Parameter Specification Product Series Eaton ED6X (Accessory for D6 MCB) Model Number ED6X-16/2/C/003 Description Residual Current Release Module, for 2-Pole MCB, 30mA Compatible With Eaton D6 series, 2-pole Miniature Circuit Breakers Rated Current of Assembly Up to 25A (When combined with a compatible D6 MCB) Rated Residual Operating Current (IΔn) 30 mA Residual Current Type Type AC (for alternating sinusoidal residual currents only) Rated Voltage 230V AC Mounting Snaps onto the side of a compatible D6 MCB on a DIN Rail. Standards & Certifications IEC 61009-1, CE

Parameter Specification Product Series Eaton D6 Model Number D6-16/1N/C/003-A Description Miniature Circuit Breaker (MCB), 2-Pole, 16A, Curve C Number of Poles 2 Poles (1 Phase + Neutral) Rated Current (In) 16 A Tripping Characteristic Curve C (5-10 x In) Rated Operational Voltage (Ue) 230/400V AC Rated Insulation Voltage (Ui) 500V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Rated Short-circuit Breaking Capacity (Icn) 6 kA Mechanical Life 20,000 cycles Electrical Life 10,000 cycles Mounting DIN Rail (35mm) Standards & Certifications IEC 60898-1, CE

Parameter Specification Product Series Eaton ED6 Model Number ED6-10/1N/C/003-A Description Residual Current Circuit Breaker (RCCB), 2-Pole, 25A, 30mA Number of Poles 2 Poles (1 Phase + Neutral) Rated Current (In) 25 A Rated Residual Operating Current (IΔn) 30 mA Rated Voltage (Ue) 230V AC Rated Short-circuit Capacity (Icn) 10 kA Residual Current Type Type AC (for alternating currents only) Tripping Characteristic Instantaneous Overcurrent Protection No (Requires backup protection by MCB or fuses) Mechanical Life 20,000 cycles Electrical Life 2,000 cycles Mounting DIN Rail (35mm) Standards & Certifications IEC 61008-1, CE

Parameter Specification Product Line Eaton Zero-Xposure Model Number ZX-FW-LPB Description Fusible Safety Disconnect Switch, Large Push Button, 30HP/60A Rated Horsepower (HP) 30 HP @ 240V AC / 50 HP @ 480V AC / 60 HP @ 600V AC Rated Amperage (A) 60 A Rated Voltage (V AC) 240V / 480V / 600V Type Fusible Disconnect Switch Actuation Large, Yellow Push Button (Turns to OFF position) Safety Standard Complies with OSHA Lockout/Tagout requirements and relevant UL/CSA standards. Locking Capability Yes, accepts multiple safety locks (up to 3 or 6, depending on the specific model variant). Fuse Type Accepts standard Class R, J, or T fuses (not included). Enclosure Rating Typically NEMA 1, 3R, 4, 4X, 12 (depending on the specific enclosure ordered). Application Used as a main or branch circuit safety disconnect for industrial machinery, motors, and control panels to ensure safe maintenance.

Parameter Specification Product Series Eaton EIT (Industrial Indicators) Model Number EIT30Y-15BO1B Description 30mm Panel Indicator Light, Yellow, Incandescent, 24V Lens Color Yellow (Y) Mounting Hole Size 30 mm Light Source Incandescent Bulb (pre-installed) Rated Voltage 24V AC/DC Bulb Power Typically ~1.5W to 3W (e.g., 24V, 1.7W) Bulb Life Shorter than LED (typically several thousand hours) Terminals Screw terminals or quick-connect, at the rear Mounting Panel mount, secured with a supplied bayonet ring Material Thermoplastic lens and body Agency Approvals UL, CSA, CE

Parameter Specification Product Series Eaton IZM Model Number IZM65B3-EGC06WH Description Molded Case Circuit Breaker, 63A, 3-Pole, Electronic Trip, Fixed Mount Frame Size IZM65 Rated Current (In) 63 A (Fixed) Number of Poles 3 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Rated Ultimate Short-Circuit Breaking Capacity (Icu) High, e.g., 35 kA or 65 kA @ 480V AC Trip Unit Type Electronic Trip Unit (Fixed Setting, as per "EGC06") Protection Functions Long-time delay, Short-time delay, Instantaneous (configurable within the EGC06 preset range) Mounting Fixed Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton IZM Model Number IZM67B3-PG20WH Description Molded Case Circuit Breaker, 250A, 3-Pole, Current Limiting, Fixed Mount Frame Size IZM67 Rated Current (In) 250 A (Fixed) Number of Poles 3 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Rated Ultimate Short-Circuit Breaking Capacity (Icu) Very High, e.g., 65 kA or 100 kA @ 480V AC Trip Unit Type Electronic (as suggested by "PG" code, which often denotes a specific electronic trip unit setting) Mounting Fixed Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton IZM Model Number IZM65N4-A04WH Description Molded Case Circuit Breaker, 65A, 4-Pole, Fixed Mount Rated Current (Iu) 65 A Number of Poles 4 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Trip Unit Thermal-Magnetic (Fixed) Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton A22 (Accessory) Model Number A22-RD-53 Description 8-Pin Round Pin Relay Socket Terminal Type Screw Clamp Number of Pins 8 Pin Shape Round Rated Operational Current Typically 10A (dependent on the relay used) Rated Insulation Voltage 500V Mounting DIN Rail (35mm) Material Thermoplastic (PBT) Compatible Devices 8-pin round pin control relays, timer relays (e.g., Eaton A22 series compatible devices) Standards & Certifications UL 508, CSA, CE

Parameter Specification Product Series Eaton Power Xpert D2 Model Number PDC94G0100D2YJ Description DIN Rail DC Power Supply, 100W, 24V DC Out Output Power 100 W Output Voltage 24 V DC Output Current 4.2 A Input Voltage Range 85 - 264 V AC (Wide Range, suitable for global use) Input Frequency 47 - 63 Hz Efficiency High (typically >89%) Power Factor (PFC) >0.9 Line Regulation <±1% Load Regulation <±1% Ripple & Noise <150mV peak-to-peak Protections Overload (115-150%), Overvoltage, Short-circuit Operating Temperature -25°C to +70°C (with derating) Cooling Convection (Fanless) Mounting DIN Rail (35mm) Safety & EMC CE, cULus, RoHS, compliant with IEC/EN/UL 62368-1
