Core Function:
Industrial eddy current sensor for extended-range displacement monitoring in heavy rotating equipment

Key Specifications:
• Sensitivity: 3.1 mV/µm (±5%)
• Extended Range: 0-3.1mm (3100µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Mechanical Configuration:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ Operating temperature: -30°C to +120°C
✓ Vibration resistant to 20g

Measurement Performance:

Target material: AISI 4140 steel

Linear operating range: 60% of full scale

Typical accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 monitoring systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Special Features:

Extended 3.1mm measurement range

Special /005 variant with enhanced environmental tolerance

Optimized for heavy industrial applications

Typical Applications:

Large turbine shaft monitoring

Compressor thrust bearing measurement

Heavy machinery protection systems

Compliance: Meets API 670 machinery protection standards
