SC-UMIX01: Universal Signal Mixer/Converter Module (RTU Interface)

Honeywell CC-PAIL51
Function: 8-Channel Analog Input Module for Experion® C-Series I/O, with HART protocol support.

Key Features:

Inputs: 8 isolated 4–20mA channels (±0.1% accuracy, 16-bit resolution).

HART Integration: Pass-through digital communication for smart field devices.

Safety Isolation: 1500 VAC (channel-to-channel and channel-to-system).

Speed: 10 ms per channel scan.

Compatibility:

Mounts in C200/C300 I/O chassis (e.g., CIOM racks).

Robust Design:

Industrial-grade (-40°C to +70°C; ATEX/IECEx Zone 2, SIL 2/3 certified).

Honeywell CC-IP0101
Function: Profibus DP Interface Module for Honeywell Experion® C-Series controllers (C200/C300).

Key Role:

Connects Experion controllers to Profibus DP field devices (sensors, drives, I/O slaves).

Supports high-speed communication (up to 12 Mbps) with redundant ports for daisy-chaining.

Critical Features:

1500 VAC isolation (field-to-system safety).

Industrial hardened: Operates in -40°C to +70°C harsh environments.

DIP-switch addressing (1–126).

Compliance:

CE, ATEX Zone 2, SIL 2 (optional).

Honeywell CC-PSP401
Function: 120W Power Supply Module for Experion® C-Series I/O systems.

Key Features:

Input: 85–265 VAC (50/60 Hz) or 88–300 VDC (universal).

Output: 24 VDC, 5A (120W max).

Redundancy: Supports N+1 backup (hot-swappable).

Protections: Short-circuit, over-voltage, and thermal shutdown.

Compatibility:

Designed for Experion C200/C300 I/O chassis (e.g., CIOM/HIOM racks).

Robust Design:

Industrial-grade (-40°C to +70°C; 5–95% humidity).

Certifications: UL, CE, ATEX Zone 2.

Honeywell CC-PCNT02
Function: Profibus DP Termination Module for Honeywell Experion® PKS systems.

Key Role:

Passive termination device ensuring signal integrity at both ends of Profibus DP networks (per IEC 61158-2).

Integral 220Ω resistor prevents signal reflection/data errors.

Compatibility:

Works with Experion C200/C300 controllers and Profibus DP I/O modules (e.g., CIOM series).

Installation:

DIN-rail mounted; requires no external power.

Environmental:

Industrial temp range (-40°C to +70°C).

Honeywell 900P01-0301=2
Function: Redundancy-Ready CPU Module for HC900 Process Control Systems.

Core Role:

Primary processor for executing control logic (PID, sequencing) in HC900 racks.

Supports hot-swap N+1 redundancy for fail-safe operation.

Key Specs:

I/O Capacity: Up to 16 modules (256 points).

Communications: Modbus TCP (Ethernet), Modbus RTU/ASCII (RS-232/485).

Environment: -40°C to +70°C industrial rating.

Integration:

Requires HC900 C70/C75 chassis; compatible with analog/digital I/O modules.

Honeywell 900C75-0460=2
Function: 120W Power Supply Module for HC900 Process Control Systems.

Key Features:

Input: 85–265 VAC (50/60 Hz) or 88–300 VDC (universal).

Output: 24 VDC, 5A (regulated, 120W max).

Redundancy: Supports N+1 backup with identical modules.

Protections: Short-circuit, over-voltage, and thermal shutdown.

Compatibility:

Designed for HC900 C50/C70/C75 racks.

Robust Design:

Operates in -40°C to +70°C harsh environments.

Certifications: UL, CE, ATEX Zone 2.

Honeywell HC900RR0-0101
Function: CPU Module for Honeywell’s HC900 Hybrid Process Control System.

Core Role:

Acts as the central processor for HC900 racks, executing control logic (PID, sequencing, etc.).

Supports 16 I/O modules (max 256 points) for analog/digital signals.

Key Features:

Communications: Ethernet (Modbus TCP), RS-232/485 (Modbus RTU/ASCII), embedded web server.

Robust Operation: -40°C to +70°C industrial temperature range.

Power: 24 VDC (±10%).

Honeywell XF524A
Function: Dual-Circuit Monitor Module for conventional fire alarm systems.

Key Features:

Monitors two independent dry-contact devices (e.g., flow switches, tamper switches, door holders).

Input Voltage: 15–32 VDC (regulated).

Low Power: Standby ≤1.5 mA; alarm ≤6 mA per circuit.

Wiring: Class A (Style Z) or Class B (Style Y) supervision.
