Action Momentary (returns to normal position when released) Rated Voltage for LED Typically 24V DC (or as specified by the accompanying contact block/LED module). Note: The LED circuit is separate from the main contact block's power circuit. Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Button Cap and Body)

Parameter Specification Product Series Eaton A22 Model Number A22-EK10 Description 22mm Push Button Operator, Momentary, Flat, Red Operator Type Push Button Button Color Red Button Shape Flat Contact Action Momentary (returns to normal position when released) Rated Operational Current Note: This depends on the contact block used. The A22-EK10 is the operator. Common contact blocks are rated at: 10A @ 250VAC / 5A @ 440VAC / 10A @ 125VDC Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Button Cap and Body) Standards & Certifications CE, UL508, CSA C22.2 No.14, CCC, and others for global markets.

Parameter Specification Product Series Eaton A22 Model Number A22-BE6 Description 22mm Selector Switch Operator, 2-Position Maintained, Metal Handle Operator Type Selector Switch (Rotor) Handle Type/Color Metal Handle, Black Number of Positions 2 Contact Action Maintained (Stays in selected position) Rated Operational Current Note: This depends on the contact block used. The A22-BE6 is the operator. Common contact blocks are rated at: 10A @ 250VAC / 5A @ 440VAC / 10A @ 125VDC Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic Body with Metal Handle Standards & Certifications CE, UL508, CSA C22.2 No.14, CCC, and others for global markets.

Parameter Specification Product Series Eaton A22 Model Number A22-EC02 Description 22mm Illuminated Push Button Operator, Momentary, Flat, Green LED Operator Type Illuminated Push Button Button Color Black (Translucent, illuminated by LED) Lens Shape Flat LED Color Green Contact Action Momentary (returns to normal position when released) Rated Voltage for LED Typically 24V DC (or as specified by the accompanying contact block/LED module). Note: The LED circuit is separate from the main contact block's power circuit. Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Button Cap and Body)

Parameter Specification Product Series Eaton A22 Model Number A22-EFR Description 22mm Emergency Stop Push Button Operator, Mushroom Head, Red/Yellow Operator Type Emergency Stop (Mushroom Push Button) Head Color Red with Yellow Base Ring Head Type Mushroom (Large, prominent head for easy and rapid activation) Contact Action Maintained (Once pressed, it stays pressed until manually reset) Reset Mechanism Manual Rotational Reset (Turn the mushroom head to release it from the latched position) Rated Operational Current Note: This depends on the contact block used. The A22-EFR is the operator. Common safety contact blocks are rated at: 10A @ 250VAC / 5A @ 440VAC / 10A @ 125VDC Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Head and Body) Safety Standards Complies with international machinery safety standards such as IEC 60947-5-1 and IEC 60947-5-5. System Feature Modular design. The A22-EFR operator must be paired with a compatible A22 contact block (e.g., A22-T-, A22-TA-, A22-TB

Parameter Specification Product Series Eaton A22 Model Number A22-BE3C Description 22mm Selector Switch, 2-Position Maintained, 1NO+1NC Operator Type Selector Switch (Rotor) Knob Color Black Number of Positions 2 Contact Action Maintained (Stays in selected position) Contact Configuration 1 Normally Open (1NO) + 1 Normally Closed (1NC) (This is typically achieved with a common terminal (C), where C->NO closes in one position, and C->NC opens in the same position, and vice-versa in the other position.) Rated Operational Current 10A @ 250VAC / 5A @ 440VAC / 10A @ 125VDC Rated Insulation Voltage 500VAC Dielectric Strength 2000VAC for 1 minute Electrical Life 500,000 cycles (min.) Mechanical Life 10,000,000 cycles (min.) Terminals Screw Terminals Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Knob and Body) Standards & Certifications CE, UL508, CSA C22.2 No.14, CCC, and others for global markets. System Feature Modular design. The switch operator (A22-BE3C) can be mounted on various A22 contact blocks and combined with other accessories.

Parameter Specification Product Series Eaton A22 Model Number A22-EK10C Description 22mm Push Button Switch, Momentary, 1NO, Red Operator Type Push Button Button Color Red Button Shape Concave (Recessed) Contact Configuration 1 Normally Open (1NO / 1 Form A) Contact Action Momentary (returns to normal position when released) Rated Operational Current 10A @ 250VAC / 5A @ 440VAC / 10A @ 125VDC Rated Insulation Voltage 500VAC Dielectric Strength 2000VAC for 1 minute Electrical Life 500,000 cycles (min.) Mechanical Life 10,000,000 cycles (min.) Terminals Screw Terminals Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Button Cap and Body) Standards & Certifications CE, UL508, CSA C22.2 No.14, CCC, and others for global markets. System Feature Modular design, compatible with the extensive A22 series of contact blocks, LED indicators, and enclosures.

Parameter Specification Product Series Eaton A22 Model Number A22-EK01C Description 22mm Push Button Switch, Momentary, 1NO Operator Type Push Button Button Color Black Button Shape Concave (Recessed) Contact Configuration 1 Normally Open (1NO / 1 Form A) Contact Action Momentary (returns to normal position when released) Rated Operational Current 10A @ 250VAC / 5A @ 440VAC / 10A @ 125VDC Rated Insulation Voltage 500VAC Dielectric Strength 2000VAC for 1 minute Electrical Life 500,000 cycles (min.) Mechanical Life 10,000,000 cycles (min.) Terminals Screw Terminals Mounting 22mm round hole, panel-mounted from the front with a supplied nut. Protection Degree IP65 (when properly mounted on panel - dust-tight and protected against water jets) Material Thermoplastic (Button Cap and Body) Standards & Certifications CE, UL508, CSA C22.2 No.14, CCC, and others for global markets. System Feature Modular design, compatible with the extensive A22 series of contact blocks, LED indicators, and enclosures.

Parameter Specification Product Series Eaton Wiring Devices / Commercial Grade Model Number Y22-10T Description 20A Quiet Toggle Switch, Single-Pole Color Ivory (Light Brown) Actuation Type Toggle Lever Control Type Single-Pole (SP) Rated Voltage 120V AC / 277V AC Rated Current 20 Amps Rated Load General Use: 20A Resistive Motor Load (HP): 2 HP at 120V/240V; 3 HP at 277V Wiring Single-Pole. Side-wiring only (no back-wire). Terminals Two side screw terminals. Requires looping wire on screws. Mounting Standard wall box Faceplate Sold separately; requires a standard single-gang wall plate. Material Thermoplastic Body and Toggle Certifications UL Listed (US) and CSA Certified (Canada) Special Features Quiet Switch: Mechanism designed for quieter operation. Commercial Grade: Built for higher durability and longer life than residential-grade switches. Typical Use Controlling lighting fixtures, outlets (if switched), and ventilation fans from one location.
